Toto REI S TX119LRS Quick Start Manual

SPECIFICATIONS

Ø45 Ø45
H C
G½
100 100

OPERATING CONDITIONS

1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc. )

MAINTENANCE

Always wipe chrome plated area with dry soft cloth,
and sometimes wipe it with cloth soaked in mild soap.
ATTENTION
1. Don t use abrasive cleaning material such as; detergents
containing hydrochloric acids, thinner, polishing powder,
and nylon brush.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S060099S
"REI S" 8" LAVATORY FAUCET W/ 1¼" POP-UP WASTE TX119LRS

INSTALLATION

1.
3 X Ø35
172
115
Ø60
3.
G1¼
max. 230
Packing
Ø35 Hole
Washer
5.
Plug
Siphon
Packing
Triangle
Packing
Kick Box
2.
Handle Base *
Connecting
Nut
Packing
Ceramic
Head Work
Packing
Lock Nut
Body
* Tighten the Handle Base by hand
4.
Faucet
Setting
Bolt
Hot
Water
Setting
Inlet
Nut
6.
Pivot
OPEN
Rod
Position
Packing
Pop-up Clip
Washer
Bolt
Nut

TROUBLESHOOTING

Handle
PROBLEM
Water leaks around the handle
Plug cannot open and close
Cold
Water
Inlet
Bottom
Position
Bolt
CHECK
SOLUTION
POINT
1 Tighten
2 Tighten
1. CERAMIC
HEAD WO RK
2. BOLT
R8
