  • Page 1 USER MANUAL PA-J670 15" Fanless Slim POS Terminal PA-J670 M2...
  • Page 2 CE NOTICE This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Page: ii PA-J670 SERIES USER MANUAL...
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    VGA Port (VGA) ..............2-10 2.5.4 COM Port (COM1, COM2, COM3, COM4 (optional) ..2-11 2.5.5 Dual USB 2.0 Ports (USB3, USB4, USB5) ......2-11 2.5.6 Dual USB 3.0 Ports (USB1, USB2) ........2-12 PA-J670 SERIES USER MANUAL Page: i...
  • Page 5 2.6.17 M.2 SSD Express Slot (M2_M) .......... 2-31 2.6.18 SATA 3.0 & SATA Power Connectors (SATA1, SATA_PWR1) ..................2-32 2.6.19 LPC Connector (JLPC1) ............ 2-33 2.6.20 Fan Connector (FAN_1) ............. 2-33 2.6.21 Power Output Connectors (OUT12V_1, OUT12V_2, Page: ii PA-J670 SERIES USER MANUAL...
  • Page 6 Terminal Assignment Connector ........2-50 2.7.4 Printer Board: MB-1030 series ........... 2-51 2.7.4.1 Jumper & Connector Quick Reference Table....2-52 2.7.5 Setting Printer Board Connectors and Jumpers : MB-3010 ..................... 2-53 2.7.5.1 Power Supply Connector ..........2-53 PA-J670 SERIES USER MANUAL Page: iii...
  • Page 7 2.9 MSR Board Component Locations & Pin Assignment ....2-68 2.9.1 ID TECH ................2-68 2.9.1.1 Main Connector ............2-68 2.9.2 MB-3012 ................2-69 2.9.2.1 Information Button Reader ........... 2-69 2.9.2.2 Output Connector ............2-69 Page: iv PA-J670 SERIES USER MANUAL...
  • Page 8 3.11.5 Hardware Monitor ............... 3-64 3.11.6 I-Button ................3-65 3.12 API Function ................3-66 3.12.1 Cash Drawer Function ............3-66 3.12.2 Watch Dog Function ............3-67 3.12.3 Hardware Monitor Function ..........3-68 3.12.4 I-Button Function ..............3-70 PA-J670 SERIES USER MANUAL Page: v...
  • Page 9 USB Configuration ............. 4-26 4.5 Chipset ..................4-27 4.5.1 North Bridge ............... 4-28 4.5.2 South Cluster Configuration ..........4-29 4.5.2.1 South Cluster Configuration - HD-Audio Configuration 4-30 4.5.2.2 South Cluster Configuration - LPSS Configuration ..4-31 Page: vi PA-J670 SERIES USER MANUAL...
  • Page 10 Exploded Diagrams for Packing .............A-66 Exploded Diagrams for Spare Parts ............A-70 Appendix B Technical Summary ..........B-1 Interrupt Map ....................B-2 I/O MAP ....................B-17 Memory Map ...................B-19 Configuring WatchDog Timer ..............B-21 Flash BIOS Update .................B-23 PA-J670 SERIES USER MANUAL Page: vii...

  • Page 11: Introduction

    Introduction This chapter gives you the information for the PA-J670. It also outlines the system specifications. The following topics are included: • About This Manual • POS System Diagrams • System Specifications • Safety Precautions Experienced users can go to Chapter 2 for a quick start.

  • Page 12: About This Manual

    Chapter 1 Introduction About This Manual Thank you for purchasing our PA-J670 Series System. The PA-J670 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The PA-J670 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 13: Pos System Diagrams

    Chapter 1 Introduction POS System Diagrams Unit: mm 1.2.1 Panel PC Page: 1-3 PA-J670 SERIES USER MANUAL...

  • Page 14: Easy Stand

    Chapter 1 Introduction 1.2.2 Easy Stand Non-bezel-free Bezel-free TouchScreen 15” Touch & LCD Optional- Power MSR & iButton LED Light Stand Adjustable angle 30~50 degree Page: 1-4 PA-J670 SERIES USER MANUAL...

  • Page 15: Small Stand

    Chapter 1 Introduction 1.2.3 Small Stand Page: 1-5 PA-J670 SERIES USER MANUAL...

  • Page 16: Printer Stand

    Chapter 1 Introduction 1.2.4 PRINTER Stand Unit: mm Page: 1-6 PA-J670 SERIES USER MANUAL...
  • Page 17 Chapter 1 Introduction Caution: Please refer to the picture below to close the printer door properly. Page: 1-7 PA-J670 SERIES USER MANUAL...

  • Page 18: System Specifications

    1 x RJ12 (+12V or +24V selectable)  HDD Slot 1 x HDD maintenance slot  DC In 1 x 4-pin DC power jack  DC Out 1x 12Vdc out (3-pin) for 2nd display (optional) Page: 1-8 PA-J670 SERIES USER MANUAL...
  • Page 19 2nd Display  Standalone: 15" LCD  Interface: RS-232C Baud Rate: 9600/19200 bps Customer Display  VFD Kit, Placement: 20 columns and 2 lines, each column is 5 x 7 dots 3.75 0.55 0.75 6.75 Page: 1-9 PA-J670 SERIES USER MANUAL...
  • Page 20 2inch 432 dots; Printable dots per line 3inch 576 dots Maximum print speed 2inch 200 mm/s; 3inch 170 mm/s Print width 2inch 54 mm; 3inch 72mm Paper width 2inch 58 +0/-1 mm; 3inch 80 +0/-1 mm Page: 1-10 PA-J670 SERIES USER MANUAL...
  • Page 21 φ8 mm (paper thickness: 75μm Minimum paper core diameter or thin) φ18 (paper thickness: thicker than 75μm) Minimum paper 10 m cutting length Cutting processing time Approx. 0.5 s/cycle Cutting frequency 1 cut/2 s max. Page: 1-11 PA-J670 SERIES USER MANUAL...
  • Page 22 CP-1257, Katakana KANJI • JAPANESE (SHIFT-JIS) Code, TRADITIONAL CHINESE Code International Characters • USA, FRANCE, GERMANY, UK, DENMARK I, SWDEN, ITALY, SPAIN I, JAPAN, NORWAY, DENMARK II, SPAIN II, LATIN AMERICA, KOREA, RUSSIA, SLAVONIC Page: 1-12 PA-J670 SERIES USER MANUAL...

  • Page 23: Safety Precautions

    Avoid direct sunlight exposure for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use PA-J670 when it has been left outdoors in a cold winter day. •...

  • Page 24: System Configuration

    Setting Main Board Connectors and Jumpers • Printer Board Component Locations & Pin Assignment • Setting Printer Board Connectors and Jumpers PDAC-3100  MB3010C  MB-1011 & MB-1013  • Setting VFD Board Connectors and Jumpers Page: 2-1 PA-J670 SERIES USER MANUAL...

  • Page 25: System External I/O Ports Diagram & Pin Assignment

    Rear I/O Ports USB 2.0 HDMI Cash USB 3.0 COM3 COM1 Drawer COM2 DC-IN Line Out Mic In Option: Printer Power or Option: Power USB or 2nd Display COM4 Power Side I/O Power USB5 Button (option) Page: 2-2 PA-J670 SERIES USER MANUAL...

  • Page 26: Main Board Component Location & Jumper Settings

    JLPC1 JP11 COM4 OUT12V_1 I-BUT1 JP_USB5 JP_USB3_2 JINV1 USB3_2 JP_VDD1 JP_USB3_1 USB5 FAN_1 JUSB7 M.2 SSD EDP1 M.2 Wi-Fi M2_M M2_E USB2 SW2 LED1 JSPK1 BAT1 JAUD1 Figure 2-1 PB-A900 Main Board Component Location Page: 2-3 PA-J670 SERIES USER MANUAL...
  • Page 27 CAUTION: Observe precautions while handling electrostatic sensitive components. Make sure to ground yourself to prevent static charge while configuring the connectors and jumpers. Use a grounding wrist strap and place all electronic components in any static-shielded devices. Page: 2-4 PA-J670 SERIES USER MANUAL...

  • Page 28: Bottom View Of System Main Board

    Chapter 2 System Configuration 2.2.2 Bottom View of System Main Board Page: 2-5 PA-J670 SERIES USER MANUAL...

  • Page 29: Setting Jumpers

    2 to create one setting and shorting. You can also select to connect pins 2 and 3 to create another setting. The format of the jumper picture will be illustrated throughout this manual. The figure below shows different types of jumpers and jumper settings. Page: 2-6 PA-J670 SERIES USER MANUAL...
  • Page 30 Chapter 2 System Configuration Jumper Diagrams Jumper Settings Page: 2-7 PA-J670 SERIES USER MANUAL...

