USER / Gain
The Gain submenu show the master input faders for every channels. This is where you will control the
volume for each amplifier output. Note: the gain values can be offset if the channel is assinged to a
with gain settings other then unity (0.0 dB).
GROUP
You do not have to select a channel, every channel's gain control is visable from the same submenu.
Select the Gain submenu
Adjust the faders to reach the desired output volume.
Be cautious when double-clicking the fader, as it will set it to unity gain and
could potentially result in a high voltage output if an audio source is presented.
It would also be wise to check and set the channel's limiters before applying
high gain levels.
Gain Scale
At 0 dB gain setting, the amplification from the line input to the amplifier output
is 26 dB. At +15 dB, the amplification reaches 41 dB.
36
Polarity inverts the channel's phase by 180°.
IntelliCloud WebUI
