Lower the Leveler Feet

Warning:
For optimum safety, it is best to lower the leveler feet
simultaneously with another person. This prevents the library
from tipping over.
Caution:
Once the leveler feet are lowered, the library is no longer
mobile. Ensure that the library is in the desired location before
lowering the leveler feet.
1. Lower the front leveler feet (Figure 4).
Note:
It may be necessary to remove the rubber portion of the leveler
feet to adequately grip the bolt head.
Note:
The leveler feet must be lowered enough to raise the library off of
its rollers. The distance the levelers need to be lowered may vary
depending on the level of the data center floor.
2. Lower the rear leveler feet.
Spectra 64K Library Stability Kit Installation Procedure
Figure 4 Lower the leveler feet.