  • Page 31: Setting Main Board Connectors And Jumpers

    USB 2.0 Connectors JUSB7 HD Audio Connector JAUD1 LVDS Inverter Connector JINV1 Embedded Display Port (EDP) Connector EDP1 M.2 Wi-Fi Express Slot M2_E M.2 SSD Express Slot M2_M SATA 3.0 & SATA Power Connectors SATA1, SATA_PWR1 Page: 2-8 PA-J670 SERIES USER MANUAL...
  • Page 32 Chapter 2 System Configuration System CONNECTOR Description NAME LPC Connector JLPC1 Fan Connector FAN_1 OUT12V_1, OUT12V_2, Power Output Connectors OUT_24V RTC Connector BAT1 Speaker Connector JSPK1 Switch LED Connectors SW2, LED1 Page: 2-9 PA-J670 SERIES USER MANUAL...
  • Page 33 Description: DC Power-In Port (rear IO) ASSIGNMENT ASSIGNMENT DC-IN +24V +24V 2.5.3 VGA Port (VGA) Port Name: VGA Description: VGA Port, D-Sub 15-pin (rear I/O) ASSIGNMENT ASSIGNMENT GREEN BLUE DDCA DATA HSYNC VSYNC DDCA CLK Page: 2-10 PA-J670 SERIES USER MANUAL...
  • Page 34 Connector Location: USB3, USB4, USB5 (side I/O) Description: Dual USB 2.0 Connectors (Type A) (Rear I/O) • USB3-4: Rear I/O • USB5: Side I/O (option) USB3/ USB 2.0 signals: USB4/ ASSIGNMENT ASSIGNMENT USB5 VCC5_USB3 VCC5_USB3 (option) USB2_P3_DN USB2_P4_DN USB2_P3_DP USB2_P4_DP Page: 2-11 PA-J670 SERIES USER MANUAL...
  • Page 35 Left Side LED Yellow Blink LAN connection is activated. No LAN message active. Right Side LED Green 100 LAN connection is activated. Orange Giga LAN connection is activated. No LAN switch/ hub is activated. Page: 2-12 PA-J670 SERIES USER MANUAL...
  • Page 36 GPIO2 / DRW2 DRW1 Draw1 Sense 2.5.10 2nd Display Power Port (2nd DIS PWR) (optional) Port Name: 2nd DIS PWR (rear I/O) Description: DC12V power supply for 2nd display ASSIGNMENT VCC12 2ND DIS PWR VCC12 Page: 2-13 PA-J670 SERIES USER MANUAL...
  • Page 37 Chapter 2 System Configuration 2.5.11 HDMI Port Connector (HDMI) Port Name: HDMI Description: HDMI Connector (rear I/O) HDMI ASSIGNMENT ASSIGNMENT DP0_HDMI_P2 DP0_HDMI_N2 DP0_HDMI_P1 DP0_HDMI_N1 DP0_HDMI_P0 DP0_HDMI_N0 DP0_HDMI_CLKP DP0_HDMI_CLKN DP0_HDMI_SCL_5V DP0_HDMI_SDA_5V VCC5_HDMI DP1_HDMI_HPD_IN Page: 2-14 PA-J670 SERIES USER MANUAL...
  • Page 38 Chapter 2 System Configuration 2.5.12 Power USB Connector (PWR USB) (optional) Port Name: PWR USB (rear I/O) Description: Power USB Connector ASSIGNMENT ASSIGNMENT 12V/24V 12V/24V PWR USB (option) Page: 2-15 PA-J670 SERIES USER MANUAL...
  • Page 39 COM4_RX COM4_RTS COM4 COM4_TX COM4_CTS COM4_DTR COM4_RI Note: COM4 will not function when jumpers JP6, JP7, JP8 are set as 2-3 connected (i-Button). Refer to the COM4 & i-Button Function Selection section for details. Page: 2-16 PA-J670 SERIES USER MANUAL...
  • Page 40 Chapter 2 System Configuration 2.6.3 VGA Connector (JVGA1) Connector Location: JVGA1 Description: VGA Connector ASSIGNMENT ASSIGNMENT CRT_RED_LL CRT_GREEN_LL CRT_BLUE_LL SPC_R CRT_VCC_L SPD_R CRT_DDC_DATA_O CRT_HSYNC_O CRT_VSYNC_O CRT_DDC_CLK_O JVGA1 Page: 2-17 PA-J670 SERIES USER MANUAL...
  • Page 41 PWM & BKLTCTL Signal Selection (JP4) Jumper Location: JP4 Description: "PWM & BKLTCTL signal support to" selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION PWM & BKLTCTL 1-3, 2-4 signal from PWM & BKLTCTL 3-5, 4-6 signal from (Default Setting) CH7511 Page: 2-18 PA-J670 SERIES USER MANUAL...
  • Page 42 Chapter 2 System Configuration 2.6.5 PWM Voltage Selection (JP5) Jumper Location: JP5 Description: PWM voltage election Selection Jumper Setting Jumper Illustration 3.3V (Default Setting) Page: 2-19 PA-J670 SERIES USER MANUAL...
  • Page 43 JUMPER ILLUSTRATION COM4 (Default Setting) JP6/JP7/JP8 I-BUT JP6/JP7/JP8 Note: COM4 will not function when jumpers JP6, JP7, JP8 are set as 2-3 connected (i-Button). Refer to the COM4 & i-Button Function Selection section for details. Page: 2-20 PA-J670 SERIES USER MANUAL...
  • Page 44 Jumper Setting Jumper Illustration 3-5, 4-6 1 Drawer & 12V (Default Setting) JP11 1 Drawer & 24V 2-4, 3-5 JP11 2 Drawers & 12V 1-3, 4-6 JP11 2 Drawers & 24V 1-3, 2-4 JP11 Page: 2-21 PA-J670 SERIES USER MANUAL...
  • Page 45 Chapter 2 System Configuration DRW1 DRW1-1 DRW1, DRW1-1, DRW1-2 shares the same power source. (Default: 12V). SIO Address Cash drawer 1 LDN 06, 0x91 bit 2 Cash drawer 2 LDN 06, 0x91 bit 3 Page: 2-22 PA-J670 SERIES USER MANUAL...
  • Page 46 To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. Page: 2-23 PA-J670 SERIES USER MANUAL...
  • Page 47 Description: Slide Switch for Panel Resolution Selection SELECTION SETTING 1024 x 768 (24 bit) (Default Setting) 2.6.9 USB 2.0 Connector (USB3_2) Connector Location: USB3_2 Description: USB 2.0 Connector ASSIGNMENT ASSIGNMENT VCC5_USB3 VCC5_USB3 USB2_P3_DN USB2_P4_DN USB2_P3_DP USB2_P4_DP USB3_2 Page: 2-24 PA-J670 SERIES USER MANUAL...
  • Page 48 Description: USB 2.0 Connector USB2/ ASSIGNMENT USB5/ VCC5_USB5 USB2_P5_DN USB6 USB2_P5_DP Connector Location: USB6 Description: USB 2.0 Connector ASSIGNMENT VCC5_USB5 USB2_P6_DN USB2_P6_DP Connector Location: JUSB7 Description: USB 2.0 Connector ASSIGNMENT VCC5 USB2_P7_DN USB2_P7_DP JUSB7 Page: 2-25 PA-J670 SERIES USER MANUAL...
  • Page 49 Chapter 2 System Configuration 2.6.11 Touch Panel Connector (TOUCH1) Connector Location: TOUCH1 Description: Touch Panel Connector ASSIGNMENT VCC5 USB2_P2_DN USB2_P2_DP TOUCH1 Page: 2-26 PA-J670 SERIES USER MANUAL...
  • Page 50 Chapter 2 System Configuration 2.6.12 HD Audio Connector (JAUD1) Connector Location: JAUD1 Description: HD Audio Connector ASSIGNMENT ASSIGNMENT HD_MIC-L HD_GND HD_MIC-R PRESENCE_N JAUD1 LINE-OUT-R MIC-JD HD_GND LINE-OUT-L LINE-OUT-JD Page: 2-27 PA-J670 SERIES USER MANUAL...
  • Page 51 Embedded Display Port (EDP) Connector (EDP1) Connector Location: EDP1 Description: EDP Connector ASSIGNMENT ASSIGNMENT EDP_DCR_EN EDP_SELF_TEST DDP_ P1 DDP_ N1 EDP_DET SOC_BKLTEN DDP_ N0 PANEL_BKLTCTL DDP_ P0 DP_AUX_DP DP_AUX_DN V12P0_INV V12P0_INV V12P0_INV V12P0_INV LVDS_VCC EDP1 LVDS_VCC Page: 2-28 PA-J670 SERIES USER MANUAL...
  • Page 52 Chapter 2 System Configuration 2.6.14 LVDS Inverter Connector (JINV1) Connector Location: JINV1 Description: LVDS Inverter Connector ASSIGNMENT V12P0_INV V12P0_INV JINV1 LVDS_BKLCTL LVDS_BKLTEN 2.6.15 i-Button Connector (I-BUT) Connector Location: I-BUT Description: i-Button Connector ASSIGNMENT I-BUT COM4_DTR_R_I COM4_RXD_R_I Page: 2-29 PA-J670 SERIES USER MANUAL...
  • Page 53 M.2 Wi-Fi Express Slot (M2_E) Connector Location: M2_E Description: M.2 Wi-Fi Express Slot ASSIGNMENT ASSIGNMENT V3P3S USB2_P2_DP V3P3S USB2_P2_DN M2_E PCIE_P1_TXP PCIE_P1_TXN PCIE_P1_RXP PCIE_P1_RXN M2_PCIE_CLKP M2_PCIE_CLKN SUSCLK WIFI_RST_ M2_PCIE_CLKREQ KILL_BT_N WAKE_M2_PCIE_N KILL_WIFI_N V3P3S V3P3S Page: 2-30 PA-J670 SERIES USER MANUAL...
  • Page 54 Chapter 2 System Configuration 2.6.17 M.2 SSD Express Slot (M2_M) Connector Location: M2_M Description: M.2 SSD KEY M Slot ASSIGNMENT ASSIGNMENT V3P3S V3P3S M2_M SATA_DEVSLP1 SATA_RXP1 SATA_RXN1 SATA_TXN1 SATA_TXP1 V3P3S V3P3S V3P3S Page: 2-31 PA-J670 SERIES USER MANUAL...
  • Page 55 Chapter 2 System Configuration 2.6.18 SATA 3.0 & SATA Power Connectors (SATA1, SATA_PWR1) Connector Location: SATA1 Description: Serial ATA 3.0 connector ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA_RXP0 SATA1 Connector Location: SATA_PWR1 Description: HDD Power Connector ASSIGNMENT VCC5 SATA_PWR1 Page: 2-32 PA-J670 SERIES USER MANUAL...
  • Page 56 Connector Location: JLPC1 Description: Low Pin Count Connector ASSIGNMENT ASSIGNMENT LPC_CLKOUT1 LPC_LFRAMEJ PMU_PLTRST_N LPC_AD0 JLPC1 LPC_AD3 LPC_AD2 V3P3A LPC_AD1 2.6.20 Fan Connector (FAN_1) Connector Location: FAN_1 Description: Fan Connector ASSIGNMENT V12P0S FANIN FAN_1 FANOUT Page: 2-33 PA-J670 SERIES USER MANUAL...

  • Page 57: Out24V

    Connector Location: OUT12V_1 Description: Output 12V Wafer ASSIGNMENT V12P0S V12P0S OUT12V_1 Connector Location: OUT12V_2 Description: Output 12V Wafer ASSIGNMENT V12P0S V12P0S OUT12V_2 / Connector Location: OUT24V OUT24V Description: Output 24V Wafer ASSIGNMENT VIN_24V VIN_24V Page: 2-34 PA-J670 SERIES USER MANUAL...

  • Page 58: Rtc Connector (Bat1)

    Chapter 2 System Configuration 2.6.22 RTC Connector (BAT1) Connector Location: BAT1 Description: RTC Connector ASSIGNMENT VBAT BAT1 2.6.23 Speaker Connector (JSPK1) Connector Location: JSPK1 Description: Speaker Connector ASSIGNMENT JSPK1 HD_SPK_R HD_SPK_L Page: 2-35 PA-J670 SERIES USER MANUAL...

  • Page 59: Switch Led Connectors (Sw2, Led1)

    Chapter 2 System Configuration 2.6.24 Switch LED Connectors (SW2, LED1) Connector Location: SW2 Description: Power Button ASSIGNMENT PWRBTNJ Connector Location: LED1 Description: System Power LED ASSIGNMENT V5P0S LED1 Page: 2-36 PA-J670 SERIES USER MANUAL...

  • Page 60: Usb2 Port Selection (Jp_Usb2)

    Chapter 2 System Configuration 2.6.25 USB2 Port Selection (JP_USB2) Jumper Location: JP_USB2 Description: USB2 Port Selection Selection Jumper Setting Jumper Illustration M.2 USB 1-3, 2-4 JP_USB2 3-5, 4-6 USB2 (Default Setting) JP_USB2 Page: 2-37 PA-J670 SERIES USER MANUAL...

  • Page 61: Usb3 Port Selection (Jp_Usb3_1, Jp_Usb3_2)

    1-3, 2-4 (See Note 1) (Default Setting) JP_USB3_1/ JP_USB3_2 USB3_2 3-5, 4-6 (See Note 2) JP_USB3_1/ JP_USB3_2 Note 1: Internal USB3_1 will be disabled. Note 2: External 2 x USB 2.0 ports will be disabled. Page: 2-38 PA-J670 SERIES USER MANUAL...

  • Page 62: Usb5 Port Selection (Jp_Usb5)

    Chapter 2 System Configuration 2.6.27 USB5 Port Selection (JP_USB5) Jumper Location: JP_USB5 Description: USB5 Port Selection Selection Jumper Setting Jumper Illustration 3-5, 4-6 USB5 (Default Setting) JP_USB5 Page: 2-39 PA-J670 SERIES USER MANUAL...

  • Page 63: Force Dnx Firmware Load Selection (Jp1)

    Selection Jumper Setting Jumper Illustration Open Normal (Default Setting) Force 2.6.29 Flash Descriptor Override Selection (JP1) Jumper Location: JP1 Description: Flash Descriptor Override Selection Selection Jumper Setting Jumper Illustration Open Normal (Default Setting) Override Page: 2-40 PA-J670 SERIES USER MANUAL...
  • Page 64 Chapter 2 System Configuration 2.6.30 EDP (Embedded Display Port) Voltage Selection (JP_VDD1) Jumper Location: JP_VDD1 Description: EDP Voltage Selection Selection Jumper Setting Jumper Illustration 3.3V (Default Setting) JP_VDD1 JP_VDD1 Page: 2-41 PA-J670 SERIES USER MANUAL...

  • Page 65: Clear Cmos Data Selection (Jp3)

    Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Normal (Default Setting) Clear CMOS* Note: Please make sure the main power is off before you clear CMOS data. Page: 2-42 PA-J670 SERIES USER MANUAL...

  • Page 66: Cash Drawer Control Selection

    ;------ Open the Cash drawer 1 -------------------------------------------- mov al, 91h out dx, al inc dx mov al, 04h out dx, al ;------ Exit the extended function mode -------------------------------------------------------- dec dx mov al, 0aah out dx, al Page: 2-43 PA-J670 SERIES USER MANUAL...

  • Page 67: Printer Board Component Locations & Pin Assignment

    Chapter 2 System Configuration Printer Board Component Locations & Pin Assignment 2.7.1 Printer Board: PDAC-3100 Figure 2-2. PDAC-3100 Printer Board Component Locations Page: 2-44 PA-J670 SERIES USER MANUAL...

  • Page 68: Jumper & Connector Quick Reference Table

    Chapter 2 System Configuration 2.7.2 Jumper & Connector Quick Reference Table Jumper / Connector NAME Power Supply Connector RS-232 Interface Connector Auto-Cutter Connector USB Connector Thermal Head/Motor/Sensor Connector Terminal Assignment Connector Page: 2-45 PA-J670 SERIES USER MANUAL...
  • Page 69 Chapter 2 System Configuration 2.7.3 Setting Printer Board Connectors and Jumpers: PDAC-3100 2.7.3.1 Power Supply Connector CN1: Power supply wafer ASSIGNMENT +24V +24V 2.7.3.2 RS-232 Interface Connector CN7: RS-232 interface connector ASSIGNMENT ASSIGNMENT Page: 2-46 PA-J670 SERIES USER MANUAL...
  • Page 70 2A-2 Auto-cutter motor drive signal 1B-1 Auto-cutter motor drive signal 1B-2 Auto-cutter motor drive signal 1A-1 Auto-cutter motor drive signal 1A-2 Auto-cutter motor drive signal 2.7.3.4 USB Connector CN8: USB Connector ASSIGNMENT ASSIGNMENT Vbus Page: 2-47 PA-J670 SERIES USER MANUAL...

