5.10.2

Connecting the Metrohm Suppressor Module (MSM)

930 Compact IC Flex SeS (2.930.1400)
Inserting large rotors
6.2835.010
Inserting small rotors
You need the adapter (6.2842.020) in order to insert a small rotor into the
suppressor drive.
The 3 entries and exits of the suppressor units, numbered 1, 2 and 3 on
the connecting piece, each have 2 permanently installed PTFE capillaries.
6.2842.000
6.2842.200
5 Installation
4 mm
23
￭￭￭￭￭￭￭￭
