Bauer 22201E-B Owner's Manual & Safety Instructions
  1. Manuals
  2. Brands
  3. Bauer Manuals
  4. Power Tool
  5. 22201E-B
  6. Owner's manual & safety instructions

Bauer 22201E-B Owner's Manual & Safety Instructions

5-speed 10" drill press
Hide thumbs Also See for 22201E-B:

Advertisement

Quick Links

Download this manual
Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2022 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
22k

Advertisement

loading

Related Manuals for Bauer 22201E-B

Summary of Contents for Bauer 22201E-B

  • Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.

  • Page 2: Table Of Contents

    Table of contents Important Safety Information ...... 2 Maintenance and Servicing ....... 12 Specifications ..........5 Parts List and Diagram ......14 Setup - Before Use ........5 Warranty ............ 16 Operating Instructions ........ 9 WARNING SyMBOLS AND DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 3 General Tool Safety Warnings (continued) 10. WEAR PROPER APPAREL. Do not wear 17. USE RECOMMENDED ACCESSORIES. loose clothing, gloves, neckties, rings, bracelets, Consult the owner’s manual for recommended or other jewelry which may get caught in moving accessories. The use of improper accessories parts.
  • Page 4 110-120 VAc Grounded Tools: Tools with Three prong plugs (cont.) 7. This tool is intended for use on a circuit that has an outlet that looks like the one illustrated above in 125 VAc 3-prong plug and Outlet. The tool has a grounding plug that looks like the plug illustrated above in 125 VAc 3-prong plug and Outlet.

  • Page 5: Specifications

    Vibration Safety This tool vibrates during use. Repeated or 2. Do not smoke during use. Nicotine reduces long-term exposure to vibration may cause the blood supply to the hands and fingers, temporary or permanent physical injury, increasing the risk of vibration-related injury. particularly to the hands, arms and shoulders.
  • Page 6 Setup - Before Use (continued) Assembly column to Base 1. Loosen Set Screw (9) in Rack Collar (78) and column (101) remove Rack Collar and Gear Rack (92) from the Column (101). The Gear Rack is stowed Bolt (102) in this position only for transit purposes. 2.
  • Page 7 4. While holding Gear Rack and Table Rack Set Screw (9) Support as assembled, slide both down collar (78) onto the Column until Gear Rack bottom is positioned against Column Base. 5. Replace Rack Collar, beveled side down, onto Lift Column and top of Gear Rack.
  • Page 8 Feed Handles/Bars Feed Bar 1. Thread the Feed Handle Bars (27) into the Seat (44) Feed Bar Seat (44) and tighten them. 2. Thread the Feed Handle Knobs (26) onto the Feed Handle Bars and tighten them. Feed Handle Feed Handle Bar (27) Knob (26) Installing/Removing the chuck...

  • Page 9: Operating Instructions

    Operating Instructions Read the ENTIRE IMpORTANT SAFETy INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Tool Set Up TO pREVENT SERIOUS INJURy FROM AccIDENTAL OpERATION: Turn the power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section.
  • Page 10 changing Drill Speed Before changing drill speeds, make sure the 3. Consult the chart below and position the machine is switched OFF and UNPLUGGED. V-Belt on the Pulleys (2, 17) according to the desired drill speed. 1. Open the Pulley Cover. 4.
  • Page 11 Workpiece and Work Area Set Up 1. Designate a work area that is clean and well-lit. 9. FOR FLAT WORK, lay the piece on to a The work area must not allow access by children wooden base and clamp it down firmly against or pets to prevent distraction and injury.

  • Page 12: Maintenance And Servicing

    Maintenance and Servicing procedures not specifically explained in this manual must be performed only by a qualified technician. TO pREVENT SERIOUS INJURy FROM AccIDENTAL OpERATION: Turn the power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section.
  • Page 13 Troubleshooting problem possible causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads.

  • Page 14: Parts List And Diagram

    parts List and Diagram pLEASE READ THE FOLLOWING cAREFULLy THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
  • Page 15 Assembly Diagram Item 58782 For technical questions, please call 1-888-866-5797. Page 15...

  • Page 16: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.

This manual is also suitable for:

58782
