  • Page 1 MatriX 800-serie 40011633-1714 MatriX 800 ENG...
  • Page 2 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 3 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 4 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 5 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 6 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 7 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 8 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 9 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 10 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 11 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 12 I n s t a l l a t i o n I n s t r u c t i o n s...

  • Page 13: Installation Requirements

    1.6). The gas regulator block with the receiver and the I.T.C. must be placed on a distance of max. 30cm behind a service Glen Dimplex Benelux certifies that this Faber fire complies with the door. essential requirements of the gas appliances directive.

  • Page 14: Preparation And Installation Instructions

    > Please note: 4.2.2 Faber ITC (Intelligent Technical Controller) The minimum chimney diameter for a 130mm flexible stainless steel pipe must 200x200mm. and for a 100mm flexible stainless The ITC gives you more options, such as ECO control, control, steel pipe 150x150mm.

  • Page 15: Removing The Glass

    I n s t a l l a t i o n I n s t r u c t i o n s 4.4.1 Hanging on the wall 800/500-650-IIL, -IIR and -III 4.6.3 Method I with cover strip (fig. 2.2) The appliance can be wall-mounted with the optional wall bracket Build the false chimney breast or plateau against the moldings H (see fig.

  • Page 16: Checking The Installation

    I n s t a l l a t i o n I n s t r u c t i o n s Removing the glass from the side Checking the burner pressure and primary pressure It is not necessary to take out the glass from the side to place the log set or for maintenance.

  • Page 17: Annual Maintenance

    Only then adjust the TVH or THL. A simple way to calculate whether the exhaust configuration is possible in combination with your fire, use the free “Faber Flue App” If a value is indicated, check that the calculated STL value is not and download it from: lower than indicated in the table.
  • Page 18 I n s t a l l a t i o n I n s t r u c t i o n s 11.1 Restrictor table (100/150) NG MatriX 800/500 – 800/650 Starting length (STL), Vertical (TVH) and Horizontal (THL) 40,2 45,2 45,2...
  • Page 19 I n s t a l l a t i o n I n s t r u c t i o n s 11.2 Restrictor table (130/200) NG MatriX 800/500 Starting length (STL), Vertical (TVH) and Horizontal (THL) 30,4 30,4 30,4 30,3...
  • Page 20 I n s t a l l a t i o n I n s t r u c t i o n s 11.3 Restrictor table (130/200) NG MatriX 800/650 Starting length (STL), Vertical (TVH) and Horizontal (THL) 30,4 30,3 30,4 30,4...
  • Page 21 I n s t a l l a t i o n I n s t r u c t i o n s 11.4 Restrictor table (130/200) LPG MatriX 800/500 Starting length (STL), Vertical (TVH) and Horizontal (THL) 40,4 30,4 30,4 40,4...
  • Page 22 I n s t a l l a t i o n I n s t r u c t i o n s 11.5 Restrictor table (130/200) LPG MatriX 800/650 Starting length (STL), Vertical (TVH) and Horizontal (THL) 40,4 40,4 40,4 30,4...
  • Page 23 I n s t a l l a t i o n I n s t r u c t i o n s Examples flue materials fig. 12.1 fig.12.2 fig. 12.3...
  • Page 24 I n s t a l l a t i o n I n s t r u c t i o n s Calculation sheet Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m...
  • Page 25 I n s t a l l a t i o n I n s t r u c t i o n s found value Search in the table at TVH and THL and enter the value that is found. ………………………………...

  • Page 26: Tecnical Data

    I n s t a l l a t i o n I n s t r u c t i o n s Tecnical data 14.1 MatriX 800/500 II2H3+ II2H3+ II2H3+ Gas category Type appliance C11/C31/C91 C11/C31/C91 C11/C31/C91 Reference gas Input Hi Efficiency class NOx-class...
  • Page 27 I n s t a l l a t i o n I n s t r u c t i o n s 14.2 MatriX 800/650 II2H3+ II2H3+ II2H3+ Gas category Type appliance C11/C31/C91 C11/C31/C91 C11/C31/C91 Reference gas Input Hi 11,3 11,3 11,3...

  • Page 28: Terminal Position

    I n s t a l l a t i o n I n s t r u c t i o n s Terminal position > Please note: These rules apply only for the proper functioning of the unit, for ventilation and environmental protection you need to comply with the applicable rules Short roof terminal.

  • Page 29: Guide De Dépannage

    I n s t a l l a t i o n I n s t r u c t i o n s Guide de dépannage - See inst. manual. - Learn a new code for remote. Light the pilot flame with - 1x 9V Alkaline.
  • Page 30 I n s t a l l a t i o n I n s t r u c t i o n s - Check the complete - Short circuit in the Pilot stays lit wiring of thermocouple thermocouple circuit. circuit.
  • Page 31 I n s t a l l a t i o n I n s t r u c t i o n s - RESET the receiver Optional: - Repaire the wiring. - Check the wiring from Step burner function can solenoid valve to receiver.

  • Page 32: Dimensional Drawings

    I n s t a l l a t i o n I n s t r u c t i o n s Dimensional drawings 17.1 MatriX 800/500-I...
  • Page 33 I n s t a l l a t i o n I n s t r u c t i o n s 17.2 MatriX 800/500-IIL...
  • Page 34 I n s t a l l a t i o n I n s t r u c t i o n s 17.3 MatriX 800/500-IIR...
  • Page 35 I n s t a l l a t i o n I n s t r u c t i o n s 17.4 MatriX 800/500-III...
  • Page 36 I n s t a l l a t i o n I n s t r u c t i o n s 17.5 MatriX 800/650-I...
  • Page 37 I n s t a l l a t i o n I n s t r u c t i o n s 17.6 MatriX 800/650-IIL...
  • Page 38 I n s t a l l a t i o n I n s t r u c t i o n s 17.7 MatriX 800/650-IIR...
  • Page 39 I n s t a l l a t i o n I n s t r u c t i o n s 17.8 MatriX 800/650-III...
  • Page 40 I n s t a l l a t i o n I n s t r u c t i o n s 17.9 Wall bracket...
  • Page 41 I n s t a l l a t i o n I n s t r u c t i o n s 17.10 Remote acces door...
  • Page 42 I n s t a l l a t i o n I n s t r u c t i o n s 17.11 Ventilation grid...
  • Page 43 I n s t a l l a t i o n I n s t r u c t i o n s 17.12 Adjustable feet...
  • Page 44 I n s t a l l a t i o n I n s t r u c t i o n s Dealerinfo: www.faber.nl info@faber.nl Saturnus 8 NL - 8448 CC Heerenveen Postbus 219 NL - 8440 AE Heerenveen...