  • Page 71: Thermal Head/Motor/Sensor Connector

    Head strobe signal Head GND Head GND Head GND Head GND Head GND Head GND LATCH Print data latch Head drive power Head drive power Head drive power Head drive power Head drive power Page: 2-48 PA-J670 SERIES USER MANUAL...
  • Page 72 Power supply of the out-of-paper sensor GND of the platen position/ out-of-paper sensor Signal of the platen position sensor Unused Frame GND Frame GND Unused Motor drive signal Motor drive signal Motor drive signal Motor drive signal Page: 2-49 PA-J670 SERIES USER MANUAL...

  • Page 73: Terminal Assignment Connector

    Feed signal RESET Reset signal Status signal Status signal Status signal Status signal Drawer sensor signal Drawer switch signal Drive terminal for the drawer (Vp side) GNDdu Drive terminal for the drawer (GND side) Unused Page: 2-50 PA-J670 SERIES USER MANUAL...

  • Page 74: Printer Board: Mb-1030 Series

    Chapter 2 System Configuration 2.7.4 Printer Board: MB-1030 series CUT_CN1 COM1 9 10 USB_CN1 24V_CN1 PRINT_CN1 Figure 2-3. MB-1030 Printer Board Component Locations Page: 2-51 PA-J670 SERIES USER MANUAL...

  • Page 75: Jumper & Connector Quick Reference Table

    Jumper & Connector Quick Reference Table Jumper / Connector NAME Power Supply Connector 24V_CN1 RS-232 Interface Connector COM1 Thermal Head/Motor/Sensor Connector PRINT_CN1 Auto-Cutter Connector CUT_CN1 Paper-Near-END Sensor Connector USB Interface Connector USB_CN1 Terminal Assignment Connector Page: 2-52 PA-J670 SERIES USER MANUAL...
  • Page 76 Setting Printer Board Connectors and Jumpers : MB-3010 2.7.5.1 Power Supply Connector 24V_CN1: Power Supply Wafer ASSIGNMENT +24V +24V 24V_CN1 2.7.5.2 RS-232 Interface Connector COM1: RS-232 Interface Connector ASSIGNMENT ASSIGNMENT DSR /CTS DTR /RTS 9 10 COM1 Page: 2-53 PA-J670 SERIES USER MANUAL...
  • Page 77 Head strobe signal Head GND Head GND Head GND Head GND Head GND Head GND LATCH Print data latch Head drive power Head drive power Head drive power Head drive power Head drive power Page: 2-54 PA-J670 SERIES USER MANUAL...
  • Page 78 Power supply of the out-of-paper sensor GND of the platen position/ out-of-paper sensor Signal of the platen position sensor Unused Frame GND Frame GND Unused Motor drive signal Motor drive signal Motor drive signal Motor drive signal Page: 2-55 PA-J670 SERIES USER MANUAL...
  • Page 79 1A-2 Auto-cutter motor drive signal 2.7.5.5 Paper-Near-END Sensor Connector CN2: Paper-near-end sensor connector ASSIGNMENT FUNCTION Power supply of the near end sensor Signal of the near end sensor GND of the near end sensor Page: 2-56 PA-J670 SERIES USER MANUAL...
  • Page 80 Feed signal RESET Reset signal Status signal Status signal Status signal Status signal Drawer sensor signal Drawer switch signal Drive terminal for the drawer (Vp side) GNDdu Drive terminal for the drawer (GND side) Unused Page: 2-57 PA-J670 SERIES USER MANUAL...

  • Page 81: Printer Board: Mb-1011 & Mb-1013

    Chapter 2 System Configuration 2.7.6 Printer Board: MB-1011 & MB-1013 MB-1013 MB-1011 Figure 2-4. MB-1011 & MB-1013 Printer Board Component Locations Page: 2-58 PA-J670 SERIES USER MANUAL...

  • Page 82: Jumper & Connector Quick Reference Table

    Chapter 2 System Configuration 2.7.6.1 Jumper & Connector Quick Reference Table Jumper / Connector NAME Power Supply Connector RS-232 Interface Connector Auto-Cutter Connector Thermal Head/Motor/Sensor Connector Terminal Assignment Connector USB Interface Connector Page: 2-59 PA-J670 SERIES USER MANUAL...

  • Page 83: Setting Printer Board Connectors And Jumpers: Mb-1011

    Chapter 2 System Configuration 2.7.7 Setting Printer Board Connectors and Jumpers: MB-1011 & MB-1013 2.7.7.1 Power Supply Connector CN1: Power supply wafer ASSIGNMENT +24V +24V 2.7.7.2 RS-232 Interface Connector CN7: RS-232 interface connector ASSIGNMENT ASSIGNMENT Page: 2-60 PA-J670 SERIES USER MANUAL...

  • Page 84: Auto-Cutter Connector

    Head drive power Head drive power Head drive power Head drive power Head drive power Print data output Synchronizing signal for print data transfer Head GND Head GND Head GND Head GND Head GND Head GND Page: 2-61 PA-J670 SERIES USER MANUAL...
  • Page 85 Power supply of the out-of-paper sensor GND of the platen position/ out-of-paper sensor Signal of the platen position sensor Unused Frame GND Frame GND Unused Motor drive signal Motor drive signal Motor drive signal Motor drive signal Page: 2-62 PA-J670 SERIES USER MANUAL...

  • Page 86: Terminal Assignment Connector

    Status signal Drawer sensor signal Drawer switch signal Drive terminal for the drawer (Vp side) GNDdu Drive terminal for the drawer (GND side) Unused 2.7.7.6 USB Interface Connector CN8: USB interface connector ASSIGNMENT Vbus Page: 2-63 PA-J670 SERIES USER MANUAL...

  • Page 87: Vfd Board Component Locations & Pin Assignment

    Chapter 2 System Configuration VFD Board Component Locations & Pin Assignment 2.8.1 VFD Board: MB-4103, LD720 JP12V Figure 2-5. MB-4103 & LD720 VFD Board Component Locations Page: 2-64 PA-J670 SERIES USER MANUAL...

  • Page 88: Jumper & Connector Quick Reference Table

    Chapter 2 System Configuration 2.8.2 Jumper & Connector Quick Reference Table Jumper / Connector NAME Power Switch Selection JP12V RS-232 Serial Interface Connector Page: 2-65 PA-J670 SERIES USER MANUAL...
  • Page 89 Chapter 2 System Configuration 2.8.3 Setting MB-4103 & LD720 VFD Board Connectors and Jumpers 2.8.3.1 Power Switch Selection JP12V: Power Switch Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION JP12V (Default) JP12V Page: 2-66 PA-J670 SERIES USER MANUAL...
  • Page 90 Chapter 2 System Configuration 2.8.3.2 RS-232 Serial Interface Connector CN1: RS-232 serial interface wafer ASSIGNMENT ASSIGNMENT +12V/+5V Page: 2-67 PA-J670 SERIES USER MANUAL...

  • Page 91: Msr Board Component Locations & Pin Assignment

    MSR Board Component Locations & Pin Assignment 2.9.1 ID TECH ID-TECH MSR Board Component Locations 2.9.1.1 Main Connector ASSIGNMENT ASSIGNMENT K-CLK Chassis Ground (Computer connections) P-CLK K-DATA (Keyboard connections) (Computer connections) P-DATA (Keyboard connections) +5V Vcc Page: 2-68 PA-J670 SERIES USER MANUAL...

  • Page 92: Information Button Reader

    MB-3012 MSR Board Component Locations 2.9.2.1 Information Button Reader I_BUTTON1: Information button reader ASSIGNMENT I_B1 I_BUTTON1 2.9.2.2 Output Connector IO1: Output wafer ASSIGNMENT ASSIGNMENT CLK_KB RX_MSR CLK_PC TX_MSR DATA_KB DATA_PC USB_D+_R USB_D-_R CHASSIS GND Page: 2-69 PA-J670 SERIES USER MANUAL...

  • Page 93: Software Utilities

    Trusted Execution Engine Installation Utility ® - Intel Serial I/O Driver Utility - Microsoft Hotfix Driver Utility ® - Intel Processor Win10 IO Driver Utility • Embedded Peripheral Devices - Printer - VFD - MSR • PA-J670 SERIES USER MANUAL Page: 3-1...

  • Page 94: Driver Disc

    Chapter 3 Software Utilities Driver Disc Enclosed with the PA-J670 Series package is our driver utilities, which comes in a DVD-ROM format. Refer to the following table for driver locations Windows 10 Enterprise 2016 LTSB_64Bit Filename (Assume that Purpose DVD- ROM drive is D :)
  • Page 95 Intel(R) Trusted Execution Engine 2019(64-bit) D:\DRIVER\Platform\5_Sound Realtek High Definition Audio driver Codec\Win10 2019(64-bit) installation D:\DRIVER\Platform\6_LAN Intel(R) Network Connections Software Chip\Win10 2019(64-bit) Note: Users must install the driver utilities right after the OS is fully installed. PA-J670 SERIES USER MANUAL Page: 3-3...

  • Page 96: Intel Chipset Software Installation Utility

    Windows 10 2019 (64-bit), and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located.

  • Page 97: Installing Graphics Driver Utility

    VGA, HDMI interfaces and make the system work simultaneously. To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Enter the Graphics folder where the driver is located.

  • Page 98: Lan Driver Utility

    LAN Driver Utility Enhanced with LAN function, PA-J670 supports various network adaptors. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Enter the LAN folder where the driver is located.

  • Page 99: Sound Driver Utility

    Chapter 3 Software Utilities Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Open the Sound Codec folder where the driver is located. Click the Setup.exe file for Windows 10 2016 (64-bit) and Windows 10 2019 (64-bit) driver installation.

  • Page 100: Installing Intel Trusted Execution Engine Installation Utility

    Trusted Execution Engine Installation Utility To install the utility, simply follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Enter the TXE folder where the driver is located. Click SetupTXE.exe file for Windows 10 2016 (64-bit) and Windows 10 2019 (64-bit) driver installation.

  • Page 101: Installing Intel Serial I/O Driver Utility

    Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Open the Serial IO folder where the driver is located. Click the SetupSerialIO.exe file for Windows 10 2016 (64-bit) driver installation.

  • Page 102: 3.8 Installing Microsoft Hotfix Driver Utility

    Windows 10, detects the system's capabilities and installs the relevant drivers and applications. To install the utility, simply follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Enter the Hotfix folder where the driver is located.

  • Page 103: Installing Intel Processor Win10 Io Driver Utility

    3.9 Installing Intel Processor Win10 IO Driver Utility To install the utility, simply follow the steps below: Connect the USB DVD-ROM device to PA-J670 and insert the driver disk. Enter the IO folder where the driver is located. Click the Intel_Processor_Win10_IO_Drivers_64Bit.exe file for Windows 10 2016 (64-bit) driver installation.

