Designator QTY Value
C2, C13, C24, C43 0 100 µF
C3, C4, C14, C15, C25, C26, 0 47 µF
C34, C35
C5, C16, C27, C36 0 100 µF
C6, C11, C17, C22, C28, C33, 0
C37, C42
D1, D2 0 100 V
FID1, FID2, FID3 0
H1, H2, H3, H4, H13, H14, H15, 0
H16, H21, H22, H23, H24, H29,
H30, H31, H32
H5, H6, H7, H8, H17, H18, H19, 0
H20, H25, H26, H27, H28, H33,
H34, H35, H36
J4, J5, J15, J16, J23, J24, J34, 0
J35
J10, J29 0
J20, J39 0
R2, R4, R26 0 10.0 kΩ
R5, R6, R8, R9, R10, R11, R12, 0
R13, R14, R15, R16, R17, R18,
R19, R20, R21, R22, R23
U1 0
U2 0
U3 0
U4 0
SBVU065 – May 2020
Submit Documentation Feedback
Table 1. MLTLDO2EVM-037 BOM
Description
CAP, AL, 100 µF, 100 V, ±20%, 0.17 ohm,
AEC-Q200 Grade 2, SMD
CAP, TA, 47 µF, 50 V, ±10%, 0.24 ohm,
SMD
CAP, AL, 100 µF, 35 V, ±20%, 0.2 ohm,
AEC-Q200 Grade 1, SMD
1 µF CAP, CERM, 1 µF, 250 V, ±10%, X7R, 2220
Diode, Switching, 100 V, 0.15 A, SOD-123FL
Fiducial mark. There is nothing to buy or
mount.
Machine Screw, Round, #4-40 x 1/4, Nylon,
Philips panhead
Standoff, Hex, 0.5"L #4-40 Nylon
SMA Straight Jack, Gold, 50 Ohm, TH
Header, 2.54 mm, 3 × 2, Gold, TH
Header, 2.54 mm, 5 × 2, Gold, TH
RES, 10.0 k, 1%, 0.125 W, AEC-Q200 Grade
0, 0805
0 RES, 0, 1%, 0.5 W, 0805
Most LDOs in the DCY package
Most LDOs in the DRV package
Most LDOs in the DQN package
Most LDOs in the SOT-23 package
Copyright © 2020, Texas Instruments Incorporated
(1) (2) (3) (4)
(continued)
Package Reference Part Number
SMT Radial J16 EEV-FK2A101M
6.2 × 6 mm 597D476X9050Z2T
D8 × L10.2 mm EEE-TC1V101P
2220 GRM55DR72E105KW01L
SOD-123FL 1N4148WFL-G3-08
N/A N/A
Screw NY PMS 440 0025 PH
Standoff 1902C
SMA Straight Jack, TH 901-144-8RFX
Header, 2.54 mm, 3 × 61300621121
2, TH
Header, 2.54 mm, 5 × 61301021121
2, TH
0805 CRCW080510K0FKEA
0805 5106
DCY0004A
SOIC8
KVU0003A
KVU0005A
Bill of Materials
Manufacturer Alternate Alternate
Part Number Manufacturer
Panasonic
Vishay-Sprague
Panasonic
MuRata
Vishay-
Semiconductor
N/A
B&F Fastener
Supply
Keystone
Amphenol RF
Wurth Elektronik
Wurth Elektronik
Vishay-Dale
Keystone
Texas Instruments
Texas Instruments
Texas Instruments
Texas Instruments
MLTLDO2EVM-037 Evaluation Module
