Elite Screens ER135WH2 User Manual

Fixed frame projection screen

Advertisement

Quick Links

Thank you for choosing an Elite Screens fixed frame projection screen! Please read through this user guide before
utilizing the screen. Correct usage and maintenance will ensure a long product life.
Care & Use Instructions
Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the points
below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
Hardware and Parts List
A. Frame Parts
B. Screen Material
C. Center joints
D. Elbow Joints
E. Wall brackets
F. Wood Screws
G. Drywall anchors
H. M5x15 screws
I. Center Support Bar
J. Support joiner
K. Fix Plates
L. Rubber hammer
M. Screw driver
Note: Please make sure all parts are included in your package before proceeding to assemble your fixed frame
projection screen.
Rev.081914-JA
ezFrame 2 &
Sable Frame 2 Series
Fixed Frame Projection Screen
User's Guide
x 6 pcs (4 top/bottom frame pcs + 2 side frame pcs)
x 1 pc
x 2 pcs
x4 pcs
x4 pcs (depending on model/size)
x 8 pcs
x 8 pcs
x 16 pcs
x 1 - 2 pcs (depending on model/size)
x 2 - 4 pcs (depending on model/size)
x 60 - 180 pcs (depending on model/size)
x 1 pc
x 1 pc
www.elitescreens.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ER135WH2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elite Screens ER135WH2

  • Page 1 Fixed Frame Projection Screen User’s Guide Thank you for choosing an Elite Screens fixed frame projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life. Care & Use Instructions...
  • Page 2: Frame Assembly

    FRAME ASSEMBLY 1. Insert the center joint (c) connector to the ½ horizontal frame piece and fasten it with two M5x15 screws (h). M5×15 Screw ½ Long Frame bevel connection 2. Insert the other ½ horizontal frame piece to the center joint (c) connector and fasten it with two M5x15 screws (h).
  • Page 3 Screw M5x15Screws Push Push Short frame Short frame (Fig.1.2) ( fig.3) Join all four frame parts together following the steps shown below. (Fig.2) Note: When assembled, please push simultaneously the two ends of the long frames. Insert the exposed ends of the joint connectors into the short (vertical) frame and align the four corners so that they meet at perfect right angles Push...
  • Page 4 Attaching the screen material to the frame 1. Make sure the screen material and frame are both lying face down on a clean, dry, and non-abrasive surface. 2. Carefully unroll the material inside the frame. (Fig.3) Please note the material will be noticeably smaller than the frame, as the material must be stretched to create a sufficient amount of tension for perfect material flatness.
  • Page 5 Tip for attaching the last corner (D): 1. Position yourself left of location ①. ③ 2. Pull the material to the corner of the frame with your hand while your left Pull hand snaps in the fix plate on location ①(the third red dot). ④...
  • Page 6: Center Support

    Black backing for AcousticPro models This procedure only applies to AcousticPro models. Disregard this section if your Fixed Frame does not include an acoustically transparent screen material. The purpose of the black backing material is to block out any light penetration that may reflect off of anything mounted behind the screen, which can cause distortion to the projected image.
  • Page 7: Installation

    Diagonal models above 135” require 2x Center Support Bars (Fig. 17) Slide the top end of the bar into the top center point of the frame to complete the center support bar installation. This will provide added stability to your frame and added tension to the material. Installation 1.
  • Page 8 7. In order to avoid damaging the screen, avoid touching it directly with your fingers, tools or any other sharp or abrasive objects. 8. Spare Parts should be placed out of reach of small children in accordance with household safety guidelines. For a local Elite Screens contact or Technical Support, please visit www.elitescreens.com Rev.081914-JA...