  • Page 104: 3.10 Peripheral Devices

    GS h FS q GS k ESC 2 GS ! GS r ESC 3 GS $ GS v 0 ESC = GS * GS w ESC ? GS ( A ESC @ GS ( K PA-J670 SERIES USER MANUAL Page: 3-12...
  • Page 105 1B 32 Select default line spacing <ESC 3> 1B 33 Set line spacing <ESC => 1B 3D Select peripheral device <ESC @> 1B 40 Initialize printer <ESC D> 1B 44 Set horizontal tab position PA-J670 SERIES USER MANUAL Page: 3-13...
  • Page 106 Set basic calculated pitch ◎ <GS V> 1D 56 Cut paper ▲ ◎ <GS W> 1D 57 Set printing area width Set relative vertical print position in page <GS \> 1D 5C Ignored mode PA-J670 SERIES USER MANUAL Page: 3-14...
  • Page 107 ● <GS k> 1D 6B Print bar code <GS r> 1D 72 Transmit status ● <GS v 0> 1D 76 30 Print raster bit image Disabled <GS w> 1D 77 Set bar code width PA-J670 SERIES USER MANUAL Page: 3-15...
  • Page 108 ●: Enabled only when data is not present in the printer buffer. ▲: Only value setting is possible. Disabled: Parameters are processed as printable data. Ignored: All command codes including parameters are ignored and nothing is executed. PA-J670 SERIES USER MANUAL Page: 3-16...
  • Page 109 Prints the data in the print buffer and performs a line feed based on the set line [Description] feed amount.  After execution, makes the top of the line the next print starting position. PA-J670 SERIES USER MANUAL Page: 3-17...
  • Page 110 Deletes all print data in the currently set print region in page mode.  This command is enabled only in page mode. [Description]  Portions included in the currently set print region are also deleted, even if previously set print region data. PA-J670 SERIES USER MANUAL Page: 3-18...
  • Page 111 Not used. Fixed to On. Not used. Fixed to Off. Not used. Fixed to Off. Not used. Fixed to On. Not used. Fixed to Off. Not used. Fixed to Off. Not used. Fixed to Off. PA-J670 SERIES USER MANUAL Page: 3-19...
  • Page 112 = 0: #2 Pin of the drawer kick connector [Description] m = 1: #5 Pin of the drawer kick connector On time is set to t x 100 msec; Off time is set to t x 100 msec. PA-J670 SERIES USER MANUAL Page: 3-20...
  • Page 113 [Format] Hex. Decimal 0 ≤ n ≤ 255 [Range] Initial Value n = 0 This command sets the size of space to right of character. [Description] Right space = n × [horizontal motion units]. PA-J670 SERIES USER MANUAL Page: 3-21...
  • Page 114 This command specifies the next print starting position in reference to the left edge of the print area. The printing start position is calculated using (nL + nH x [Description] 256) x (vertical or horizontal motion units). Specifications exceeding the print range are ignored. PA-J670 SERIES USER MANUAL Page: 3-22...
  • Page 115 This command enables the print data following it to be printer out underlined. The underline mode varied depending on the following values of n: Function [Description] Turns off underline mode Turns on underline mode, set at 1-dot thick Turns on underline mode, set at 2-dot thick PA-J670 SERIES USER MANUAL Page: 3-23...
  • Page 116 [Range] Initial Value n = 1 [Description] Selects the peripheral device for which the data is effective from the host computer. Function “0” “1” Undefined Undefined Undefined Undefined Undefined Undefined Undefined Printer Invalid Valid PA-J670 SERIES USER MANUAL Page: 3-24...
  • Page 117 This command turns emphasized mode on or off by toggling the least significant bit of n as followings: [Description] When the LSB of n is 0, the emphasized mode is turned off. When the LSB of n is 1, the emphasized mode is turned on. PA-J670 SERIES USER MANUAL Page: 3-25...
  • Page 118 ESC T, the horizontal motion unit (x) is used.  The maximum line spacing is 150mm {5.9 inches }. When the setting value exceeds the maximum, it is converted to the maximum automatically. PA-J670 SERIES USER MANUAL Page: 3-26...
  • Page 119 FS q : Define NV bit image c. GS v 0 : Print raster bit images d. GS L : Set left margin  Recover to standard mode using ESC @ (initialize printer). PA-J670 SERIES USER MANUAL Page: 3-27...
  • Page 120 Initial Value n = 0 [Description] This command specifies international characters according to n values. Character Set France Germany Denmark I Sweden Italy Spain Japan Norway Denmark II Spain II Latin America Korea Russia Slavonic User Define PA-J670 SERIES USER MANUAL Page: 3-28...
  • Page 121 GS $ :Specify absolute position for character vertical direction in page Mode GS \: :Specify relative position for character vertical direction in page mode  Standard mode is selected when the power is turned on, the printer is reset or initialized (ESC @). PA-J670 SERIES USER MANUAL Page: 3-29...
  • Page 122  This command only affects printing in standard mode.  In page mode, this command is only effective for the setting.  This command is effective for ANK and Chinese characters. PA-J670 SERIES USER MANUAL Page: 3-30...
  • Page 123  If (vertical starting position + printing area height) exceeds the printable area, the printing area height is automatically set to (vertical printable area - [Description] vertical starting position). (X, Y) Paper Print Region (X+Dx-1, Y+Dx-1) PA-J670 SERIES USER MANUAL Page: 3-31...
  • Page 124 This command specifies position alignment for all data in one line in standard mode, using n as follows: Alignment Left alignment [Description] Center alignment Right alignment This command has no effect in page mode. PA-J670 SERIES USER MANUAL Page: 3-32...
  • Page 125 Selects the paper out detector to stop printing when paper has run out. Function “0” “1” Undefined Undefined Undefined [Description] Undefined Undefined Undefined Paper roll near end detector Invalid Valid Paper roll near end detector Invalid Valid PA-J670 SERIES USER MANUAL Page: 3-33...
  • Page 126 This command executes a full cut of the paper in standard mode ESC m [Name] Partial cut. ASCII [Format] Hex. Decimal [Range] This command executes a partial cut of the paper with one point uncut in [Description] standard mode. PA-J670 SERIES USER MANUAL Page: 3-34...
  • Page 127 Hex. Decimal 0 ≤ n ≤ 8 [Range] Initial Value n = 0 Select page n of the character code table. Character set CP-437 Katakana CP-850 CP-852 [Description] CP-860 CP-863 CP-865 CP-1252 User Define PA-J670 SERIES USER MANUAL Page: 3-35...
  • Page 128  NV bit image is a bit image defined in non-volatile memory by FS q and printed by this command.  This command is ignored when the specified NV bit image n is undefined. PA-J670 SERIES USER MANUAL Page: 3-36...
  • Page 129 8 dots. For xL = 64, xH = 0, yL = 96, yH = 0 (xL+xHx256) x8dot = 512 dots d1 d97 d49057 d2 d98 [Description] d49058 (yL+yHx256) x8dot = 768 dots d49152 PA-J670 SERIES USER MANUAL Page: 3-37...
  • Page 130 4 times 5 times 6 times 7 times 8 times Table 2 [Enlarged in vertical direction] Decimal Enlargement 1 time(standard) 2 times 3 times 4 times 5 times 6 times 7 times 8 times PA-J670 SERIES USER MANUAL Page: 3-38...
  • Page 131 [(nL + nH x 256) x basic [Description] calculated pitch] from the starting point.  When not in page mode, this command is ignored.  Specifications for absolute positions that exceed the specified print range are ignored. PA-J670 SERIES USER MANUAL Page: 3-39...
  • Page 132 0. X x 8 dot d1 dy+1 dyx2+1 [Description] d2 dy+2 dyx2+2 y x 8 dot d2 dyx2 dyx3 dx x y x8 PA-J670 SERIES USER MANUAL Page: 3-40...
  • Page 133 Basic sheet (paper roll) [Description] 1 , 49 Paper Roll 2 , 50 m specifies a test pattern.. Type of Test Print 2 , 50 Printer Status (Self Print) 3 , 51 Rolling Pattern Print PA-J670 SERIES USER MANUAL Page: 3-41...
  • Page 134 This command prints the downloaded bit image defined by GS * according to the mode denoted by m. Vertical dot Horizontal dot Mode [Description] density(DPI) density(DPI) 0 , 48 Normal 1 , 49 Double-width 2 , 50 Double-height 3 , 51 Quadruple PA-J670 SERIES USER MANUAL Page: 3-42...
  • Page 135 Selects the printing position of HRI characters when printing bar codes. Printing Position 0, 48 No print [Description] 1, 49 Above bar code 2, 50 Below bar code 3, 51 Above and below bar code(both) PA-J670 SERIES USER MANUAL Page: 3-43...
  • Page 136 Initial Value (nL + nH x 256)=0 (nL=0, nH=0) nL and nH set the specified left margin. The left margin is [(nL + nH x 256) x basic calculated pitch]. Printable area [Description] Left margin Printing area width PA-J670 SERIES USER MANUAL Page: 3-44...
  • Page 137 Feeds paper to (cutting position + [n x basic calculated pitch]) and performs a full cut Feeds paper to (cutting position + [n x basic calculated pitch]) and performs a partial cut (one point uncut) PA-J670 SERIES USER MANUAL Page: 3-45...
  • Page 138 [(nL + nH x 256) x basic calculated pitch] for the next data expanding starting position.  When not in page mode, this command is ignored. PA-J670 SERIES USER MANUAL Page: 3-46...
  • Page 139 Not used. Fixed to Off Second byte (printer information) Off/On Decimal Function Not used. Fixed to Off Not used. Fixed to Off Not used. Fixed to Off Not used. Fixed to Off Not used. Fixed to Off PA-J670 SERIES USER MANUAL Page: 3-47...
  • Page 140 Black mark sensor status Not used. Fixed to Off Not used. Fixed to Off Not used. Fixed to On Not used. Fixed to On Not used. Fixed to On Not used. Fixed to On PA-J670 SERIES USER MANUAL Page: 3-48...
  • Page 141 Selects Font B (9 x 17). GS h n [Name] Set bar code height. [Format] ASCII Hex. Decimal 104 n 1 ≤ n ≤ 255 [Range] Initial Value n = 162 [Description] Sets bar code height to n dots. PA-J670 SERIES USER MANUAL Page: 3-49...
  • Page 142 48 ≤ d ≤ 57, 65 ≤ d ≤ 68, CODABAR 36, 43, 45, 46, 47, 58 1 ≤ n ≤ 255 0 ≤ d ≤ 127 CODE93 2 ≤ n ≤ 255 0 ≤ d ≤ 127 CODE128 PA-J670 SERIES USER MANUAL Page: 3-50...
  • Page 143 Paper roll near end detector Has Paper Paper out [Description] Drawer Kick Connector Status (n=2,50) Status “0” “1” Fixed at 0 Undefined Undefined Fixed at 0 Undefined Undefined Undefined Drawer kick connector pin “L” “H” PA-J670 SERIES USER MANUAL Page: 3-51...
  • Page 144 (yL + yH x 256) in bytes. [Ex.:] When xL + xH x 256 = 64 [Description] (xL+xHx256) x 8dot = 512 dot .... (yL + yH x 256) dot 7 6 5 4 3 2 1 0 PA-J670 SERIES USER MANUAL Page: 3-52...
  • Page 145 2 ≤ n ≤ 16 [Range] Initial Value n = 2 Specifies a module size of QR Code and Data Matrix. [Description] n: The number of dots for one side of the module size. PA-J670 SERIES USER MANUAL Page: 3-53...
  • Page 146 Mode Numerical mode Alphanumeric mode 8-bit byte mode Kanji mode Mixed mode nl, nh: Specifies the number of data. Data: Kanji data of the QR Code data should be set by Shift JIS code. PA-J670 SERIES USER MANUAL Page: 3-54...
  • Page 147 Batch specifies the Kanji character print mode. Function “0” “1” Underline Undefined Undefined Undefined Double tall expanded Expanded wide Undefined Undefined FS & [Name] Select Kanji character mode. ASCII & [Format] Hex. Decimal [Range] [Description] Specifies Kanji character mode. PA-J670 SERIES USER MANUAL Page: 3-55...
  • Page 148 Initial Value n1 = 0, n2=0 Sets the Kanji character space amount and right space amount.  Left space amount: n1 x (basic calculated pitch) [Description]  Right space amount: n2 x (basic calculated pitch) PA-J670 SERIES USER MANUAL Page: 3-56...
  • Page 149 Specifies or cancels quadruple size Kanji character.  Cancels quadruple size when n = <*******0>B. [Description]  Specifies quadruple size when n = <*******1>B.  n is effective only when it is the lowest bit. PA-J670 SERIES USER MANUAL Page: 3-57...

  • Page 150: 3.11 Api

    Chapter 3 Software Utilities 3.11 API 3.11.1 API Package Content You can find the enclosed API Package files in the Protech Manual / Driver DVD. Depending on the machine types, the API Package may include the following files: Function DLL Directory...

  • Page 151: Api Procedure

    End if ‘========================================= Receive_Status2 = CashDrawerOpen(&H2) If Receive_Status2 = true then Text2.text = “cash drawer2 open” ‘enter text into textbox. Else Text2.text = “cash drawer2 close” ‘enter text into textbox. End if ‘========================================= End sub PA-J670 SERIES USER MANUAL Page: 3-59...
  • Page 152 Open cash drawer1 PortAccess.CashDrawerOpen(0x01); //check cash drawer1 status Open cash drawer2 PortAccess.CashDrawerOpen(0x02); //check cash drawer2 status Bool bstatus; bstatus = PortAccess.GetCashDrawerStatus(0x01); bstatus = PortAccess.GetCashDrawerStatus(0x02); //Before get cash drawer status, need to initial cash drawer first Page: 3-60 PA-J670 SERIES USER MANUAL...
  • Page 153 As Boolean ======================================================== VB 6 external function: Declare Function CashDrawerOpen Lib "CashDrawer.dll" (ByVal num_drawer As Integer) As Boolean Declare Function GetCashDrawerStatus Lib "CashDrawer.dll" (ByVal num_drawer As Integer) As Boolean Note: VB.net short = integer VB6 PA-J670 SERIES USER MANUAL Page: 3-61...

