  • Page 10: Safety Instructions

    Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 1 General 1.1 Introduction Only have the fire installed by a qualified installer according to the water and electric safety regulations. Read this installation manual properly. 1.2 Check  Before installation, check the fire for transport damage and report immediately to your supplier.

  • Page 11: Installation Instructions

    Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 4 Installation instructions 4.1 Preparing the fire  Ensure that all packing items are removed.  Remove the transport screw on the front see fig. 1.0.  Remove the front glass and store it at a safe place see Chapter 5.

  • Page 12: Removing Glass

    Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 4.4.2 Water connection This appliance is equipped with the following overflow protections: o Electromechanical valve in the Control box which is sent by an overflow sensor in the water tank. o Absorption valve in the Engine that kicks in when the water sump has an unexpectedly overflow see fig.
  • Page 13 Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 5.2.2 Second front glass For cleaning only it’s not necessary to remove this glass.  Remove the cover strip. See fig. 2.4a, b and c.  Remove both glass springs at the top. See fig. 2.4d.
  • Page 14 Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 8 Using the fire 8.1 Manual control - behind access door (see fig. 4.1) A = main switch 1 = ON/OFF 2 = pairing 3 = only for maintenance (service engineer) 4 = reduce flame...

  • Page 15: Performance Test

    Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 9 Performance test  First time water fill, see Chapter 8.3.  Check all connections for water leakage.  Check if the fan, mounted at the top inside the fire, is running.  Check if the remote control is functioning at the desired distance (max. 8m) o If needed, move the receiver to a different position in- or outside the construction (see fig.
  • Page 16 Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 10.1.2 Cleaning air filter  Gently slide the air filter upwards out of its plastic holder see fig. 8.0.  Gently rinse with water in the sink and dry with fabric towel before returning. ...

  • Page 17: Technical Data

    Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 11 Technical data Watts Volts 230-240 Batteries remote (2x) 1,5 AA Water consumption 0,15 Inlet water pressure 0,5-8 Water connection Inch ½ or ¾ 12 Trouble shooting Symptom Cause Action The flame effect will not start.

  • Page 18: Dimensional Drawings

    Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 13 Dimensional Drawings 13.1 e-MatriX 800/500-RD (LL) 18 < < < <...
  • Page 19 Manual e-MatriX 800-RD/ST (LL) -------------------------------------------------------------------------------------------------------------------------------------- 13.2 e-MatriX 800/500-ST (LL) 19 < < < <...
