  • Page 2 Please find the latest version at WWW.GRUNDIG-SECURITY.COM Limitation of Liability / Legal Disclaimer Abetechs GmbH (Grundig Security) undertakes all reasonable efforts to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s...
  • Page 3 OPEN SOURCE SOFTWARE LICENSE INFORMATION The software components provided with Grundig products may contain copyrighted software that is licensed under various open source software licenses. For detailed information about the...
  • Page 4 You may obtain the complete corresponding open source part of a specific product from us for a period of three years after our last shipment of this product by sending an email to: info@grundig-security.com Safety Instruction Make sure that you only use the power adapter that is specified in the specifications sheet of the product.
  • Page 5 Improper use or replacement of the battery may result in the hazard of explosion. Do not use any accessories that are not recommended by GRUNDIG. Do not modify the product in any way. If the product starts to smell or smoke comes out of the device, immediately stop using the product and disconnect it from the power supply to prevent fire or electric shocks.
  • Page 6 Do not expose the sensor of the product to laser beams as this may damage the sensor. If the product supports IR, you need to take some precautions to prevent IR reflection. Do not install the product close to reflective surfaces of objects as this may cause reflection.

  • Page 7: Table Of Contents

    Table of Contents 1 Overview ..................8 1.1 Cable Descriptions ..............8 1.2 Alarm Output................9 2 Installation ..................10 2.1 Installing the Memory Card ............ 10 2.1.1 DE2xxx Series & DE2xxxI Series (IR) PTZ Camera....10 2.1.2 DE3xxx Series PTZ Camera ..........12 2.1.3 DY3xxx Series PTZ Bullet Camera ........
  • Page 8 3.2.2 Activation via SADP Software .......... 43 3.3 Modifying the IP Address ............44 4 Accessing via Web Browser ............47 4.2 Initializing the Memory Card ..........50...

  • Page 9: Overview

    1 Overview 1.1 Cable Descriptions The cable interfaces of network PTZ camera are shown in Figure 1-1. The cables are distinguished by different colors. Refer to the labels attached on the cables for identification. Notes:  The cables vary depending on different camera models. ...

  • Page 10: Alarm Output

    Figure 1-1 Cables of PTZ Camera  Power Cord: Supports 12 VDC power supply.  Video Cable: Connect BNC Cable to test the video output.  Alarm Cable: Connect terminal ALARM-IN with GND interface, and connect terminal ALARM-OUT with ALARM-COM interface. ...

  • Page 11: Installation

    2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Notes:  Do not drag the PTZ camera with its waterproof cables; otherwise the waterproof performance is affected.
  • Page 12 Figure 2-1 DE2xxx Series PTZ Camera Figure 2-2 DE2xxxI Series (IR) PTZ Camera 2. Rotate the cover to a proper position, align the memory card with the memory card slot and insert it. Figure 2-3 Insert the Memory Card...

  • Page 13: De3Xxx Series Ptz Camera

    3. Rotate the cover and push it back. 2.1.2 DE3xxx Series PTZ Camera Steps: 1. Loosen three screws on the bottom of camera to reveal the memory card slot, as shown in Figure 2-4. Figure 2-4 DE3xxx Series PTZ Camera 2.

  • Page 14: De4Axxxi Series (Ir) Ptz Camera

    2.1.4 DE4AxxxI Series (IR) PTZ camera Steps: 1. Remove the four silicone plugs on the decorative rim as shown in Figure 2-5, and you can see four flange screws in the decorative rim. Figure 2-5 Remove the Silicone Plugs 2. Loosen four flange screws with a screwdriver. Remove the bubble and the decorative rim as shown in Figure 2-6.
  • Page 15 3. Open the memory card cover and insert the memory card into the card slot as shown in Figure 2-7 and Figure 2-8. Figure 2-7 For 20× Camera Module Memory Card Slot Memory Card Cover Figure 2-8 For 4× Camera Module 4.

  • Page 16: Installing De2Xxx Series & De2Xxxi Series (Ir) Ptz Camera

    2.2 Installing DE2xxx Series & DE2xxxI Series (IR) PTZ Camera DE2xxx series PTZ camera supports wall mounting, ceiling mounting, and installing with junction box. DE2xxxI Series (IR) PTZ camera supports wall mounting and ceiling mounting. 2.2.1 Wall Mounting Before you start: Make sure the camera is power-off before you install the camera.
  • Page 17 Figure 2-9 Base Plate for DE2xxx Series PTZ Camera OPEN Base Plate on the Bottom of the Dome Front View of Base Plate Figure 2-10 Base Plate for DE2xxxI Series (IR) PTZ Camera 2. Align the cable hole on the base plate with the hole on the bracket for wiring.
  • Page 18 Figure 2-11 For DE2xxx Series PTZ Camera Figure 2-12 For DE2xxxI Series (IR) PTZ Camera 3. Route the cables through the cable hole. 4. Align the PTZ camera with the base plate. Rotate the PTZ camera clockwise to the base plate, and the PTZ camera is secured with the base plate by three locks on the plate.
  • Page 19 Figure 2-13 Secure DE2xxx Series PTZ Camera Figure 2-14 Secure DE2xxxI Series (IR) PTZ Camera 5. Secure the mounting base to the wall with four PA4*25 screws (supplied).