  • Page 154: Cash Drawer

    Cash Drawer Status Cash drawer status will be displayed after OPEN is tapped. • Cash Drawer is closed when the following picture is shown: • Cash Drawer is opened when the following picture is shown: Page: 3-62 PA-J670 SERIES USER MANUAL...

  • Page 155: Watchdog Timer

    • START: Tap to start the watchdog timer. Meanwhile, the REFRESH and STOP buttons will be enabled. • STOP: Tap to stop the watchdog timer. • REFRESH: Tap to restart the watchdog timer. PA-J670 SERIES USER MANUAL Page: 3-63...
  • Page 156 Chapter 3 Software Utilities 3.11.5 Hardware Monitor Button/Item Description Tap to get the hardware monitoring values, such as the Monitor voltages, temperatures, and fan speeds (rpm). Page: 3-64 PA-J670 SERIES USER MANUAL...
  • Page 157 Chapter 3 Software Utilities 3.11.6 I-Button Button/Item Description Tap to get the i-Button data that will be displayed below Monitor the IBUTTON DATA field. PA-J670 SERIES USER MANUAL Page: 3-65...

  • Page 158: Hardware Monitor

    = 1 (Get the Cash Drawer1 status) num_drawer = 2 (Get the Cash Drawer2 status) Return: True (1) on success, False (0) on failure Example: Short data; data= GetCashDrawerStatus(0x01); // Get the Cash Drawer1 status if (data) Page: 3-66 PA-J670 SERIES USER MANUAL...

  • Page 159: Watch Dog Function

    Stop the watchdog timer Value None Return: True (1) on success, False (0) on failure Watchdog_Recount bool Watchdog_Recount (void); Purpose: Restart the watchdog timer Value None Return: True (1) on success, False (0) on failure PA-J670 SERIES USER MANUAL Page: 3-67...

  • Page 160: Hardware Monitor Function

    +5VIN 5VCC 0x05 +12VIN VIN1 +12V VIN1 0x06 -12VIN VIN2 VIN2 0x07 -5VIN VIN3 VoltType 81866 0x01 VCore 0x02 VCC12 0x03 VCC5 0x04 5VSB 0x05 0x06 0x07 Return: Float type data on voltage value Page: 3-68 PA-J670 SERIES USER MANUAL...
  • Page 161 Value FanType W83627HF W83627EHF SMSC3114 W83627UHG Fan1 SysFanIN FAN1 FAN1 0x01 0x02 Fan2 CPUFANIN FAN2 FAN2 0x03 AUXFANIN FanType 81866 Fan1 0x01 0x02 Fan2 0x03 Return: Float type data on fan speed value (rpm) PA-J670 SERIES USER MANUAL Page: 3-69...

