- Page 1 Quick Start Guide GD-CI-AP2627T GD-CI-AP4637T GD-CI-AT3637T GD-CI-AT8637T GD-CI-BP4637T grundig-security.com...
- Page 2 Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Abetechs GmbH (Grundig Security) reserves the right to change the contents of this document without prior notice. Design and specifications are subject to change without prior notice.
- Page 3 OPEN SOURCE SOFTWARE LICENSE INFORMATION The software components provided with Grundig products may contain copyrighted software that is licensed under various open source software licenses. For detailed information about the...
- Page 4 You may obtain the complete corresponding open source part of a specific product from us for a period of three years after our last shipment of this product by sending an email to: info@grundig- security.com Safety and Installation Instructions...
- Page 5 Improper use or replacement of the battery may result in the hazard of explosion. Do not use any accessories that are not recommended by GRUNDIG. Do not modify the product in any way. If the product starts to smell or smoke comes out of the device, immediately stop using the product and disconnect it from the power supply to prevent fire or electric shocks.
- Page 6 Installation Instructions It is necessary to fix the device firmly if the product is installed on a wall or ceiling. Do not install the product on surfaces or in places that are vibrating. Do not install the product near radiation sources. Do not install the product near heat sources, like radiators or other equipment that produces some heat.
- Page 7 Special Installation Instructions for IP Cameras Make sure that the latest firmware is installed on the IP Device. You may get the latest firmware from www.grundig-security.com website or from techsupport@grundig-security.com.
-
Page 8: Table Of Contents
3.1 Wiring ................18 3.2 Activating the Camera ........... 19 3.2.1 Activation via Web Browser ........19 3.2.2 Activation via Grundig IP-Finder Tool ....... 20 3.3 Modifying the IP Address ..........22 4 Accessing via Web Browser ............25 4.1 Initializing the Memory Card ......... 27... -
Page 9: Appearance Description
1 Appearance Description The overview of the bullet camera is shown below. 12 13 Overview of the Camera... - Page 10 Description Description Sun Shield Lens Front Cover Three-axis Adjustment Bracket Junction Box Side Outlet Cover Alarm Interface Audio Interface RJ 45 Network Interface Power Interface Cover Reset Button Video Out (BNC) Memory Card Slot Note: Hold RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
-
Page 11: Installation
2 Installation 2.1 Memory Card Installation The camera supports memory card installation. Steps: 1. Loosen the screws using the supplied Allen wrench to remove the cover of the memory card slot. Allen Wrench Remove the Cover of the Memory Card Slot 2. -
Page 12: Camera Mounting
Insert the Memory Card 3. Tighten the screws to replace the slot cover. Replace the Slot Cover 2.2 Camera Mounting 2.2.1 Ceiling/Wall Mount Steps:... - Page 13 1. Drill screw holes in the wall/ceiling according to the holes 1 on the supplied adapter. Drill Holes in the Wall/Ceiling 2. Secure the adapter to the wall/ceiling with the screws. Install the Adapter 3. Loosen the screws to remove the junction box.
- Page 14 Remove the Junction Box 4. Route the cables through the sealing plugs in the junction box. Pierce the sealing plugs on the junction box. Thread cables through the sealing plugs. Note: For RJ45 network interface, use the supplied cable routing tool. ...
- Page 15 Route the Cables through the Junction Box 5. Secure the junction box in the wall/ceiling with screws. Secure the Junction Box 6. Hook the camera to the junction box with the safety rope and connect the cables to the camera.
- Page 16 Hook the Camera to the Junction Box 7. Secure the camera to the junction box with the screws. Secure the Camera 8. Adjust the view angle. 3-axis (pan/tilt/rotation) adjusting allows adjustment for optimum camera rotation and placement. Follow the steps below to adjust the view angle.
- Page 17 Loosen the lock screw using the supplied Allen wrench. Adjust the view angle of the camera. The adjusting range of the panning is from 0° to 360°, the tilting is from 0° to 90° and the rotation is from 0° to 360°. Tighten the lock screw.
-
Page 18: Mounting With A Gang Box
2.2.2 Mounting with a Gang Box Before you start: The gang box is not included in the package. You need to prepare one for this mounting type. Steps: 1. Secure the adapter to a gang box with the screws. 2. Route the cables of the camera. 3. -
Page 19: Setting The Network Camera Over The Lan
3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, contact your dealer or the nearest service center for help. -
Page 20: Activating The Camera
Activation via Web Browser and Activation via Grundig IP-Finder Tool are supported. We will take activation via Grundig IP-Finder Tool and Activation via Web Browser as examples to introduce the camera activation. -
Page 21: Activation Via Grundig Ip-Finder Tool
5. Click OK to save the password and enter the live view interface. 3.2.2 Activation via Grundig IP-Finder Tool The Grundig IP-Finder Tool is used for detecting the online device and activating the camera. Get the Grundig Finder Tool from the supplied disk or the official... - Page 22 User manual for other two activation methods. Steps: 3. Run the Grundig IP-Finder Tool to search the online devices. 4. Check the device status from the device list and select the inactive device.
-
Page 23: Modifying The Ip Address
To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your Use the Grundig IP-Finder Tool to search and change the IP address of the device. We take modifying the IP Address via Grundig IP-Finder as an example to introduce the IP address modification. - Page 24 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address 4. Input the admin password and click Modify to activate your IP address modification.
- Page 25 The batch IP address modification is supported by the Grundig IP- Finder. Please refer to the User Manual of Grundig IP-Finder for details.
-
Page 26: Accessing Via Web Browser
4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:... - Page 27 4. Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug- Note: You may have to close the web browser to finish the installation of the plug-in.
-
Page 28: Initializing The Memory Card
4.1 Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection. - Page 29 QG-GD-CI-AP4637T-2020-03-12-V4-EN ©ABETECHS GMBH, DÜSSELDORF, GERMANY grundig-security.com...
