protech prox PA-A901 Quick Reference Manual

PA-A901
Quick
Reference
Guide

Specifications

CPU Support
Core Logic
System
Memory
Network Gigabit 10/100/1000 Base-T Fast Ethernet
Power Supply
BIOS
System Weight
Dimensions (WxHxD)
O.S. Support
Storage
HDD
USB
Serial Ports
LAN
I/O Ports
VGA
Cash Drawer
DC-In
Customer Display
Printer
Add-Ons
MSR & iButton JIS I or II, ISO Track1+2+3 (PS/2 interface)
Fingerprint
2nd Display
LCD
Resolution
Display
Brightness
Touchscreen
Tilt Angle
EMC & Safety
Operating Temp.
Environment
Storage Temp.
Humidity
All Rights Reserved. Copyright 2019
PA-A901
7th Gen. Skylake 6th Gen. Kabylake
® ®
Intel Core™ i5-7500T
Intel Core™ i5-6500
®
®
Intel Core™ i3-7101E Intel Core™ i3-6100
®
Intel Core™ i3-7101TE ® ®
Intel Celeron G3900
® ® ® ®
Intel Pentium G4560
Intel Pentium G4400
® ®
Intel Celeron G3930TE
Intel ® H110 Chipset
1 x DDR4 SO-DIMM (1 slot, up to 8GB)
120 ~150 watt power adapter
AMI SPI BIOS, 8Mbits with VGA BIOS
With power adapter approx. 5 kg
372 x 169 x 315mm
Windows 10 / Windows 7 Pro / POS Ready 7 / WES 7
* 7th Gen. processor supports Win 10 only.
1 x 2.5" HDD or SSD
Rear: 2 x USB 2.0 / 2 x USB 3.0 / Side: 1 x USB 2.0
1 x RJ45 + 2 x DB9 (all support +5V/+12V selectable)
1 x RJ-45
1 x DB-15 VGA Interface
1 + 1 (option, with Y cable) x RJ11 (+12V/+24V selectable)
1 x 4 pin DC Power Jack
VFD, 20 columns and 2 lines, each column is 16 x 16 dots
2" or 3" easy loading thermal printer with Auto-cutter
8-bit grayscale reader
7" TFT LCD, resolution: 1024x600, brightness: 220 cd/m²
15.6" TFT LCD
1366 x 768
220 cd/m²
15.6" P-CAP touch panel, USB interface
40 degrees
CE / FCC
0°C ~ 35°C (32°F ~ 95°F)
-5°C ~ 60°C (23°F ~ 140°F)
20% ~ 90%

Packing Checklist

If you discover any item below are damaged or
lost, please contact your vendor immediately.
PA-A901
This Quick Reference Guide
AC Power Adaptor
COM Port to RJ45 Cable (L =150mm)
Manual/Driver CD
Ver. Q1

System View

Front View
iButton
Left Side View
Top View
Printer
Paper Out Fingerprint
419
Rear View
2nd Display
372
(optional)
Line
Out USB3/4 USB1/2
MSR
Right Side View
314
Power Button
I/O View
RFID
LAN
Line Out
eSATA
CD-2 eSATA
Line
Out USB3/4 USB1/2
USB 3.0 USB 2.0
Cash Drawer 2
(optional)
PA-A901
x1
x1
x1
x1
x1
PA-A901
Unit: mm
Barcode
Printer Scanner
VGA CD-1 COM1 DC-In
I/O Ports
USB 2.0
COM2 COM3
LAN COM2 COM3
VGA CD-1 COM1 DC-In
DC-In
VGA
COM1
Cash
Drawer 1