  • Page 20: Ceiling Mounting

    Figure 2-15 Install the Mounting Base 6. Install the PTZ camera to the bracket. 1). Route the cables of the PTZ camera through the wall bracket. 2). Connect the corresponding cables. 3). Hang the bracket together with the PTZ camera on the mounting base.
  • Page 21 Before you start: The ceiling mounting is applicable to the indoor/outdoor solid ceiling construction. The followings are the mandatory precondition for ceiling mounting:  The thickness of the ceiling shall range from 5 mm to 40 mm.  Make sure the ceiling is strong enough to withstand more than four times the weight of the PTZ camera and its accessories.
  • Page 22 Ceiling Mounting without Junction Box Steps: 1. Rotate the base plate counterclockwise to separate it from the PTZ camera, as shown in Figure 2-9 and Figure 2-10. 2. Attach the drill template (supplied) to the place where you want to fix the PTZ camera, and make sure the front arrow appoints to the monitoring area.
  • Page 23 Cable Slot Cover Figure 2-21 For DE2xxxI Series (IR) PTZ Camera 4. Attach the base plate to the ceiling and secure it with the supplied three self-tapping screws by aligning with three screw holes in the ceiling, and the front arrows on the drill template and base plate should be aligned together as well, as shown in Figure 2-22 and Figure 2-23.
  • Page 24 Figure 2-23 For DE2xxxI Series (IR) PTZ Camera 5. Route the cables through the cable hole. 6. Align the PTZ camera with the base plate. Rotate the PTZ camera clockwise into the base plate, and the PTZ camera is secured with the base plate by three locks on the plate.

  • Page 25: Installing With Junction Box

    2.2.3 Installing with Junction Box Notes:  The thickness of the ceiling shall range from 5 mm to 40 mm.  Make sure the ceiling is strong enough to withstand more than four times the weight of the PTZ camera and its accessories. Steps: 1.
  • Page 26 OPEN Base Plate on the Bottom of the Dome Front View of Base Plate Figure 2-26 For DE2xxxI Series (IR) PTZ Camera 2. Attach the drill template (supplied) to the place where you want to fix the PTZ camera, and make sure the front arrow appoints to the monitoring area.
  • Page 27 on the drill template and junction box should be aligned together as well. Figure 2-28 Fix the Junction Box 5. Connect the cables and route the cables clockwise through the hooks and fix the camera and the junction box with three hooks. Tighten it clockwise and loosen it anticlockwise.

  • Page 28: Installing De3Xxx Series Ptz Camera

    2.3 Installing DE3xxx Series PTZ Camera DE3xxx series PTZ camera supports ceiling mounting and in-ceiling mounting. Note: Wall mounting, installation with junction box, and installation with tripod are supported for DE3xxx series PTZ camera. The corresponding accessories shall be purchased separately. 2.3.1 Ceiling Mounting Notes: ...
  • Page 29 Figure 2-30 Attach the Drill Template 3. Insert the expansion screws into the ceiling. (Optional) 4. Insert four PM4*10 screws into the ceiling and fix the base plate, as shown in Figure 2-31. Make sure the FRONT arrow of the base plate is of the same direction as the arrow of the drill template.

  • Page 30: In-Ceiling Mounting

    clockwise into the base plate, and the PTZ camera is secured with the base plate by three locks on the plate. 6. Fix the screws on the side with a screwdriver, as shown in Figure 2-32. ③ ① ② OPEN LOCK Figure 2-32 Fix the Camera 7.
  • Page 31 Figure 2-33 Drill Template 2. Fix the base plate onto the in-ceiling bracket with the four screws in the package (supplied). Make sure that the cable holes of the base plate are aligned to the cable holes of the bracket, as shown in Figure 2-34.
  • Page 32 4. Align the PTZ camera with the base plate. Rotate the PTZ camera clockwise into the base plate, and the PTZ camera is secured with the base plate by three locks on the plate. 5. Fix the screws on the side with a screwdriver, as shown in Figure 2-35.

