Appendices
Mic In to Insert Send
Measurement
Input Impedance
Output Impedance
Gain
Gain Matching
Noise Floor (Unweighted)
EIN
Frequency Response
THD+N Ratio
Crosstalk
Maximum Input Level
28
Value
12 kΩ
1.2 kΩ
600Ω
400Ω
70Ω
4.8 dB typical ±0.1dB
11.3 dB typical ±0.1dB
16.6 dB typical ±0.1dB
22.9 dB typical ±0.1dB
28.9 dB typical ±0.1dB
35.3 dB typical ±0.1dB
41.6 dB typical ±0.1dB
47.5 dB typical ±0.1dB
53.3 dB typical ±0.1dB
59.2 dB typical ±0.1dB
65.5 dB typical ±0.1dB
< 0.08 dB
< -97.3 dBu
-130.0 dBu typical, -129.0 dBu nominal
±0.2 dB
< -92 dB / 0.0025%
< -108 dB
< -105 dB
< -81 dB
> 21.5 dBu
Conditions
Green setting
Dim White setting
Orange setting
Red setting
-
5 dB gain
11 dB gain
17 dB gain
23 dB gain
29 dB gain
35 dB gain
41 dB gain
47 dB gain
53 dB gain
59 dB gain
65 dB gain
Any gain setting
gain
17 dB gain, unweighted, 20 Hz - 20kHz,
150R termination
65 dB gain, A-weighted, 20 Hz - 20kHz,
150R termination
20 to 20 kHz, any gain
17 dB gain, 20 dBu out, 1 kHz
Aggressor 15 dBu 50 Hz in, 5 dB gain,
20 dBu out
Adjacent channels 150R terminator, 35
dB gain
Aggressor 15 dBu 1 kHz in, 5 dB gain,
20 dBu out
Adjacent channels 150R terminator, 35
dB gain
Aggressor 15 dBu 10 kHz in, 5 dB gain,
20 dBu out
Adjacent channels 150R terminator, 35
dB gain
Minimum gain
