A
ALIGN THE TABS AND
INSERT AT THE BOTTOM
C
30
B
GENTLY PUSH THE
BATTERY UPWARDS
THERE WILL BE AN AUDIBLE CLICK AS THE
BATTERY LOCKS ITSELF IN TO PLACE
S T E P 1 4
INSTALL
BATTERY
If you removed your battery from your bike, follow
these steps to install:
Install the battery by inserting the lower tab of the
battery into the tab recess hole on the frame of the
bike at an angle of approximately 45º (A).
Making sure that everything is aligned correctly, simply
hinge the battery upward into position (B). Use gentle
pressure to push it into place, you will hear an audible
click as it locates and locks itself into place (C).
The battery is now locked in position. If you want
to remove the battery you will need to use the key
provided with the battery. See STEP 1 for more
information.
Do not force the battery into the opening, as it can
result in damage to the battery or terminal.
