Speco IP-400 Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880

Web Camera

IP-400
• View cameras over the Internet, network and normal CCTV systems simultaneously
• Works with Dynamic and Static IP Address • Supports DDNS servers • Network and composite outputs
• Image Device: 1/3"Super HAD* CCD • Minimum Illumination: 0.8 lux
• Powerful PTZ function with various protocols • 1 CH video output for CCTV monitor, VCR, DVR, etc.
• Pure WEB based monitoring solution • Simultaneous 16 CH remote recording with client software
• Remote system management: configuration and upgrade

Specifications

CPU . . . . . . . . . . . . . . . . . . . . .
OS
. . . . . . . . . . . . . . . . . . . . .
Flash Memory . . . . . . . . . . . . . . .
RAM . . . . . . . . . . . . . . . . . . . . .
Viewer . . . . . . . . . . . . . . . . . . .
Network Protocol . . . . . . . . . . . .
Network Interface . . . . . . . . . . . .
Compression Algorithm . . . . . . . . .
Compression Rate . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . .
Image Size . . . . . . . . . . . . . . . . .
Frame Rate
. . . . . . . . . . . . . . . .
Image Sensor . . . . . . . . . . . . . . .
TV System . . . . . . . . . . . . . . . . .
Effective Pixel . . . . . . . . . . . . . . .
White Balance . . . . . . . . . . . . . .
Backlight Compensation . . . . . . . .
Minimum illumination . . . . . . . . .
Sync System . . . . . . . . . . . . . . . .
Lens Mount . . . . . . . . . . . . . . . .
AUTO Iris . . . . . . . . . . . . . . . . .
Pan/Tilt Control . . . . . . . . . . . . .
Power . . . . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . .
*Super-HAD is a trademark of Sony Corporation
IP-400 Camera
CD-ROM
For more information contact us at:
Features
32Bit RISE Processor
Embedded Linux
8MB
16MB
Web browser based monitoring
TCP/IP, HTTP, FTP, SMTP, PPP, UDP, DDNS and more
10/100 base-T Ethernet (RJ-45)
M-JPEG
1/10~1/200
1CH, NTSC/PAL
640 x 480, 320 x 240, 160 x 120
30 frame/sec (320x240)
1/3" Super-HAD CCD
NTSC
771(H) x 492(V)
ATW/AWC
ON/OFF selectable
0.8 lux at F1.2 (50IRE AGC on)
Internal
C/CS Mount
Video/DC
RS-232C
DC12V/500mA Regulated UL/CSA power supply included
2.5"W x 2.25"H x 3.5"L including bracket
14˚F to 120˚F
0.8 lbs.
Package Includes:
RJ-45 cable
Instructions
Power supply
Warranty
