Super-Analogue™ Outboard
X-Rack Mic Amp User's Guide
This documentation package contains the User's Guide for your new X-Rack Mic Amp
module. Depending on the age of your X-Rack, these pages may already be present in
your X-Rack Owner's Manual – please check to see if these pages match your Manual.
If they do not, these pages should be filed alongside it.
Please Note. X-Rack units prior to serial number XRK0110 are not 100% compatible with the X-Rack Mic
Amp as these units can not provide +48V phantom power unless field retrofit kit 629620XR
has been fitted. This kit is available free-of-charge from your local distributor, if the X-Rack unit
concerned is in warranty. For units that are out of warranty a small charge will be made. The
absence of this kit is indicated by the buscard in the X-Rack being a '629620X1 RE 1' (rev 1),
with a number of components (ie. 'IC2', 'C4', 'L4') missing.
For correct operation of Total Recall™, your X-Rack unit must be running V1.1/0 or later
software. Please refer to your X-Rack Owners Manual for instructions on how to check the
current software version and how to obtain and install a newer version if required.
There may be a newer version of the X-Rack Owner's Manual available for download from our
website (
http://www.solid-state-logic.com
)
82S6XR0A0B
Advertisement
Table of Contents
Related Manuals for Solid State Logic 82S6XR0A0B
Summary of Contents for Solid State Logic 82S6XR0A0B
- Page 1 Solid State Logic S O U N D V I S I O N SUPERANALOGUE X - R A C K Super-Analogue™ Outboard X-Rack Mic Amp User’s Guide This documentation package contains the User’s Guide for your new X-Rack Mic Amp module.
-
Page 3: Operation
A. The Mic Amp Module A.1 Connection The rear panel of the module carries the Mic (‘IN’) and Line input (‘LINE’) XLRs along with a single output (‘OUT’) XLR. The Line input and output operate at a nominal level of +4dBu although the gain of the Line input can be varied by a front panel control. - Page 4 X-Rack Owner’s Manual A.2.3 HF/LF Section This section contains simple high and low pass filters as follows: HF (Low Pass): LF (High Pass): The two filters can be switched into circuit independently. A.2.4 OUTPUT Section This small section contains a tri-colour signal present indicator and two routing switches (‘REC L’...
-
Page 5: Performance Specification
The following pages contain audio performance specification figures for the X-Rack Mic Amp module. No other Solid State Logic products are covered by this document and the performance of other Solid State Logic products can not be inferred from the data contained herein. - Page 6 X-Rack Owner’s Manual A.2.4 Instrument Input Performance Un-balanced signal applied to Instrument Input and measured at Output. Pad switched out and Input Gain control set to +12dB (minimum). Gain Input Impedance Output Headroom THD + Noise (-18dBu applied, +28dB gain) Frequency Response Equivalent Input Noise (Input terminated with 150Ω)
-
Page 7: Calibration Information
A.4 Calibration Information The X-Rack Mic Amp module is factory calibrated and should only need calibration if a potentiometer or other component has been replaced or if it is suspected that there is a problem with calibration. In each of the following instructions it is assumed that the lid of the X-Rack has been removed and that power has been applied. -
Page 8: Audio Output
X-Rack Owner’s Manual A.5 Connector Details Audio Input Location: Rear Panel Conn' Type: XLR Female Description Chassis Audio +ve Audio -ve Instrument Input Location: Front Panel Conn' Type: Mono 1/4" Jack Socket Description Guitar Input Sleeve Chassis A.6 Physical Specification * Depth: Height: Width:...
