Toto EGO II TX494SELV1BR Quick Start Manual

SPECIFICATIONS
230
67
Ø95
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning.
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and fittings.
2. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the
basic installation principles are the same.
S06725-1BN
INSTALLATION
1

Make sure floor is flat
Hot Water
3
Supply *
HOT
Cold Water
Supply *
* Pipe supplied by owner
5
* Cut the cover after the
mortar dry
"EGO II" LEVER HANDLE FLOOR STANDING
SINGLE LEVER BATH FILLER
2
a
Floor
Base
Water Pass
Sleeve
Anchor
6 X Ø6
Holes
b
Screw
4
Cover
Maxi m um
Mortar Level
COLD
Minimum
Mortar
Mortar Level
6
* Plastic
Hex. Key
Cover
Bolt*
Washer*
Base
Cover
* Remove the Base Cover
, keep the Bolt & Washer
TX494SELV1BR
7
Body
Hex. Key
Cover
Bolt & Washer
(Dari step 6)
Swivel
Ring
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Water leaks around the handle 1
Handle is loose 2
1. CONNECTING NUT
2. BOLT
SOLUTION
Tighten
Tighten
R9
