System Layout - Code Alarm PROFESSIONAL Series Installation Manual

86
2020 Voxx Electronics Corporation. All rights reserved.
( - )
( + )
STARTER INTERUPT RELAY
87 ORANGE
YELLOW
87a
WHITE
85
RED
OPEN
30
LED PORT
BLUE
GREEN
WHITE/RED
WHITE
BLACK
BROWN
RED
HORN / SIREN OUTPUT POLARITY JUMPER
DBI PORT
# 1024389
PROGRAMMING / VALET PORT
PURPLE
BLUE
GREEN
YELLOW
ORANGE
RED/WHITE
#1031123
86 - ARMED OUTPUT ( - )
85 - IGNITION ( + )
87A - STARTER OUTPUT - MOTOR SIDE
30 - STARTER INPUT - KEY SIDE
87 - OPEN
UNLOCK OUTPUT ( - )
LOCK OUTPUT ( - )
PARKING LIGHT INPUT
PARKING LIGHT OUTPUT
GROUND
HORN / SIREN OUTPUT
BATTERY 12V ( + )
DOOR TRIGGER INPUT ( + )
TRUNK PIN INPUT ( - )
DOOR TRIGGER INPUT ( - )
IGNITION INPUT ( + )
ARMED OUTPUT ( - )
TRUNK RELEASE OUTPUT ( - )
23
