Icon-Line Moderna series have been approved according to the EN 13240, NS 3058, NS 3059. And the Icon-Line Moderna series are modified so that they are also re- commended as exempt for use within smoke control areas (SCA) throughout the UK (see clean air act Appendix A) of the air supply regulation so that it can`t be closed completely. -
Page 3: Before Installation
It is important that upon receipt check your Heta product completely and report any damage or defects to your dealer. The packaging must be disposed of as follows: Wood is untreated and able to burn in the stove. - Page 4 With your new wood stove you should find the following: Q.C. check Operating / Instruction manual Graphite spray for Heta glove lubrication Nr. 0023-9002 Nr. 0027-0130 Data plate Handle Nr. 6000-027676 8057 0000-DK Heta A/S Jupitervej 22 . DK-7620 Lemvig . Denmark EN 13240:2001/A2:2004 - AEA - NS 3058/3059, Aus §15A...
- Page 5 Before using Installation of the handle for the stove door. Item 1 or 2.
-
Page 6: Operating Instructions
See fig. 2. sition. This ensures the stove and chimney are thoroughly heated. The Icon-Line Moderna series has been safety tested with a load of 2,5 kg of wood. The warranty will be voided if this Closed amount is exceeded. -
Page 7: Emptying The Ash
bottom of the combustion chamber on top of most towards the front of the stove. Place fi- the grate as insulation. rewood equivalent to 1.6 kg on top of the em- bers in one layer, perpendicular to the chamber Be careful when emptying the opening. -
Page 8: Draft Conditions In The Chimney
(soot build-up, bird nests, leaves etc.). ficiency. Heta wood stoves are constructed so reduced draft can occur when: that it itself provides an optimal blend of com- bustion air. -
Page 9: Operating Problems
used to vaporize the water and this will all disap- In the event of smoke or malodorous fumes are pear up the chimney. Thus, it is important to use being produced, you must first check to see dry, well seasoned wood, for eg. wood with a whether the chimney is blocked. -
Page 10: Diagram For Maintenance
Therefore, the duration of the warranty is 5 years on this product, covering manufactu- rer’s defects, 1 year on paint adhesion defects from purchase date from Heta and a 3 months total warranty for seals, vermiculite and glass from the date of sale from the dealer. -
Page 11: Stove Data Table En 13240
* stone top 115 kg. * stone top 113 kg. * stone top 115 kg. The nominal output is the output to which the stove has been tested. Testing is conducted with the combustion air open 44% for Icon-Line Moderna Series. -
Page 12: Troubleshooting
1.19 troubleshooting table - applies to all stove types Fault Cause Troubleshooting Solution Inadequate chimney draft. Lighting problems. When the You can test using a lighter whether Improve the chimney. The chimney only has stove is cold, smoke seeps flame is drawn into the combustion sufficient draft when it is hot. -
Page 13: Cleaning/Replacing Bicks After Chimney Sweeping
1.20 icon-line Moderna series. Cleaning after sweeping or before replacing vermiculite stones Note: it may be necessary to clean/vaccum the holes and air ducts behind the rear stone. Order of removing Fire bricks. Replace in reverse order. Starting with Fig. 6. -
Page 14: Cleaning/Replacing Bicks After Chimney Sweeping Side Windows
1.21 icon-line Moderna series side windows Cleaning after sweeping or before replacing vermiculite stones Note: it may be necessary to clean/vaccum the holes and air ducts behind the rear stone. Order of removing Fire bricks. Replace in reverse order. Starting with Fig. 6. -
Page 15: Parts
1.22 icon-line Moderna series Parts - inside fire chamber 10 12 Pos. Name Qty. 1 0023-026431 Bottom stone - right side 2 0023-026436 Vermiculite, rear, bottom 3 0023-026437 Vermiculite, rear, top 4 0023-026438 Baffle, left 5 0023-026698 Bottom stone - left side... - Page 16 icon-line Moderna side windows Parts - inside fire chamber Pos. Name Qty. 1 0023-026431 Bottom stone - right side 2 0023-026433 Vermiculite right side - front 3 0023-026434 Stone under side windows 4 0023-026435 Vermiculite, rear, right 5 0023-026436 Vermiculite, rear, bottom 6 0023-026437 Vermiculite, rear, top 7 0023-026438...
- Page 17 Parts - Door Pos. Name Qty. 1 0008-0036 M4x6 Hexagon socket head cap screw BN 1206 Black 2 0008-1002 M6x6 Hexagon socket set screw BN30, FZB 3 0008-2304 M4x6 Hexalobular socket pan head screw BN 5687, RF A2 4 0021-026343 Glass 5 0023-3008 Glass gasket ø12 L = 1,7 m 6 0023-3010...
-
Page 18: Installation Instructions
installation instructions Contents Installation instructions ..............19 Distance requirements ..............19 Floor ....................19 Chimney connection ................. 19 Combustion air and ventilation ............20 Stovedrawings/measurments ............. 20-22 Outlet for tensile measurement ............22 Connecting direct air below or behind ..........23 Clearances for installation EN 13 240 .......... -
Page 19: Installation Instructions
11 of this manual. must be sealed with fireproof material and / or beading. Heta A/S stresses that it is of utmost 2.2 floor importance that this is done correctly with very tight joints. -
Page 20: Combustion Air And Ventilation
Ventilation stalled to an outside air supply. The Icon-Line Moderna series (6,6 kW) requires The stove is approved as a room air dependent the additional ventilation, when not connected stove in accordance with EN 13240. All the... - Page 21 Icon-Line Moderna Side windows Series 1007 1046 ø100 137 Center fresh air from bottom Icon-Line Moderna V Series ø225 1046 1007...
-
Page 22: Outlet For Tensile Measurement
Icon-Line Moderna V Side windows Series ø225 1046 1007 2.6 outlet for tensile measurement (Moderna V) 0006-3012 M5 Nipple not 0008-0084 included with the oven. M5x6 Tensile measure- ment must be carried out during normal firing and be at min. 12 PA (0.12 mbar) -
Page 23: Connecting Direct Air Below Or Behind
ø100 mm, the draught in the flue depends on this air for optimal combu- stion. Air intake Heta recommends max. 4 meters of direct air ø100 pipe, with max. 3, 90° bends and a min. of ø100 Flexi pipe... -
Page 24: Clearances For Installation En 13 240
2.8 Clearances for installation en 13 240 Furnitures The dimensions are the minimum dimensions, unless otherwise stated. Combustible material Clearances Oventype Distance from oven to combustible material Stove Rear the stove At the Over Corner Minimum insulated /uninsu- side oven furnitures distance dimensions in mm... -
Page 25: Changing To A Back Flue Outlet
2.9 Changing to a back outlet - Does not apply to the Moderna V series Accessory 0030-2410... -
Page 26: Installation Of Purchased Bottom Door
2.10 installation of purchased bottom door Bottomdoor Nr. 6000-027652 - 0008-026844 - 0010-0315 0008-0058 1013-027278 - 0010-0315 - - 6000-026668 Screw for adjustment - 0008-026669... -
Page 27: Eu Declaration Of Conformity
Certifikat no. 2639 Manufacturer Heta A/S Ecodesign Adress Jupitervej 22, DK 7620 Lemvig EU Declaration of Conformity E-mail heta@heta.dk Website www.heta.dk DoC Icon-Line Moderna 2639-2023 Telephone +45 9663 0600 Product fiche Model identifier Icon-Line Moderna, Moderna Side windows, Icon-Line Moderna V, Moderna V Side windows...
