Toto GLORIA TX492SG Quick Start Manual

SPECIFICATIONS
150±10
20
G½
420
Ø250
50
67
OPERATING CONDITIONS
1.
Water supply pressure : 0.05 ~ 0.75 MPa.
2.
Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
Flow Regulator should not be remove because it could
2.
damage the system
3. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
The hot water supply side of the faucets is in a condition of
4.
high temperature. Do not allow skin to contact with the
hardware surface directly. Otherwise, scalding may occur.
S06653
"GLORIA" LEVER HANDLE SHOWER COLUMN SET TX492SG
INSTALLATION
1 MOUNT CONNECTORS
PARALLEL WITH THE WALL
Hot
Water
Supply
Leg
WALL
3
Drill
40
5
Pipe
0
-4
Bolt
Hex.
Key
Hanger
Body
2
Cover
Packing
Cold
Water
Supply
Body
Use Seal tape
(Not Include)
* Tighthen the nut
4
Sleeve Anchor
2 x Ø8
Holes Bracket
w/ Oring
Screw
6 *Tighten the nut w it h wrench.
Bolt
Cover
Hex.
Holder
Key
Packing
Nut*
Pipe
Flow Regulator &
Check Valve inside
(Don t remove)
7
Hand Shower
Packing
Flexible Hose
Packing
TROUBLESHOOTING
PROBLEM
Unsatisfactory spray
Water leaks around the handle
Water leaks around the nut
Handle is loose
Nut *
3. NUT
1. NOZZLES
Shower
Head
4. BOLT
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as
ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning
CHECK
SOLUTION
POINT
1 Clean
2 Tighten
3
Tighten
4
Tighten
Flow Regulator
Inside
(Don t remove)
2. CERAMIC
HEAD WORK
R13
