Super Analogue Mic Amp
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 82S6XL020E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Solid State Logic 82S6XL020E

Summary of Contents for Solid State Logic 82S6XL020E

  • Page 1 Super Analogue Mic Amp Owner’s Manual...
  • Page 3 Solid State Logic S U P E R A N A L O G U E M I C A M P Super-Analogue™ Outboard Owner’s Manual 82S6XL020E...
  • Page 4 Revision 0D, June 2004 Revision 0E, July 2004 Minor changes, November 2004 Minor changes, June 2005 As research and development is a continual process, Solid State Logic reserves the right to change the features and specifications described herein without notice or obligation E&OE...

  • Page 5: Table Of Contents

    Contents 1.0 Introduction 2.0 Safety Considerations Safety Warnings 3.0 Installation Setting the mains voltage selector Mounting Standalone Operation Connecting to XL 9000 consoles Connecting to XLogic Remote Control unit Configuring the unit 4.0 Operation Appendices: Internal Links and Fuses Test Mode Connector Details Electronic Specification Calibration Information...
  • Page 6 XLogic Mic Amp Owner’s Manual Page 2...

  • Page 7: Introduction

    In the event of a fault during the warranty period the unit must be returned to your local distributor who will arrange for it to be shipped to Solid State Logic for repair. All units should be shipped to Solid State Logic in their original packaging.

  • Page 8: Safety Considerations

    Safety Earth Connection Any mains powered item of Solid State Logic equipment that is supplied with a 3-core mains lead (whether connectorised or not) should always have the earth wire connected to the mains supply ground. This is the safety earth and grounds the exposed metal parts of the racks and cases and should not be removed for any reason.
  • Page 9 Mains Supply and Phases Solid State Logic equipment is designed for connection to single phase supplies with the Neutral conductor at earth potential - category TN - and is fitted with a protective fuse in the Live conductor only. It is not designed for use with Phase (Live) and Neutral connections reversed or where the Neutral conductor is not at earth potential (TT or IT supplies).
  • Page 10 XLogic Mic Amp Owner’s Manual 1 2 0 100V Setting (Use for 90-105V) (Use for 105-125V) These diagrams show the PCB arrangements for the different voltage settings. Note that where the mains voltage is a nominal 230V, the ‘240V Setting’ should be used – not the ‘230V Setting’! Page 6 Mains Input Module 2 3 0...

  • Page 11: Installation

    3.0 Installation Voltage Selection Before connecting the mains supply ensure that the voltage range selector next to the IEC socket on the rear of the unit is correctly set. The input setting must be confirmed before applying power. The input module can be configured to be one of 4 voltage settings.

  • Page 12: Console Wiring Diagram

    XLogic Mic Amp Owner’s Manual Console Wiring Diagram Page 8...

  • Page 13: Connecting To Xl 9000 Consoles

    Mic Amp unit. If the console if wired with DL connectors then a DL to 25 way ‘D’ type male adaptor cable will be required. Interconnecting cables may be ordered from Solid State Logic or supplied by the facility. See the block diagrams opposite. Appendix B contains pinouts for all connectors. Appendix B also includes wiring information to build an adaptor cable to connect the audio and control DLs to 25 way ‘D’...
  • Page 14 XLogic Mic Amp Owner’s Manual Remote Control Wiring Diagram Page 10...

  • Page 15: Connecting To Xlogic Remote Control Unit

    5 network cable(s) with a minimum conductor size of 26AWG. Use of 24AWG cable allows the cable to be extended to a maximum of 200 metres. To ensure compliance with EU EMC regulations Solid State Logic recommend fitting a ferrite bead close to each end of the cable.
  • Page 16 XLogic Mic Amp Owner’s Manual Table 1: Channel Display Setting - Normal Operation Channel Address * Position Note: 'DP' - decimal point * Pull address pins marked '1' to 0V to enable. Page 12 BCD Switch Setting Display 1 Display 2 Front Panel Displays Display 3 Display 4...

  • Page 17: Configuring The Unit

    Configuring the XLogic Mic Amp There are a number of internal link settings, most of which should not normally require adjustment – see Appendix A for a full listing. Those links that change the operation of the unit are described below. Setting the Channel Displays If the unit is connected to an XL 9000 console the 5 address bits on the 25 way ‘D’...
  • Page 18 XLogic Mic Amp Owner’s Manual Stereo Jack Page 14 PIC Controller Channel 1 +48V PHANTOM POWER TRIM Ø +48V +18 — +78dB -20dB Hi-Z PIC Controller Channel 2 +48V PHANTOM POWER TRIM Ø +18 — +78dB +48V -20dB Hi-Z PIC Controller Channel 3 +48V PHANTOM...

