Apex Digital CloudPower Series Operation Manual page 65

User processing functions per channel
Gain:
Polarity:
Delay:
PEQ:
HP/LP filters:
Limiter:
Group processing functions
Six global processing group overlays which can link any amplifier channel in the network
Gain:
Polarity:
Delay:
PEQ:
Speaker processing functions
Gain:
Polarity:
Delay:
PEQ:
HP/LP filters:
Limiter:
FIR filters:
(1) Filter types:
Circuit protection
Mains and power supply
Power outputs
Cooling
Inputs
Analog
A/D conversion
Input impedance
Max. Input level
Digital
Internal Streaming source
Remote control and monitoring
Network connection
Apex remote control software
Front panel indicators
Daylight viewable colour OLED display
-80 to +15dB, 0,1dB steps
Normal / inverted
0 to 250 ms (Shared between User and Group settings)
12 x PEQ. Each PEQ can be set to a choice of 16 filter types (1)
Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct
Peak voltage, RMS voltage
-80 to +15dB, 0,1dB steps
Normal / inverted
0 to 250 ms (Shared between User and Group settings)
12 x PEQ. Each PEQ can be set to a choice of 16 filter types (1)
-80 to +15dB, 0,1dB steps
Normal / inverted
0 to 250 ms (Shared between User and Group settings)
12 x PEQ. Each PEQ can be set to a choice of 16 filter types (1)
Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct
Peak voltage, RMS voltage
768 taps per channel
Bell-Sym,Bell-Asym, Notch, Low-Shelf 6dB or12dB, High-Shelf 6dB or 12dB
All-Pass 90° or 180°, High-Pass 6dB, or 12dB, High-Pass Vari-Q 12dB,
Low-Pass 6dB or 12dB, Low-Pass Vari-Q 12dB, Band-Pass
Under, over voltage, over current protection
DC, Over-temp, Over-current limiter, VHF
Cooling fans with signal control speed
4 balanced analog line inputs 4x 3-pin Phoenix
32 bit
10k Ohm
21 dBu
4 input Dante (integral in CP354D / CP704D / CP1504D / CP3004D. Retrofit module
available for CP354 / CP704 / CP1504 / CP3004)
Two channel internal streaming source supporting Spotify and AirPlay
Single port Ethernet interface
Web UI with built in web-server
Real time level , limit and fault indicators
Specifications
65
