Product Highlights

• Class D, DC coupled amplifiers
• All models can directly drive low impedance or 70/100V loudspeakers
• Intuitive IntelliCloud web interface
• Remote management from anywhere in the world
• Built-in Wi-Fi Hotspot for access without network connectivity
• Internal streaming source supporting Spotify and Apple Airplay
• Four analog balanced line inputs
• Dante™ audio network integrated in 'D' models
• 3 stages of on board 64bit DSP:
User processing DSP facilities:
• Gain, mute and phase inversion
• Delay, up to 250ms (combined with group delay)
• X-over HPF and LPF with 19 filter variations
• 12-band parametric filtering, with choice of 16 filter types including all-pass filters
• RMS and Peak limiter
Speaker processing DSP facilities:
• Delay up to 30ms
• 12-band parametric filtering, with choice of 16 filter types including all-pass filters
• X-over HPF and LPF with 19 filter variations
• FIR filter implementation
• RMS and Peak limiter
Group processing DSP facilities:
• 6 output groups, assignable between multiple amplifiers in the network
• Group delay, up to 250ms (combined with user delay)
• Group gain, mute and phase inversion
• Additional 12-band parametric EQ per group
• Internal Global Preset and Speaker Preset library
• Apex GlidePath technology - our proprietary control loop provides a load
independent frequency response and low harmonic and intermodulation distortion
• Power supply with worldwide operation from 100-240 Vac. Active power factor
correction circuitry ensures efficient use of the mains power system
• Low idle loss (heat) through the use of a proprietary control loop which relaxes the
output stages' dead time
• Daylight viewable colour OLED display
• Slimline 1U chassis