  • Page 162: I-Button Function

    Chapter 3 Software Utilities 3.12.4 I-Button Function Decode_Ibutton_Process bool Decode_Ibutton_Process(short[] buffer); Purpose: Get the i-Button data. Value Buffer = i-Button read will sent to this buffer Return: True (1) on success, False (0) on failure Page: 3-70 PA-J670 SERIES USER MANUAL...
  • Page 163 The BIOS Setup Utilities consist of the following menu items: • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu PA-J670 SERIES USER MANUAL Page: 4-1...
  • Page 164 Chapter 4 BIOS Setup Introduction The system PA-J670 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 165 Setup program. In a moment, the main menu of the Aptio Setup Utility will appear on the screen: PA-J670 SERIES USER MANUAL Page: 4-3...
  • Page 166 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. Page: 4-4 PA-J670 SERIES USER MANUAL...
  • Page 167 Displays the TXE firmware version. No changeable options Displays the GOP driver version. Set the current date. The “Day” is System Date month, day, year automatically changed. System Time hour, minute, second Set the clock of the system. PA-J670 SERIES USER MANUAL Page: 4-5...
  • Page 168 Enables system to wake from S5 using S5 RTC Wake Settings Sub Menu RTC alarm. CPU Configuration Sub Menu CPU Configuration Parameters. Network Stack Sub Menu Network Stack Settings. Configuration USB Configuration Sub Menu USB Configuration Parameters. Page: 4-6 PA-J670 SERIES USER MANUAL...
  • Page 169 State of Security Device. Platform - Disabled Enables or Disables Platform Hierarchy Hierarchy - Enabled (Default) Storage - Disabled Enables or Disables Storage Hierarchy Hierarchy - Enabled (Default) PA-J670 SERIES USER MANUAL Page: 4-7...
  • Page 170 - TPM 1.2 TPM 2.0 devices, Auto will support both Device Select - TPM 2.0 with the default set to TPM 2.0 devices if - Auto (Default) not found, TPM 1.2 devices will be enumerated Page: 4-8 PA-J670 SERIES USER MANUAL...
  • Page 171 (OS/S4 Sleep State). This option Hibernation (S4) - Enabled (Default) may be not effective with some OSes. Enable Sleep - Disabled Enables or Disables System ability to Sleep (S3) - Enabled (Default) (OS/S3 Sleep State.) PA-J670 SERIES USER MANUAL Page: 4-9...
  • Page 172 Configures the parameters of Serial Port 2 Sub Menu Configuration (COMC). Serial Port 3 Configures the parameters of Serial Port 3 Sub Menu Configuration (COMA). Serial Port 4 Configures the parameters of Serial Port 4 Sub Menu Configuration (COMD). Page: 4-10 PA-J670 SERIES USER MANUAL...
  • Page 173 Change Settings settings will be reflected on - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; this setup page after system - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; restarts. - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - Ring (Default) COM Voltage - 12V COM Voltage Selection - 5V PA-J670 SERIES USER MANUAL Page: 4-11...
  • Page 174 Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; settings will be reflected on this - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; setup page after system restarts. - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; - Ring (Default) COM Voltage - 12V COM Voltage Selection - 5V Page: 4-12 PA-J670 SERIES USER MANUAL...
  • Page 175 Allows users to change the - IO=3F8h; IRQ=3,4,5, 6,7,9,10,11,12; device resource settings. New Change Settings settings will be reflected on this - IO=2F8h; IRQ=3,4,5, 6,7,9,10,11,12; - IO=3E8h; IRQ=3,4,5, 6,7,9,10,11,12; setup page after system restarts. - IO=2E8h; IRQ=3,4,5, 6,7,9,10,11,12; PA-J670 SERIES USER MANUAL Page: 4-13...
  • Page 176 Allows users to change the - IO=3F8h; IRQ=3,4,5, 6,7,9,10,11,12; device resource settings. New Change Settings - IO=2E8h; IRQ=3,4,5, 6,7,9,10,11,12; settings will be reflected on this - IO=2F0h; IRQ=3,4,5, 6,7,9,10,11,12; setup page after system restarts. - IO=2E0h; IRQ=3,4,5, 6,7,9,10,11,12; Page: 4-14 PA-J670 SERIES USER MANUAL...
  • Page 177 Displays the voltage level of VCC5V in VCC5V No changeable options supply. Displays the voltage level of VSB5V in VSB5V No changeable options supply. Displays the voltage level of VBAT in VBAT No changeable options supply. PA-J670 SERIES USER MANUAL Page: 4-15...
  • Page 178 Duty Cycle 2 - 70 (Default) temperature by different duty cycle 1-100. Auto fan speed control. Fan - Numeric speed will follow different Temperature 3 - 40 (Default) temperature by different duty cycle 1-100. Page: 4-16 PA-J670 SERIES USER MANUAL...
  • Page 179 Temperature 4 - 30 (Default) temperature by different duty cycle 1-100. Auto fan speed control. Fan - Numeric speed will follow different Duty Cycle 4 - 30 (Default) temperature by different duty cycle 1-100. PA-J670 SERIES USER MANUAL Page: 4-17...
  • Page 180 BIOS Setting Options Description/Purpose Enable - Enabled (Default) Enables/Disables F81966 Watchdog timer WatchDog - Disabled settings. Watchdog Timer - Numeric Selects count of watchdog timer. Watchdog Count - 10 (Default) Timer = 1sec * Count Page: 4-18 PA-J670 SERIES USER MANUAL...
  • Page 181 (Default) Wake system • Fixed Time: system will wake on the - Fixed Time from S5 hr:min:sec specified. - Dynamic Time • Dynamic Time: System will wake on the current time + Increased minute(s) PA-J670 SERIES USER MANUAL Page: 4-19...
  • Page 182 Description/Purpose Selects 0-23. For example, enter 3 for Wake up hour Numeric 3 am and 15 for 3pm. Wake up minute Numeric Selects 0-59 for Minute. Wake up second Numeric Selects 0-59 for Second. Page: 4-20 PA-J670 SERIES USER MANUAL...
  • Page 183 Chapter 4 BIOS Setup 4.4.6.2 S5 RTC Wake Setting- Dynamic Time Figure 4-18. S5 RTC Wake Setting Screen – Dynamic Time BIOS Setting Options Description/Purpose Wake up minute increase Numeric Selects 1 – 5. PA-J670 SERIES USER MANUAL Page: 4-21...
  • Page 184 When enabled, a VMM (Virtual Machine Intel - Disabled Monitor) can utilize the additional Virtualization - Enabled (Default) hardware capabilities provided by Technology Vanderpool Technology (VT). - Disabled (Default) VT-d Enables or Disables VT-d function. - Enabled Page: 4-22 PA-J670 SERIES USER MANUAL...
  • Page 185 L1 Data Cache No changeable options L1 Data Cache size. L1 Code Cache No changeable options L1 Code Cache size. L2 Cache No changeable options L2 Cache size. L3 Cache No changeable options L3 Cache size. PA-J670 SERIES USER MANUAL Page: 4-23...
  • Page 186 Chapter 4 BIOS Setup 4.4.7.2 CPU Configuration - CPU Power Management Figure 4-21. CPU Power Management Screen BIOS Setting Options Description/Purpose - Disabled EIST Enables or Disables Intel SpeedStep. - Enabled (Default) Page: 4-24 PA-J670 SERIES USER MANUAL...
  • Page 187 Wait time to press ESC key to abort the Numeric (from 0 to 5) time PXE boot. Media detect Numbers of times presence of media will Numeric (from 1 to 50) count be checked. PA-J670 SERIES USER MANUAL Page: 4-25...
  • Page 188 Chapter 4 BIOS Setup 4.4.9 USB Configuration Figure 4-23. USB Configuration Screen BIOS Setting Options Description/Purpose USB Mass - Disabled Enables or Disables USB Mass Storage Storage Driver - Enabled (Default) Driver Support. Support Page: 4-26 PA-J670 SERIES USER MANUAL...
  • Page 189 Chapter 4 BIOS Setup Chipset Figure 4-24. Chipset Menu Screen BIOS Setting Options Description/Purpose North Bridge Sub Menu North Bridge Parameters. South Cluster Sub Menu South Cluster Configuration. Configuration PA-J670 SERIES USER MANUAL Page: 4-27...
  • Page 190 BIOS Setting Options Description/Purpose Total Memory No changeable options Displays the Total Memory. Memory Speed No changeable options Displays the speed of Memory. Memory Slot1 No changeable options Displays the size of Slot 1. Page: 4-28 PA-J670 SERIES USER MANUAL...
  • Page 191 HD-Audio Configuration Settings Configuration LPSS Sub Menu LPSS Configuration Settings. Configuration PCI Express Sub Menu PCI Express Configuration Settings. Configuration SATA Drives Sub Menu SATA Device Configuration Settings. Miscellaneous Sub Menu Miscellaneous Configurations Settings. Configurations PA-J670 SERIES USER MANUAL Page: 4-29...
  • Page 192 Chapter 4 BIOS Setup 4.5.2.1 South Cluster Configuration - HD-Audio Configuration Figure 4-27. HD-Audio Configuration Screen BIOS Setting Options Description/Purpose - Disabled Enables or Disables HD-Audio HD-Audio Support - Enabled (Default) Support. Page: 4-30 PA-J670 SERIES USER MANUAL...
  • Page 193 Chapter 4 BIOS Setup 4.5.2.2 South Cluster Configuration - LPSS Configuration Figure 4-28. LPSS Configuration Screen BIOS Setting Options Description/Purpose LPSS I2C #6 Support - Disabled (Default) Enables or Disables LPSS I2C #6 (D23:F1) - Enabled Support. PA-J670 SERIES USER MANUAL Page: 4-31...
  • Page 194 South Cluster Configuration - LPSS Configuration - Enable Figure 4-29. LPSS Configuration Screen (Enable) BIOS Setting Options Description/Purpose - Standard Mode - Fast Mode (Default) Set I2C2 Speed Selects LPSS I2C #6 Speed. - Fast Plus Mode - High Speed Mode Page: 4-32 PA-J670 SERIES USER MANUAL...
  • Page 195 Options Description/Purpose PCI Express Root Port 3 PCI Express Root Port 5 (I211 LAN) Sub Menu (I210 LAN) Settings. PCI Express Root Port 4 PCI Express Root Port 1 M.2) Sub Menu (M.2) Settings. PA-J670 SERIES USER MANUAL Page: 4-33...
  • Page 196 Auto: Disables unused root port - Disable PCI Express Root Port 3 automatically for the most - Enable (Default) (I211 LAN) optimum power savings. - Auto • Enable: Enables PCIe root port. • Disable: Disables PCIe root port. Page: 4-34 PA-J670 SERIES USER MANUAL...
  • Page 197 Auto: Disables unused root port - Disable automatically for the most PCI Express Root Port 4 (M.2) - Enable (Default) optimum power savings. - Auto • Enable: Enables PCIe root port. • Disable: Disables PCIe root port. PA-J670 SERIES USER MANUAL Page: 4-35...
  • Page 198 Enables or Disables SATA Port 0 - Enabled (Default) Displays the connected device on SATA Port 1 No changeable options SATA Port 1 - Disabled Port 1 Enables or Disables SATA Port 1 - Enabled (Default) Page: 4-36 PA-J670 SERIES USER MANUAL...
  • Page 199 - S5 State (Default) applied. • S5 State: System will remain at power-off state until the power button is pressed. - Disable Wake On Lan Enables or Disables the Wake on Lan. - Enable (Default) PA-J670 SERIES USER MANUAL Page: 4-37...
  • Page 200 Security Figure 4-35. Security Menu Screen BIOS Setting Options Description/Purpose Administrator Password can be 3-20 Specifies the administrator password. Password alphanumeric characters. Password can be 3-20 User Password Specifies the user password. alphanumeric characters. Page: 4-38 PA-J670 SERIES USER MANUAL...
  • Page 201 Specifies the power-on state of the NumLock State - Off NumLock Key. - Disabled (Default) Quiet Boot Enables or Disables Quiet Boot Options - Enabled Boot Option - [Drive(s)] Sets the system boot order. #1~#n - Disabled PA-J670 SERIES USER MANUAL Page: 4-39...
  • Page 202 Saves the changes done so far as User No changeable options Defaults Defaults. Restore User Restores the User Defaults to all the setup No changeable options Defaults options. Boot Override - [Drive(s)] Forces to boot from selected [drive(s)]. Page: 4-40 PA-J670 SERIES USER MANUAL...
  • Page 203 Appendix A System Diagrams This appendix includes the easy maintenance diagrams, exploded diagrams and part numbers of PA-J670 system components. The following topics are included: • Easy Maintenance Hard Drive  Memory  Main Board  • Exploded Diagrams for Panel PC •...
  • Page 204 HDD fixing screws Step 2. Pull out HDD tray Easy Stand Step 1. Lay down System on a flat as under drawing Step 2. Unassemble the HDD fixing screws Step 3. Pull out HDD tray Page: A-2 PA-J670 SERIES USER MANUAL...
  • Page 205 Pull out HDD tray Step 2. Unassemble the HDD fixing screws Printer Stand Step 1. To adjust LCD angle to zero degrees Step 3. Pull out HDD tray Step 2. Unassemble the HDD fixing screws PA-J670 SERIES USER MANUAL Page: A-3...
  • Page 206 Appendix A System Diagrams Easy Maintenance - Memory Step 1. Set the Panel PC and Stand apart from each other. Page: A-4 PA-J670 SERIES USER MANUAL...
  • Page 207 Appendix A System Diagrams Step 2. Release 2 screws ○ Step 3. Follow arrow direction to remove back cover ○ PA-J670 SERIES USER MANUAL Page: A-5...
  • Page 208 Appendix A System Diagrams Step 4. Memory could be taken out. Page: A-6 PA-J670 SERIES USER MANUAL...
  • Page 209 Easy Maintenance - Mainboard Step 1. Pull out all cables which are connected on M/B and then release the fixing screws on M/B. Step 2. Follow the arrow direction to remove the Main Board. PA-J670 SERIES USER MANUAL Page: A-7...
  • Page 210 Appendix A System Diagrams Exploded Diagrams for Panel PC LCD Panel Display Exploded Diagram ITEM Description Part No. Q’ty PA-J670 LCD Holder Module 20-029-03001497 15" LCD Panel (LED backlight), 300nits, 52-351-03150321 XGA (1024x768) SPONGE (341.9x8x0.5 mm) 30-013-24100000 Thermal Interface Pads, K=6.2,...
