7.1. Target Board Shorting Blocks: Factory Defaults
The C8051F912 Target Board comes from the factory with pre-installed shorting blocks on many headers. Figure 9
shows the positions of the factory default shorting blocks.
P1
14
Downloaded from Elcodis.com electronic components distributor
R15
J16
P1.4
J15
TOUCH SENSE SWITCH
GND
P1.0
PORT1
J3
J6 VDD/DC+
J5
H1
Pin 1
Figure 9. C8051F912 Target Board Shorting Blocks: Factory Defaults
