Speco CVC-544BC2 Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Color Board Camera in Aluminum Housing
CVC-544BC2
Our small economical 1/3" color CCD board camera has a housing made of durable
black aluminum. It has 1.0 lux sensitivity with 380 lines of resolution. It features a
built-in 3.6mm wide angle lens and built-in electronic shutter. A mounting bracket
and 12V DC power supply are also included.

Specifications

Resolution . . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . .
Number of Pixels . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . .
Scanning Frequency . . . . . . . . . . . .
Output . . . . . . . . . . . . . . . . . . . .
Video Output Level . . . . . . . . . . . . .
Video S/N Ratio . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . .
Operating Temperature . . . . . . . . . .
Humidity . . . . . . . . . . . . . . . . . . .
Housing . . . . . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . .
For more information contact us at:
Features
380 lines
1/3" Color CCD image sensor
1 lux
3.6mm, 74º Horizontal, 57º Vertical
Auto 1/60 - 1/100,000 sec.
512 horizontal line x 492 vertical line
NTSC Color 525 line 60 field/second
Horizontal 15.75 kHz vertical 60 Hz
Video - RCA with BNC adapter, power- DC jack
1.0 Vp-p 75 ohm
Greater than 46 dB
210 mA
14º F to 122º F
Within 95% RH
Black Metal
Regulated 12V DC power supply
included (UL and CSA listed)
1.5"L x 2"W x 3"H
2.5 oz
