PEERLESS PLA 50-S Installation And Assembly Manual

Articulating swivel arm for 32" - 50" plasma screens

Advertisement

Quick Links

Installation and Assembly
- Articulating Swivel Arm for 32" - 50"
Models: PLA 50, PLA 50-S
Plasma Screens
Maximum Load Capacity: 150 lb (68 kg)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLA 50-S and is the answer not in the manual?

Questions and answers

Summary of Contents for PEERLESS PLA 50-S

  • Page 1 Installation and Assembly - Articulating Swivel Arm for 32" - 50" Models: PLA 50, PLA 50-S Plasma Screens Maximum Load Capacity: 150 lb (68 kg)
  • Page 2: Wall Construction

    Read instruction sheet before you start installation and assembly. WARNING • Do not begin to install your Peerless product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please call Peerless customer care at 1-800-729-0307.
  • Page 3: Parts List

    Before you start make sure all parts listed are included with Parts List your product. MODEL MODEL PLA 50 PLA 50-S DESCRIPTION QTY. PART # PART # A wall plate 201-1095 201-4095 B tilt-roll assembly 201-1093 201-4093 C arm assembly...
  • Page 4: Installation To Wood Stud Wall

    Installation to Wood Stud Wall WARNING • Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached hardware and components. • Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the screws, greatly reducing their holding power.
  • Page 5 Installation to Concrete Wall WARNING • Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor. • Make sure that the supporting surface will safely support the combined load of the equipment and all attached hard- ware and components.
  • Page 6 WARNING • If you are uncertain that product is properly installed, call customer care. Note: There are five mounting positions. The center position is shown (right). Slide washer (J) over wall support arm axle (D). Next, insert plastic cap (N) into axle. Then, insert holding pin (M) into axle.
  • Page 7 Attach two pieces of vinyl trim (E) to wall plate (A). Next, attach one piece of vinyl trim to bottom of swivel box on arm assembly (C). Insert one finishing cap (L) into each unused hole of wall plate (A). SWIVEL BOX Note: Refer to adapter bracket instruction sheet for attachment of adapter bracket to plasma before proceeding with step 5.
  • Page 8 WARNING • Use an assistant or mechanical lifting equipment to safely lift and position the plasma TV. Insert two M10 screws (F) into swivel box on arm assembly (C) as shown. Leave approx. 1/4" of exposed thread. SWIVEL BOX .25" Hook tilt-roll assembly (B) onto M10 screws (F).
  • Page 9 Depending on the specific size & weight of the plasma, articulating swing arm may be angled at different positions, causing plasma to appear to lean sideways at different articulating positions. Tilt-roll assembly (B) allows plasma to be manually adjusted, so plasma can be horizontal at all positions. To adjust, gently rotate plasma by hand to desired position.

This manual is also suitable for:

Pla 50
