Toto CURIO TX492SCZ Quick Start Manual

SPECIFICATIONS
150±10
20
G½
420
Ø208
50
67
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2.
Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. Flow Regulator should not be remove because it could
damage the system
3. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
The hot water supply side of the faucets is in a condition of
4.
high temperature. Do not allow skin to contact with the
hardware surface directly. Otherwise, scalding may occur.
S06530Z
INSTALLATION
1
MOUNT CONNECTORS
PARALLEL WITH THE WALL
Hot
Water
Supply
WALL
Leg
3
Drill
40
5
Pipe
0
-4
Bolt
Hex.
Key
Hanger
Body
"CURIO" SHOWER COLUMN SET TX492SCZ
2
Cover
Packing
Cold
Water
Supply
Body
Use Seal tape
(Not Include)
* Tighthen the nut
4
Sleeve Anchor
2 x Ø8
Bracket
Holes
w/ Oring
Screw
6
Hex. Key
Bolt
Cover
Holder
Packing
Shower Head
Pipe
7
Hand Shower
Packing
Flexible Hose
Packing
TROUBLESHOOTING
PROBLEM
Unsatisfactory spray
Water leaks around the handle
Water leaks around the nut
Handle is loose
Nut *
Flow Regulator Inside
(Don t remove)
3. NUT
1. NOZZLES
4. BOLT
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as
ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning
CHECK
SOLUTION
POINT
1 Clean
2 Tighten
3
Tighten
4
Tighten
Flow Regulator Inside
(Don t remove)
2. CERAMIC
HEAD WORK
R7