  • Page 211 Resistive Flat Touch Panel Exploded Diagram ITEM Description Part No. Q’ty 15" Flat Resistive Touch Panel 52-380-00062401 PA-J670 Front Cover-A (FLAT TP) 30-002-28112353 (Black) PA-3251 Double Coated Tape B 94-026-04902220 PA-3251 Double Coated Tape A 94-026-04901220 PA-J670 SERIES USER MANUAL...
  • Page 212 Appendix A System Diagrams Projected Capacitive Flat Touch Panel Exploded Diagram BOM: Capacitive Flat_TP_module_Assy ITEM Description Part No. Q’ty 15" Projected Capacitive Touch Panel 52-380-00543901 PA-J670 Front Cover (FLAT TP) (Black) 30-002-28310353 Page: A-10 PA-J670 SERIES USER MANUAL...
  • Page 213 3.5mm Phone Jack (Mic) VGA Cable (DB15F to 16F/P2.0) 27-017-49706031 L=300mm PT-2070 Power Switch Cable L=400mm 27-019-33908071 PA-J670 1-Port USB Cable L=280mm 27-006-35306111 PA-6222/6225 Speaker Cable L=250mm 27-021-33505071 Fillister Head Screw #1 / M2x0.4Px4mm 22-272-20004011 Flat Head Screw #2 / UNC-No.4-40, 22-315-40008019 L=8mm, FLAT=1.0mm...
  • Page 214 Part No. Q’ty HEX CU BOSS UNC No.4-40, L=4.8, 22-692-40048051 H=7mm Round Head with Spring Washer Screw 22-232-30060211 M3x0.5Px6mm SE-8134 SATA HDD & Power Cable 27-008-40103081 L=100mm Fillister Head Screw #2 / M3x0.5Px6mm 82-275-30006018 Page: A-12 PA-J670 SERIES USER MANUAL...
  • Page 215 Appendix A System Diagrams Resistive Touch Panel Module Exploded Diagram ITEM Description Part No. Q’ty Resistive_Flat_TP_Assy Panel-MB-module_sub-assembly PA-8525 LED Lens (Transparency) 30-021-02130343 Round Washer Head Screw #1 / 22-132-20004011 T2.0x4mm Pan Head Screw T3.0x6mm 22-132-30060011 PA-J670 SERIES USER MANUAL Page: A-13...
  • Page 216 PA-8525 LED Lens (Transparency) 30-021-02130343 Round Washer Head Screw #1 / 22-132-20004011 T2.0x4mm Pan Head Screw T3.0x6mm 22-132-30060011 Fillister Head Screw #2 / M3x0.5Px4mm 82-272-30004018 PA-6980 Capacitive Touch Cable 27-016-37704111 (5p to 5p) L=155mm Page: A-14 PA-J670 SERIES USER MANUAL...
  • Page 217 Appendix A System Diagrams Front Cover Exploded Diagram ITEM Description Part No. Q’ty PA-J670 Back Cover-2 (Black) 30-002-28111353 PA-J670 MSR Cover (Black) 30-002-28510353 PA-J670 EVA (90x25x1mm) 30-013-15100497 PA-J670 EVA (390x4x0.5mm) 30-013-15300497 PA-J670 Waterproof Membrane for 30-083-25100497 Speaker Holes PA-J670 USB Cover (Black)
  • Page 218 ITEM Description Part No. Q’ty Front_module_sub-assembly Back-cover-module_sub-assembly Flat Head Screw #2 / M3x0.5Px5mm 22-215-30005011 Fillister Head Screw #2 / M3x0.5Px6mm 22-275-30006011 Fillister Head Screw #2 / M3x0.5Px6mm 82-275-30006018 Flat Head Screw M3x0.5Px6mm (Black) 22-215-30060011 Page: A-16 PA-J670 SERIES USER MANUAL...
  • Page 219 Appendix A System Diagrams HDD Module Exploded Diagram ITEM Description Part No. Q’ty PA-J670 PPC Sub-assembly HDD or SSD PA-J670 HDD Tray 20-054-03001353 Flat Head Screw #2 / M3x0.5Px4mm 22-215-30004311 Round Washer Head Screw 22-242-30005311 M3x0.5Px5mm PA-J670 SERIES USER MANUAL Page: A-17...
  • Page 220 Appendix A System Diagrams Cable Cover Exploded Diagram ITEM Description Part No. Q’ty PA-J670 PPC Sub-assembly PA-J670 AL Cover-1 (w/Paint) (Black) 20-004-01062353 PA-J670 Cable Cover (Black) 30-002-28210353 Flat Head Screw #2 / M3x0.5Px5mm 22-215-30005011 Fillister Head Screw #2 / M3x0.5Px6mm...
  • Page 221 Appendix A System Diagrams Power Adaptor Holder Exploded Diagram ITEM Description Part No. Q’ty PA-J670 PPC assembly PA-J670 Adaptor Holder 60W (w/Paint) 20-029-02061497 (Black) 60W AC to DC 24V/2.5A Power Adaptor 52-002-10683002 Flat Head Screw #2 / M4x0.7Px6mm 22-215-40006011 (Black)
  • Page 222 Appendix A System Diagrams Option_COM4 Kit ITEM Description Part No. Q’ty Back_cover_module Modular_Coupler_Jack 10-085-10012035 COM_To_RJ45_Cable 27-051-35305031 Washer 23-312-30080081 Round Washer Head Screw 22-242-30005311 Option_Printer Power Port Kit Page: A-20 PA-J670 SERIES USER MANUAL...
  • Page 223 Q’ty PRINT_PWR_Cable 27-012-35304111 DC_Jack_Holder 80-029-03001353 DC_Jack_Plate 80-005-03001353 EVA_Sponge 90-013-15100314 Flat Head Screw 22-212-30005311 Option_RFID Board Kit ITEM Description Part No. Q’ty MB_Module_ASSY RFID_Antenna_PCB 27-068-31002111 RFID_Bracket Round Washer Head Screw 22-242-30005311 Fillister Head Screw 22-272-20003011 PA-J670 SERIES USER MANUAL Page: A-21...
  • Page 224 Appendix A System Diagrams Exploded Diagrams for Stand Easy Stand ITEM Description Part No. Q’ty PA-J670_PPC PA-J670_Stand_module Fillister Head Screw 22-272-40004911 Round Head Screw 22-245-40012031 Page: A-22 PA-J670 SERIES USER MANUAL...
  • Page 225 Appendix A System Diagrams ITEM Description Part No. Q’ty Stand Cover (Black) 30-002-28610353 Hinge Base 20-032-21001353 Silicone Rubber 90-013-06100353 EVA_Stand 90-013-15300353 Flat Head Screw 22-112-40007015 PA-J670 SERIES USER MANUAL Page: A-23...
  • Page 226 Description Part No. Q’ty Stand Holder (Black) 20-029-01061353 PA-6225 Stand Hinge L 20-012-29001314 Hinge Fix Bracket 2 20-006-21002353 Stand Holder Cover (Black) 30-002-28710353 Silicone Rubber 90-013-06100353 Round Head Screw 22-232-50015011 Flat Head Screw 22-215-30006311 Page: A-24 PA-J670 SERIES USER MANUAL...
  • Page 227 Appendix A System Diagrams ITEM Description Part No. Q’ty Stand_cover_module Stand_holder_module Hinge Fix Bracket_1 20-006-21001353 Round Head Screw 22-232-50015011 PA-J670 SERIES USER MANUAL Page: A-25...
  • Page 228 Appendix A System Diagrams Normal Stand ITEM Description Part No. Q’ty PA-J670_PPC_Module PA-6151_Rotate_Module PA-6151_Stand_Module RW_Screw_M3_L15mm 22-235-30015011 Page: A-26 PA-J670 SERIES USER MANUAL...
  • Page 229 Appendix A System Diagrams Rotation Part (1) PA-J670 SERIES USER MANUAL Page: A-27...
  • Page 230 Appendix A System Diagrams ITEM Description Part No. Q’ty POS-6920_Rotate_Support 80-002-03003226 L_Support 80-002-03002226 R_Support 80-002-03001226 POS-6920_Pipe 80-056-02001226 Washer_ID_8.5_OD_24 23-202-09150247 POS-6920_Rotate_Cover 30-002-28610226 PS5000_Hinge_Spacer 30-041-04100139 HEX_Screw_M8_L154mm 22-252-80154005 Plain_Washer_D8_D19_T1.5 23-202-08150191 HEX_Nuts_M8_L7.85mm 23-142-80081291 Flat_Screw_T4_L7mm 22-112-40007015 Silicon Rubber Pad 90-036-06200226 Page: A-28 PA-J670 SERIES USER MANUAL...
  • Page 231 Appendix A System Diagrams Bottom Case (1) PA-J670 SERIES USER MANUAL Page: A-29...
  • Page 232 Appendix A System Diagrams ITEM Description Part No. Q’ty POS-6920-Stand-Cover 30-002-28710226 POS-6920-Stand-Base 80-032-03001226 Rubber Foot 30-004-01600000 Tapping Screw T3.0x8mm 22-122-30080011 R_S_Screw, M4.0x0.7Px8mm 22-232-40008211 R_S_Screw, M3.0x0.5Px6mm 22-232-30006311 POS-6920_Rotate_Module 60W Power Adaptor 52-002-10068302 PA-6970 Power Holder 80-029-03001253 Page: A-30 PA-J670 SERIES USER MANUAL...
  • Page 233 Appendix A System Diagrams Big Stand ITEM Description Part No. Q’ty PA-J670_PPC_Module PA-6225_Rotate_Module PA-6225_Stand_Module RW_Screw_M3_L15mm 22-235-30015011 PA-J670 SERIES USER MANUAL Page: A-31...
  • Page 234 Appendix A System Diagrams Rotation Part (2) ITEM Description Part No. Q’ty Rotate Base assembly Hinge-Fixing 80-012-03001314 Screw / M5x0.8Px15mm 22-232-50015011 Stand Rotate Cover 30-002-28410314 Screw / M3x0.5Px12mm 22-275-30010011 Page: A-32 PA-J670 SERIES USER MANUAL...
  • Page 235 Appendix A System Diagrams ITEM Description Part No. Q’ty Rotate-Base 20-032-03001314 Rotate_Base-Sponge 30-013-24100314 Cable Clamp 90-042-04100314 Cable Clamp 30-042-04100314 M3 Screw 22-242-30005311 PA-J670 SERIES USER MANUAL Page: A-33...
  • Page 236 Appendix A System Diagrams Bottom Case (2) Page: A-34 PA-J670 SERIES USER MANUAL...
  • Page 237 Q’ty SCREW / T3.0x8mm 22-122-30080011 Rubber Foot (40x12x4mm) 30-004-01100314 HEX CU BOSS / M3x0.5Px6L, H=15 22-290-30015051 72W Adaptor Screw / M3x0.5Px5mm 22-242-30005311 120W_Adaptor_Bracket 80-029-03003314 No Printer cover assembly SCREW / M3x0.5Px6mm 82-275-30006018 60W_Power_Adaptor 52-002-10068302 PA-J670 SERIES USER MANUAL Page: A-35...
  • Page 238 Appendix A System Diagrams Page: A-36 PA-J670 SERIES USER MANUAL...
  • Page 239 90-023-04100314 Round Washer Head Screw 22-242-30005311 M3x0.5Px5mm Latch 90-023-09100000 Flat Head Screw M3x0.5Px6mm 22-212-30006011 EMI Shielding Gasket (12x10x5mm) 90-050-31100000 PS-3100 RJ11 Holder 80-029-03002165 PS-3100 Cash Drawer Cable L=250mm 27-026-16505111 Round Head Screw M2.5x0.45Px4mm 22-232-25004011 PA-J670 SERIES USER MANUAL Page: A-37...
  • Page 240 Appendix A System Diagrams ITEM Description Part No. Q’ty Stand Cover 30-002-28110314 Cable Clamp 90-023-04200314 SCREW/T3.0x8mm 22-122-30080011 Page: A-38 PA-J670 SERIES USER MANUAL...
  • Page 241 Appendix A System Diagrams Printer Stand ITEM Description Part No. Q’ty PA-J670_PPC_Module PA-6225_Rotate_Module PA-6225_Stand_Module RW_Screw_M3_L15mm 22-235-30015011 PA-J670 SERIES USER MANUAL Page: A-39...
  • Page 242 Appendix A System Diagrams Extension Power Cable ITEM Description Part No. Q’ty HEX CU BOSS/M3x0.5Px6L, H=15mm 22-290-30015051 DC IN CLIP 80-014-03001314 DC IN EXTENDED CABLE 27-012-31408111 SCRE /M3x0.5Px5mm 22-242-30005311 Page: A-40 PA-J670 SERIES USER MANUAL...
  • Page 243 Appendix A System Diagrams Exploded Diagrams for Printer Module Front view Rear view Bottom view ITEM Description Part No. Q’ty Printer Module Stand HDD Cover 30-002-02110314 SCREW/T3.0x8mm 22-122-30080011 PA-J670 SERIES USER MANUAL Page: A-41...
  • Page 244 Appendix A System Diagrams Thermal Printer Page: A-42 PA-J670 SERIES USER MANUAL...
  • Page 245 27-006-31409111 Print For USB Cable 27-006-31409112 Print For USB Cable 27-051-31408111 Print For USB Cable 27-051-31408113 Print For USB Cable 27-051-31408112 Cash Drawer Cable 27-026-16505111 option Screw / M3 x 0.5P x 10mm 22-232-30010311 PA-J670 SERIES USER MANUAL Page: A-43...
  • Page 246 Appendix A System Diagrams ITEM Description Part No. Q’ty Note S AND BRACKET ASSEMBLY RUBBER FOOT 30-004-01100314 For with STAND DRESS COVER 30-002-28510 printer S AND COVER ASSEMBLY SCREW/T3.0x8mm 22-122-30080011 Page: A-44 PA-J670 SERIES USER MANUAL...
  • Page 247 Appendix A System Diagrams Top view Bottom view Separation view PA-J670 SERIES USER MANUAL Page: A-45...
  • Page 248 Housing Assembly Screw / M3x0.5P x 6mm 82-275-30006018 Stand Printer Cover 30-002-28310314 3-Inch Printer ITEM Description Part No. Q’ty Stand Printer Housing 30-014-28110314 PS-3100 SPACER SUPPORT (Φ6x25mm) 30-041-04100165 Roller Pin 20-045-19012199 Canoe Clip (Φ2.9mm) 90-042-04100000 Page: A-46 PA-J670 SERIES USER MANUAL...
  • Page 249 Appendix A System Diagrams 3-Inch Printer Assembly Step-1: Step-2: Step-3: PA-J670 SERIES USER MANUAL Page: A-47...
  • Page 250 SCREW/M3x0.5Px5mm 22-242-30005311 3” Printer (Main body) 52-701-03017003 Front Cover Assembly Paper Cover Pin 20-004-10011165 Rotary Damper (15gf-cm) 90-022-09100314 ITEM Description Part No. Q’ty STAND PRINTER COVER_F 30-002-02210314 3” Printer (Main body) 52-701-03017003 SCREW/T3.0x5mm 22-121-30005011 Page: A-48 PA-J670 SERIES USER MANUAL...
  • Page 251 Appendix A System Diagrams 2-Inch Printer ITEM Description Part No. Q’ty Stand Printer Housing 30-014-28110314 PS-3100 SPACER SUPPORT (Φ6x25mm) 30-041-04100165 Roller Pin 20-045-19012199 Canoe Clip (Φ2.9mm) 90-042-04100000 2 Inch Printer Assembly Step-1: PA-J670 SERIES USER MANUAL Page: A-49...
  • Page 252 PDAC3100-D1 Printer Board MB-1030RB/RC Printer Board MB-1011(3)RC SCREW/M2x0.4Px4mm 22-272-20004011 PRINTER-PCB-MYALR 90-056-02100314 SCREW/M3x0.5Px5mm 22-242-30005311 2” Printer (Main body) 52-701-01020003 Front Cover Assembly Paper Cover Pin 20-004-10011165 Rotary Damper (15gf-cm) 90-022-09100314 2 inch Paper Block 30-061-28110242 Page: A-50 PA-J670 SERIES USER MANUAL...
  • Page 253 Appendix A System Diagrams ITEM Description Part No. Q’ty STAND PRINTER COVER_F 30-002-02210314 2” Printer (Main body) 52-701-01020003 SCREW/T3.0x5mm 22-121-30005011 PA-J670 SERIES USER MANUAL Page: A-51...
  • Page 254 Appendix A System Diagrams Exploded Diagrams for Peripheral Devices Vertical i-Button Kit ITEM Description Part No. Q’ty PA-J670_PPC I-button See Order I-Button_Bracket 20-006-03063353 Flat Head Screw 22-215-30005011 Round Washer Head Screw 22-235-30007011 PA-J670 SERIES USER MANUAL Page: A-52...
  • Page 255 Appendix A System Diagrams Vertical Fingerprint Only Kit ITEM Description Part No. Q’ty PA-J670_PPC Fingerprint_module Fingerprint Holder 20-029-03061353 Pan Head Screw 22-122-30080011 Flat Head Screw 22-215-30005111 Flat Head Screw 22-215-30006111 PA-J670 SERIES USER MANUAL Page: A-53...
  • Page 256 Appendix A System Diagrams Fingerprint ITEM Description Part No. Q’ty PC_Sheet Fingerprint Top Cover 30-002-12720210 Fingerprint Btm Cover 30-002-12820210 Finterprint Module 52-551-00501205 Fingerprint Bracket Fingerprint Cable Flat Head Screw 22-712-30010011 Page: A-54 PA-J670 SERIES USER MANUAL...