  • Page 33: Installing Dy3Xxx Series Ptz Bullet Camera

    2.4 Installing DY3xxx Series PTZ Bullet Camera 2.4.1 Dimensions of DY3xxx Series PTZ Bullet Camera Two structures of DY3xxx Series PTZ bullet cameras are available: wall-mounted PTZ bullet camera and base-mounted PTZ bullet camera. Select the proper PTZ bullet camera and the installation method according to its working environment.

  • Page 34: Wall Mounting

    4-φ7 Unit: mm Figure 2-38 Base-mounted PTZ Bullet Camera 2.4.2 Wall Mounting Before you start: The wall-mounted PTZ bullet camera can be installed on cement wall and pole mounting. The installing environment shall meet the following conditions:  For cement wall, you need to use the expansion screw to fix the bracket.
  • Page 35 1. Drill screw holes on the wall according to the dimensions of wall-mounted camera and insert four M6 expansion screws into the screw holes, as shown in Figure 2-39. Figure 2-39 Drill Screw Holes 2. Route the cables through the camera bracket and cover the four hex nuts with flat washers.

  • Page 36: Base Mounting

    2.4.3 Base Mounting Before you start: Base-mounted PTZ bullet camera can be installed on hard plane structures such as cement surface. Note: Make sure that the plane structure is strong enough to withstand more than eight times the weight of the PTZ camera and its accessories.

  • Page 37: Installing De4Axxxi Series (Ir) Ptz Camera

    2.5 Installing DE4AxxxI Series (IR) PTZ Camera DE4AxxxI series (IR) PTZ camera supports ceiling mounting and in-ceiling mounting. Note: Wall mounting, pendant mounting, and installation with junction box are supported for DE4AxxxI series (IR) PTZ camera. The corresponding accessories shall be purchased separately. 2.5.1 Ceiling Mounting Ceiling mounting for DE4AxxxI series (IR) PTZ camera is similar to ceiling mounting for DE2xxx series &...

  • Page 38: In-Ceiling Mounting

    2.5.2 In-ceiling Mounting Notes:  Reserve at least 250 mm of height for in-ceiling mounting.  The thickness of the ceiling shall range from 5 mm to 40 mm.  Make sure the ceiling is strong enough to withstand more than four times the weight of the PTZ camera and its accessories Steps: 1.
  • Page 39 Figure 2-44 Drill Template 3. Align the cable holes of the base plate to the cable holes of the in-ceiling bracket and then fix the base plate onto the bracket with the four screws in the package (supplied), as shown Figure 2-45. Figure 2-45 Fix the Base Plate to In-ceiling Bracket 4.
  • Page 40 Figure 2-46 Fix the Camera 7. Place the camera and the bracket into the hole drilled in step 2, and rotate the screws clockwise to fix the camera. 8. Fix the decorative rim with the bubble and the decorative rim will be attached to the in-ceiling bracket automatically, as shown in Figure 2-47.

  • Page 41: Setting The Ptz Camera Over The Lan

    3 Setting the PTZ Camera over the LAN Notes:  You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, strengthen your own protection. If the product does not work properly, contact with your dealer or the nearest service center.

  • Page 42: Activating The Camera

    Figure 3-2 Connecting via a Switch or a Router 3.2 Activating the Camera Purpose: You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via web browser, activation via SADP, and activation via client software are supported.
  • Page 43 Notes:  The default IP address of the camera is 192.168.1.64.  The computer and the camera should belong to the same subnet.  For the camera enables the DHCP by default, you need to use the SADP software to search the IP address. Figure 3-3 Activation Interface (Web) 3.

  • Page 44: Activation Via Sadp Software

    5. Click OK to activate the camera and enter the live view interface. 3.2.2 Activation via SADP Software SADP software is used for detecting the online device, activating the device, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts.

  • Page 45: Modifying The Ip Address

    STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 46 Use the SADP software or client software to search and change the IP address of the device. We take modifying the IP Address via SADP software as an example to introduce the IP address modification. Note: For IP address modification via client software, refer to the user manual of client software.
  • Page 47 Figure 3-5 Modify the IP Address Note: You can enable the Guarding Vision service for the device during activation. Refer to Chapter Fehler! Verweisquelle konnte nicht gefunden werden. Fehler! Verweisquelle konnte nicht gefunden werden.. 4. Input the admin password and click Modify to activate your IP address modification.

  • Page 48: Accessing Via Web Browser

    4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version/Vista/Win7/Server 2003/Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024 × 768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 5 and above version and Google Chrome 18 and above version Steps:...
  • Page 49 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the network PTZ camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
  • Page 50 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, refer to the user manual of the network camera.

  • Page 51: Initializing The Memory Card

    If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection. QG-GD-CI-AP2647P-2018-01-06-V2-EN ©ABETECHS GMBH, DÜSSELDORF, GERMANY...
