Speaker Preset Creator

The web interface hosts its own Preset Creator software for designing speaker presets.
To access this feature, simply add "/preset.html" after the IP address in the URL.
For instance: http://192.168.0.10/preset.html
Access to this preset creator page can be secured with an OEM code if necessary.
The control interface operates similarly to the
Mute will mute or unmute the amplifier's channel output. This status is not saved within the preset.
Select is used to select the channel to which the connected speaker is allocated while designing a preset.
When a modification is made within any of the submenus, the
led's will turn to a green
ON
You can remove the processing on that element using the
Added capability to incorporate a
FIR filter with 768 taps.
To activate the filter:
• Press the filter icon.
• Locate the file on your computer.
• Confirm to upload.
• Toggle the latch switch to the on
position.
The Delay function is designed for phase alignment and can be adjusted up to 30 milliseconds.
The Gain fader offers additional information regarding the output voltage.
The Limiter functions in the same manner as with the user controls.
and
USER
status indicating processing is active.
The X-Over's Enable Overwrite feature permits users to modify the
crossover frequency of a protected speaker preset using the USER
controls.
The frequency specified here becomes the minimum for the HPF
or the maximum for the LPF, but it can be adjusted in the opposite
direction to attenuate frequencies.
Usage example: The top speaker preset can operate with various
subwoofers. Depending on the specific subwoofer in use,
adjustments can be made to the top speaker's HPF settings.
IntelliCloud WebUI
interfaces, with a few exceptions.
GROUP
ON/OFF
button.
CLEAR
Access and Manage the
preset library.