  • Page 257 Appendix A System Diagrams Vertical MSR & Fingerprint Kit ITEM Description Part No. Q’ty PA-J670_PPC MSR_Finger_Print_Module Fillister Head Screw 22-275-30006011 PA-J670 SERIES USER MANUAL Page: A-55...
  • Page 258 MSR Cable 27-014-27402072 MSR Housing Poron 90-013-24100314 MSR Bracket EVA-1 90-013-15400353 MSR Bracket EVA-2 90-013-15200314 MSR Bracket EVA-3 90-013-15400314 Plastic Tape 34-008-02002000 0.00015 Fillister Head Screw 22-272-30049015 Round Head Screw 22-135-30008311 Round Head Screw 22-835-30019011 Page: A-56 PA-J670 SERIES USER MANUAL...
  • Page 259 MSR Bracket EVA-2 90-013-15200314 MSR Bracket EVA-3 90-013-15400314 Plastic Tape 34-008-02002000 0.00015 Fillister Head Screw 22-272-30049015 Round Head Screw 22-135-30008311 Round Head Screw 22-835-30019011 Pan Head Screw 22-132-30060011 USB Fingerprint 52-551-00501205 Fingerprint Cable 27-004-31404112 PA-J670 SERIES USER MANUAL Page: A-57...
  • Page 260 Appendix A System Diagrams Vertical RFID, MSR, SMART Card Reader Kit Component Name P/N No. Q’ty PA-J670_PPC MSR/RFID Reader Module See Order RFID EVA 90-013-15500353 RFID_Bracket 20-006-03065353 Flat Head Screw 22-215-30006111 Fillister Head Screw 22-215-30006111 Page: A-58 PA-J670 SERIES USER MANUAL...
  • Page 261 Vertical SMART Card Reader, MSR Kit Component Name P/N No. Q’ty PA-J670_PPC MSR+Smart Card Reader See Order Smart Card EVA 90-013-15600353 Smart Card Double Adhesive 94-026-04501353 Smart Card Bracket 20-006-03064353 Round Washer Head Screw 22-235-30007011 PA-J670 SERIES USER MANUAL Page: A-59...
  • Page 262 Appendix A System Diagrams Component Name P/N No. Q’ty PA-J670_PPC MSR_Module Round_Screw_M3x14mm 22-232-30014011 Page: A-60 PA-J670 SERIES USER MANUAL...
  • Page 263 Appendix A System Diagrams MSR & i-Button / Single Head 10-4 PA-J670 SERIES USER MANUAL Page: A-61...
  • Page 264 MSR Fix Bracket 20-006-03006210 MSR_Protech_P32 MB-3012RA-12N 10-1 MSR Cable 27-014-31402071 iButton Cable 27-022-16503071 MSR_ID TECH_PS2 52-151-08333416 10-2 MSR Cable 27-014-27402072 Mylar Sheet for MSR (10-4) 30-056-02100336 MSR_SYSKING_PS2 52-551-00883000 10-3 MSR Cable 27-014-21007111 Ibutton Cable 27-022-16503071 Page: A-62 PA-J670 SERIES USER MANUAL...
  • Page 265 Twin Head MSR, RS-232, GIGA-TMS 52-551-00243100 MJR243R-10(F/W V1.01) MSR for M/B cable (PB-6722 COM4_1) MSR for to itself cable IBUTTON for M/B cable (PB-6722 I-BUT) IBUTTON for itself cable 10-1 PA-6225 Mylar Sheet for MSR 30-056-02100336 PA-J670 SERIES USER MANUAL Page: A-63...
  • Page 266 Appendix A System Diagrams Second Display Page: A-64 PA-J670 SERIES USER MANUAL...
  • Page 267 15” TFT LCD VGA Monitor See Order 2nd_Dis_Hinge_Bracket 20-006-03062353 2nd Display Hinge 20-006-03062353 Round Head Screw 22-235-30008011 Round Head Screw 22-245-40008011 2nd_Dis_Hinge_Base 20-032-03061353 Flat Head Screw 22-215-40015011 Flat Head Screw 22-215-40010011 Round Head Screw 22-245-40008011 PA-J670 SERIES USER MANUAL Page: A-65...
  • Page 268 Appendix A System Diagrams Exploded Diagrams for Packing PPC Package Exploded Diagram ITEM Description Part No. Q’ty PA-J670 EPE Top (PPC Type) 94-016-00301353 (496x183x139mm) PA-J670 EPE Bottom (PPC Type) 94-016-00302353 (496x183x172mm) PS-650X Carton Boxes 34-003-01301086 (332x150x45mm) PA-J670 PPC PA-6922 Inner Carton...
  • Page 269 Appendix A System Diagrams Easy Stand System with Packing Component Name P/N No. Q’ty EPE Right 94-016-00307353 EPE Left 94-016-00308353 Accessories Box 34-003-01301086 PA-J670 Model Outer Carton (PPC Type) 94-001-01404353 Mylar 30-056-02100008 PE Bag 32-100-20010000 PA-J670 SERIES USER MANUAL Page: A-67...
  • Page 270 Normal Stand System with Packing Component Name P/N No. Q’ty PS-650X Carton Boxes 34-003-01301086 15-IN Panel Mylar 90-056-25300000 PA-J670 Model EPE Left 94-016-00304353 EPE Right 94-016-00303353 PE Bag (850X670X0.07mm) 34-010-00210003 PA-J670 Outer Carton 94-001-01402353 Page: A-68 PA-J670 SERIES USER MANUAL...
  • Page 271 Big Stand System with Packing Component Name P/N No. Q’ty PS-650X Carton Boxes 34-003-01301086 15-IN Panel Mylar 90-056-25300000 PA-J670_model PA-J670 EPE Left 94-016-00306353 PA-J670 EPE Right 94-016-00305353 PE Bag (850x670x0.07mm) 34-010-00210003 PA-J670 Outer Carton 94-001-01403353 PA-J670 SERIES USER MANUAL Page: A-69...
  • Page 272 Exploded Diagrams for Spare Parts Easy Stand Spare Parts ITEM Description Part No. Q’ty Easy Stand Service Pack Package Bag 480x460mm 32-100-20010000 EPE Top 94-016-00311353 EPE Bottom 94-016-00312353 Inner Carton 94-002-01401353 Outer Carton 94-001-01407353 Page: A-70 PA-J670 SERIES USER MANUAL...
  • Page 273 Appendix A System Diagrams Normal Stand Spare Parts ITEM Description Part No. Q’ty Normal Stand Silica gel 34-005-00010007 Package Bag 480x460mm 32-100-20010000 EPE top 280x273x42mm 94-016-00303269 EPE bottom 280x273x42mm 94-016-00304269 Outer Carton 592x308x229mm 94-001-01403269 PA-J670 SERIES USER MANUAL Page: A-71...
  • Page 274 Appendix A System Diagrams Printer Stand Spare Parts ITEM Description Part No. Q’ty Printer Stand Package bag 480x460mm 32-100-20010000 EPE top 94-016-00309353 EPE bottom 94-016-00310353 Carton 94-010-01405353 Page: A-72 PA-J670 SERIES USER MANUAL...
  • Page 275 This appendix will give you a brief introduction of the allocation maps for the system resources. The following topics are included: • Interrupt Map • DMA Channels Map • I/O Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update PA-J670 SERIES USER MANUAL Page: B-1...
  • Page 276 IRQ 65 Microsoft ACPI-Compliant System IRQ 66 Microsoft ACPI-Compliant System IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System IRQ 71 Microsoft ACPI-Compliant System Page: B-2 PA-J670 SERIES USER MANUAL...
  • Page 277 IRQ 95 Microsoft ACPI-Compliant System IRQ 96 Microsoft ACPI-Compliant System IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System IRQ 99 Microsoft ACPI-Compliant System IRQ 100 Microsoft ACPI-Compliant System IRQ 101 Microsoft ACPI-Compliant System Page: B-3 PA-J670 SERIES USER MANUAL...
  • Page 278 IRQ 125 Microsoft ACPI-Compliant System IRQ 126 Microsoft ACPI-Compliant System IRQ 127 Microsoft ACPI-Compliant System IRQ 128 Microsoft ACPI-Compliant System IRQ 129 Microsoft ACPI-Compliant System IRQ 130 Microsoft ACPI-Compliant System IRQ 131 Microsoft ACPI-Compliant System Page: B-4 PA-J670 SERIES USER MANUAL...
  • Page 279 IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157 Microsoft ACPI-Compliant System IRQ 158 Microsoft ACPI-Compliant System IRQ 159 Microsoft ACPI-Compliant System IRQ 160 Microsoft ACPI-Compliant System IRQ 161 Microsoft ACPI-Compliant System Page: B-5 PA-J670 SERIES USER MANUAL...
  • Page 280 IRQ 185 Microsoft ACPI-Compliant System IRQ 186 Microsoft ACPI-Compliant System IRQ 187 Microsoft ACPI-Compliant System IRQ 188 Microsoft ACPI-Compliant System IRQ 189 Microsoft ACPI-Compliant System IRQ 190 Microsoft ACPI-Compliant System IRQ 191 Microsoft ACPI-Compliant System Page: B-6 PA-J670 SERIES USER MANUAL...
  • Page 281 IRQ 266 Microsoft ACPI-Compliant System IRQ 267 Microsoft ACPI-Compliant System IRQ 268 Microsoft ACPI-Compliant System IRQ 269 Microsoft ACPI-Compliant System IRQ 270 Microsoft ACPI-Compliant System IRQ 271 Microsoft ACPI-Compliant System IRQ 272 Microsoft ACPI-Compliant System Page: B-7 PA-J670 SERIES USER MANUAL...
  • Page 282 IRQ 296 Microsoft ACPI-Compliant System IRQ 297 Microsoft ACPI-Compliant System IRQ 298 Microsoft ACPI-Compliant System IRQ 299 Microsoft ACPI-Compliant System IRQ 300 Microsoft ACPI-Compliant System IRQ 301 Microsoft ACPI-Compliant System IRQ 302 Microsoft ACPI-Compliant System Page: B-8 PA-J670 SERIES USER MANUAL...
  • Page 283 IRQ 326 Microsoft ACPI-Compliant System IRQ 327 Microsoft ACPI-Compliant System IRQ 328 Microsoft ACPI-Compliant System IRQ 329 Microsoft ACPI-Compliant System IRQ 330 Microsoft ACPI-Compliant System IRQ 331 Microsoft ACPI-Compliant System IRQ 332 Microsoft ACPI-Compliant System Page: B-9 PA-J670 SERIES USER MANUAL...
  • Page 284 IRQ 356 Microsoft ACPI-Compliant System IRQ 357 Microsoft ACPI-Compliant System IRQ 358 Microsoft ACPI-Compliant System IRQ 359 Microsoft ACPI-Compliant System IRQ 360 Microsoft ACPI-Compliant System IRQ 361 Microsoft ACPI-Compliant System IRQ 362 Microsoft ACPI-Compliant System Page: B-10 PA-J670 SERIES USER MANUAL...
  • Page 285 IRQ 386 Microsoft ACPI-Compliant System IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System IRQ 389 Microsoft ACPI-Compliant System IRQ 390 Microsoft ACPI-Compliant System IRQ 391 Microsoft ACPI-Compliant System IRQ 392 Microsoft ACPI-Compliant System Page: B-11 PA-J670 SERIES USER MANUAL...
  • Page 286 IRQ 416 Microsoft ACPI-Compliant System IRQ 417 Microsoft ACPI-Compliant System IRQ 418 Microsoft ACPI-Compliant System IRQ 419 Microsoft ACPI-Compliant System IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System IRQ 422 Microsoft ACPI-Compliant System Page: B-12 PA-J670 SERIES USER MANUAL...
  • Page 287 IRQ 446 Microsoft ACPI-Compliant System IRQ 447 Microsoft ACPI-Compliant System IRQ 448 Microsoft ACPI-Compliant System IRQ 449 Microsoft ACPI-Compliant System IRQ 450 Microsoft ACPI-Compliant System IRQ 451 Microsoft ACPI-Compliant System IRQ 452 Microsoft ACPI-Compliant System Page: B-13 PA-J670 SERIES USER MANUAL...
  • Page 288 IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System IRQ 478 Microsoft ACPI-Compliant System IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System IRQ 481 Microsoft ACPI-Compliant System IRQ 482 Microsoft ACPI-Compliant System Page: B-14 PA-J670 SERIES USER MANUAL...
  • Page 289 Microsoft ACPI-Compliant System IRQ 507 Microsoft ACPI-Compliant System IRQ 508 Microsoft ACPI-Compliant System IRQ 509 Microsoft ACPI-Compliant System IRQ 510 Microsoft ACPI-Compliant System IRQ 511 Microsoft ACPI-Compliant System IRQ 1024 Intel SD Host Controller Page: B-15 PA-J670 SERIES USER MANUAL...
  • Page 290 IRQ 4294967293 Port - 5AD9 Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root IRQ 4294967294 Port - 5AD8 Note: The resource information is gathered using Windows 10 (the IRQs could be assigned differently depending on your OS). Page: B-16 PA-J670 SERIES USER MANUAL...
  • Page 291 PCI Express Root Complex 0x00000078-0x00000CF7 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller Page: B-17 PA-J670 SERIES USER MANUAL...
  • Page 292 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x0000F090-0x0000F097 Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer Page: B-18 PA-J670 SERIES USER MANUAL...
  • Page 293 Intel(R) Serial IO I2C Host Controller 0x9131A000-0x9131AFFF - 5AB6 Intel(R) Serial IO I2C Host Controller 0x91319000-0x91319FFF - 5AB6 0x7C000001-0x7FFFFFFF PCI Express Root Complex 0x7B800001-0x7BFFFFFF PCI Express Root Complex Intel(R) Trusted Execution Engine 0x91321000-0x91321FFF Interface Page: B-19 PA-J670 SERIES USER MANUAL...
  • Page 294 0xCFFFE000-0xCFFFEFFF Intel SD Host Controller 0x91314000-0x91315FFF Standard SATA AHCI Controller 0x9131E000-0x9131E0FF Standard SATA AHCI Controller 0x9131D000-0x9131D7FF Standard SATA AHCI Controller Intel(R) I210 Gigabit Network 0x91280000-0x912FFFFF Connection #2 Intel(R) I210 Gigabit Network 0x9127C000-0x9127FFFF Connection #2 Page: B-20 PA-J670 SERIES USER MANUAL...
  • Page 295 To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. Page: B-21 PA-J670 SERIES USER MANUAL...
  • Page 296 ;---------------------------------Enable Watch dog feature ------------------------------ 030h ;------------------------------- Enable Watch PME-------------------------------------------- 0FAh ; ------------------------ Set timeout interval to 30 ------------------------------------------ 0F6h ;-------------------Set second as counting unit and start counting --------------------- 0F5h ;---------------------------------Exit the extended function mode ------------------------- 0AAh Page: B-22 PA-J670 SERIES USER MANUAL...
  • Page 297 BIOS Setup. (3) Select [Boot] menu and set UEFI USB flash drive to be the 1 boot device. (4) Press <F4> key to save configuration and restart the system to boot into EFI Shell environment. Page: B-23 PA-J670 SERIES USER MANUAL...
  • Page 298 Verifying Boot Block ..done Erasing Main Block ..done Updating Main Block ..done Verifying Main Block ..done Erasing NVRAM Block ..done Updating NVRAM Block ..done Verifying NVRAM Block ..done fs0:\afuefix64> _ Page: B-24 PA-J670 SERIES USER MANUAL...
  • Page 299 The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. 11  2  3  4  5  6  Version 2.18.1263. Copyright (C) 2020 American Megatrends, Inc.  BIOS Date: 03/26/2020 10:34:47 Ver: J6700PD0  Press <DEL> or <ESC> to enter setup.    Page: B-25 PA-J670 SERIES USER MANUAL...

Table of Contents
