Apex Digital CloudPower Series Operation Manual page 67

Specifications CP716D Specifications CP716D
Operating conditions
Temperature
Storage temperature
Safety / Compliance
Amplification and power supply
Amplification class
Power supply model
Power Factor
Mains Rating
Operating Voltage
AC Mains connector
Max. average power consumption (1/8)
Watts (W)
Amps @ 230V
Amps @ 120V
Audio Specifications
Frequency response
Distortion THD+N
Noise level (20 Hz - 20 kHz @ 8 ohm)
Latency
Phase response
S/N (20 Hz - 20 kHz @ 8 ohm)
Damping factor
Input sensitivity
DSP
Digital Signal Processor
I/O Routing
Dante™ Audio Networking
16 Dante input channels with adjustable gain in the amplifier channel mixer
Supports 48/96kHz Dante networks
Two Gigabit network ports for the Dante network, configurable in switched or redundant mode
Supports AES67
Locate function (from Dante Controller, locate mode can be switched on to make the network port LEDs flash to locate them)
0° to 50° C, 10 to 60 % non-condensing
-20° to 70° C
CE Certificate
Class D GlidePath technology
Universal switch mode power supplies with active PFC
> 0,9 above 1/2 P
100 - 240V @ 50-60 Hz
90 - 260V
Powercon 32A
700W
3,1
5,9
1Hz - 22kHz
0,05% @ P/2 , 20Hz- 20 kHz, 22 kHz BW
< 100 uV (A)
1 mS
±10 deg 3 Hz - 20 kHz
118 dB (A)
4000@8ohm <1Khz
Settable in speaker preset. By default analog in to amplifier output = 26dB
64 bit fixed point
Flexible routing matrix
Specifications
67
