1. INTRODUCTION
1.1 PRODUCT DESCRIPTION &
INTENDED USE
Thank you for choosing a NewMotion Electric Vehicle
(EV) Charge Point.
This charge point is intended to charge the batteries within
EVs compatible with IEC-61851 MODE3 definition and
requirements. Dedicated EV specific plugs will need to be
utilised. No adaptors, conversion adaptors or extension
sets for cables are allowed to be used. EVs and cables
used with this charge point should always be undamaged
and in their original state.
This charge point is M&E-compliant, a Secured Mess
& Eichrecht Device (SMED) is build upon the existing
energy meter inside the charger. All legal relevant data
from each transaction is stored inside this device. It's
possible for users to read and access live- and historical
data on the LED display screen.
1.2 SAFETY WARNING + CAUTION!
The electrical system must be voltage-free during the
entire installation procedure. Failing to do so can lead to
serious injury or even death. The installation procedure
must be carried out by a trained electrician who works in
accordance with all relevant local laws and regulations.
Do not install in potentially explosive atmospheres and/
or zones with high electromagnetic radiation and/or in
flood-prone areas.
The charge point is connected to the electricity grid
and even if the equipment is switched off, hazardous
voltages may be present at the input terminals. Always
switch off the AC supply before starting any work on
the charge point and/or its installation. Do not carry out
any work in rainy conditions or when the humidity is
above 95%. The safety guidelines are intended to ensure
correct installation and usage. Any failure to comply with
the valid safety guidelines or instructions provided in this
manual may result in fire, electrocution or severe injury.
The charge point is a product in Safety Class I and is
supplied with an earth terminal for protection purposes.
The AC input clamps must be fitted with an uninterruptible
earth for protection purposes. Ensure that the connection
cables are fitted with fuses and circuit breakers. Never
replace a protection component with another type. First
check the full installation to determine if that component
INSTALLATIEHANDLEIDING – P4
INSTRUCTION MANUAL – P4 | P4
can be used with the existing installation components.
Before you switch on the charge point, check that
the available power source matches the configuration
settings of the product, as described in this manual.
Tripping of the RCD could be caused by an earth fault
or a defect relay. If, after resetting the RCD, the device
cannot be activated or immediately trips again; please
contact NewMotion or your installer.
1.3 LEGAL DISCLAIMER
This manual is created for you with care.
We however do not guarantee that all information is
complete, accurate and correct.
If you find any unclarities or mistakes in this installation
manual, or if you have any feedback or suggestions in
general about this manual, please inform us at
installationmanualfeedback@newmotion.com and men-
tion the document version in the subject.
Please check our website
the latest version of this manual.
We strongly advise you to have our product installed
by certified professionals. How our product should be
installed and used depends on local circumstances and
local and national regulation, which are not mentioned
in our manual. NewMotion is not responsible for any
loss or damage whatsoever caused – including without
limitation, any indirect, personal or consequential loss or
damage - arising from or in connection with the use of
this manual. Nor does NewMotion accept any liability for
any such loss or damage arising out of your reliance on
any information contained in this manual.
VERSION 0129NM02INT01
095NM21INT02
