PEERLESS PLCM-UNL Technical Data Sheet

TECHNICAL DATA SHEET -
The Straight Column Ceiling Mount offers a straight column from the
ceiling attachment point to the flat panel screen. The straight column
ceiling mount is ideal for sports facilities, airports, lobbies or retail
environments.

Features:

• PLCM-UNL models include a PLP-UNL adapter plate (landscape
only)
• 0° to 20° adjustable tilt and 360° swivel
• Screen mounts horizontally
• Uses standard 1 1/2" – 11.5 NPT schedule 40 pipe
• Additional length can be added for lowering
• Theft-resistant security fasteners secure the screen to the mount
• Sold without ceiling plate
• Complete detailed installation instructions for wood and concrete
structures

Accessories:

• Ceiling Plate required (sold separately). Various options available.
Other ceiling accessories can be ordered separately to allow
mounting to I-beams, cathedral ceilings, trusses, etc.

Dimensions:

Weight:

23.1 lb (10.5 kg)

Shipping weight:

30.3 lb (13.7 kg)

Maximum Load Capacity:

200 lb (90.7 kg)

Shipping Carton dimensions:

L = 38.0625" (967 mm)
W = 12" (305 mm)
H = 8.125" (206 mm)
The Straight Column Flat Panel Ceiling Mount shall be a Peerless model PLCM-UNL and shall be mounted where indicated on the plans. It shall be
constructed of heavy gauge cold rolled steel, steel tubing and finished with scratch resistant Black Fused Epoxy. It shall feature 360° swivel and 0°
to 20° range of tilt. Assembly and installation shall be done according to instructions provided by the manufacturer.
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax 708-865-2941
www.peerlessmounts.com
Straight Column Flat Panel Ceiling Mount
for 32" to 60" LCD And Flat Panel Screens
MODEL: PLCM-UNL
A R C H I T E C T S S P E C I F I C A T I O N S
All other brand and product names are trademarks or registered trademarks of their respective owners.
ISSUED: 07-31-06 SHEET NO: 200-9831-3 07-08-09
© 2008, Peerless Industries, Inc. All rights reserved.
page 1 of 3
