Toto UMI TX492SUN Quick Start Manual

SPECIFICATIONS
150±10
20
G½
229
Ø180
47
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water. Wipe
entire surface completely dry with clean soft cloth. Many cleaners
may contain chemicals, such as ammonia, chlorine, toilet cleaner etc.
which could adversely affect the finish and are not recommended for
cleaning
S060445N
"UMI" SINGLE LEVER SHOWER COLUMN SET TX492SUN
INSTALLATION
1
MOUNT CONNECTORS
PARALLEL WITH THE WALL
Hot
Water
Supply
Leg
WALL
3
Drill
40
5
Pipe
0
62
-7
Bolt
Hex.
Key
Pipe
Body
2
Cold
Water
Supply
Use Seal tape
Body
(Not Include)
*Tighten the Nut.
4
Sleeve Anchor
Bracket
w/ Oring
2 x Ø8
Holes
Screw
6
Use Seal Tape
(Not Include)
Cover
Packing
Holder
Shower
Head
7
Hand Shower
Hanger
Packing
Flexible Hose
Packing
TROUBLESHOOTING
PROBLEM
Unsatisfactory spray
Cover
Water leaks around the handle
Water leaks around the nut
Handle is loose
Packing
Nut* Flow Regulator Inside
(Don t remove)
3. NUT
1. NOZZLES
2. CONNECTING
NUT
ATTENTION
1.
Don t use abrasive cleaners or solvents on faucets and fittings.
2. Flow Regulator should not be remove because it could damage
the system
3. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the basic
installation principles are the same.
The hot water supply side of the faucets is in a condition of high
4.
temperature. Do not allow skin to contact with the hardware
surface directly. Otherwise,
scalding may occur.
CHECK
SOLUTION
POINT
1 Clean
2 Tighten
3
Tighten
4 Tighten
Flow Regulator Inside
(Don t remove)
4. B OLT
R6