  • Page 19: Operation

    The XLogic Mic Amp is a 1U rack mounting unit containing four ultra high quality microphone amplifiers, utilising Solid State Logic’s Super Analogue technology. The unit can be controlled locally, from the XLogic Mic Amp Remote unit or from an XL 9000 console, allowing the mic amp to be placed close the microphone in order to eliminate the signal degradation caused by long mic cables.
  • Page 20 XLogic Mic Amp Owner’s Manual Table 2: Channel Displays (Test Mode) Channel LK5 (bit 5) Address * Position Note: 'DP' – decimal point * – Ignored in Test Mode – No entry means display is blank – See right for segment display drawing Page 16 BCD Switch Setting...

  • Page 21: Appendix A - Internal Links And Fuses

    Appendix A – Internal links and fuses Fuses (Mains Inlet) The mains inlet contains a single 1 amp 1.25" time delay fuse (SSL Part No. 35FJJ310). To change it disconnect the mains inlet, then using a small screwdriver prise open the mains selector cover. This contains the fuse. Test and replace with the same type and value if necessary.

  • Page 22: Appendix B: Connector Pinouts

    XLogic Mic Amp Owner’s Manual Appendix B: Connector Pinouts Mic Input Location: Front Panel Conn' Type: XLR Female Description Chassis Audio +ve Audio -ve Audio/Control Location: Connector Type: ID Bit 1 ID Bit 2 ID Bit 3 ID Bit 4 ID Bit 5 * Linking the appropriate pins to 0V will set the channel displays.

  • Page 23: Headphone Output

    Appendix B: Connector Pinouts (continued) Headphone Output Location: Conn' Type: Sleeve Monitor In / Monitor Out Location: Conn' Type: Remote 1 - 2 Location: Rear Panel Conn' Type: 8-way RJ45 Socket Description Ch 2 Switch Control Ch 2 Gain Control Ch 1 Switch Control Ch 2 Overload Ch 1 Overload...
  • Page 24 XLogic Mic Amp Owner’s Manual Appendix B: Connector Pinouts (continued) Table 3a - XL 9000 DL to 25way ‘D’ Wiring: Channels 1-8 / 25-32 / 49-56 / 73-80 Signal Channel 1 Positive Channel 1 Negative Channel 1 Screen Channel 2 Positive Channel 2 Negative Channel 2 Screen Channel 3 Positive...
  • Page 25 Appendix B: Connector Pinouts (continued) Table 3b - XL 9000 DL to 25way ‘D’ Wiring: Channels 9-16 / 33-40 / 57-64 / 81-88 Signal Channel 9 Positive Channel 9 Negative Channel 9 Screen Channel 10 Positive Channel 10 Negative Channel 10 Screen Channel 11 Positive Channel 11 Negative Channel 11 Screen...
  • Page 26 XLogic Mic Amp Owner’s Manual Appendix B: Connector Pinouts (continued) Table 3c - XL 9000 DL to 25way ‘D’ Wiring: Channels 17-24 / 41-48 / 65-72 / 89-96 Signal Channel 17 Positive Channel 17 Negative Channel 17 Screen Channel 18 Positive Channel 18 Negative Channel 18 Screen Channel 19 Positive...
  • Page 27 Appendix B: Connector Pinouts (continued) Table 4 - Channel Address Bit Linking Channel Channels 1-4 connect pin 11 Channels 5-8 connect pin 24 Channels 9-16 connect pins 11, 24 Channels 13-16 connect pin 12 Channels 17-20 connect pins 11, 12 Channels 21-24 connect pins 12, 24 Channels 25-28...

  • Page 28: Appendix C - Performance Specification

    XLogic Mic Amp Owner’s Manual Appendix C – Performance Specification Conditions: Source impedance 150Ω unless otherwise stated. All measurements are RMS and are made using a 22Hz to 22kHz filter unless otherwise stated. General Gain: Input Impedance: Noise Input terminated with 150Ω Equivalent input noise: Gain 70dB...
  • Page 29 THD + Noise In all cases THD is essentially unmeasurable, being less than the inherent noise of the amplifier until the output level exceeds +20dBu. Note: All THD+N measurements at gains above +30dB made using 40dB resistive pad to minimise effect of generator noise at low signal levels.

  • Page 30: Microphone Input

    XLogic Mic Amp Owner’s Manual Appendix D – Calibration Information The XLogic Mic Amp is factory calibrated and should only need calibration if a potentiometer or other component has been replaced or if it is suspected that there is a problem with calibration. In all of the following instructions it is assumed that the top cover has been removed and that power has been applied.

  • Page 31: Appendix E - Physical Specification

    Appendix E – Physical Specification * Depth: Height: Width: Weight: Power: Boxed size: Boxed weight: * All weights and dimensions are approximate Appendix F – Environmental Specifcation Temperature Operating: Non-operating: Max. Gradient: Relative Humidity Operating: Non-operating: Max. wet bulb: Vibration Operating: Non-operating, power off: Shock...
  • Page 32 XLogic Mic Amp Owner’s Manual Page 28...
