Summary of Contents for Magmaweld ID 350E
- Page 1 USER MANUAL ID 350E (+90) 444 93 53 magmaweld.com (+90) 538 927 12 62 info@magmaweld.com...
- Page 2 ID 350E DC WELDING INVERTER СВАРОЧНЫЙ ИНВЕРТОР DC DC KAYNAK İNVERTÖRÜ...
-
Page 3: Table Of Contents
Contents ID 350E CONTENTS SAFETY PRECAUTIONS General Information TECHNICAL INFORMATION Machine Components Product Label Technical Data Accessories Delivery Control INSTALLATION Installation and Operation Recommendations Mains Plug Connection Connection to Mains Connections for MMA Welding TIG Welding Connections User Interface OPERATION... -
Page 4: Safety Precautions
ID 350E Safety Precautions SAFETY PRECAUTIONS Be Sure To Follow All Safety Rules In This Manual! • Safety symbols found in the manual are used to identify potential hazards. • When any one of the safety symbols are seen in this manual, it must be understood that there is Explanation Of Safety a risk of injury and the following instructions should be read carefully to avoid potential hazards. - Page 5 Safety Precautions ID 350E Make sure all connections are tight, clean, and dry. • Keep cables dry, free of oil and grease, and protected from hot metal and sparks. • Bare wiring can kill. Check all cables frequently for possible damage. If a damaged or an uninsulated cable is detected, repair or replace it immediately.
- Page 6 ID 350E Safety Precautions • Use a standard protective mask and a suitable glass filter to protect your eyes and face. • Protect other naked parts of your body (arms, neck, ears, etc.) with suitable protective clothing Arc Light May Damage from these rays. Your Eyes and Skin • Enclose your work area with flame-resistant folding screens and hang warning signs at eye level so that people around you will not sustain injuries from arc rays and hot metals.
- Page 7 Safety Precautions ID 350E • In small-sized and confined spaces, absolutely make sure to perform welding / cutting operations, accompanied by another person. Welding / Cutting in • Avoid performing welding / cutting operations in such enclosed areas as much as possible. Small Sized and Confined Spaces • Take all necessary precautions when moving the machine. The areas where the machine to be...
- Page 8 ID 350E Safety Precautions • Ensure that your welding and/or cutting machine has been installed and situated in its place according to the user manual. Before installing the welding / cutting equipment, the person in charge of the operation and / or Evaluation Of According to article 5.2 of IEC 60974-9;...
- Page 9 • This device is not domestic waste. It must be directed to recycling within the framework of the European Union directive and national laws. Waste Procedure • Obtain information from your dealer and authorized persons about the waste management of your used machines. WARRANTY FORM Please visit our website www.magmaweld.com/warranty-form/wr for warranty form. USER MANUAL www.magmaweld.com...
-
Page 10: Technical Information
Arc Force potentiometer. It can be used as a Touch-Scratch DC TIG* welder if a TIG torch with a valve is connected. ID 350E can also be used with long welding cables up to 25 m. Plus, wireless and cable remote control options are possible.The machine is fan cooled and thermally protected... -
Page 11: Product Label
Technical Information ID 350E 1.3 Product Label Three Phase Transformer Rectifier Duty Cycle TIG Welding Open Circuit Voltage MMA Welding Mains Voltage and Frequency Direct Current Rated Welding Voltage Vertical Characteristic Rated Mains Current Mains Input 3-Phase Alternating Current Rated Welding Current Suitable for Operation at Hazardous... -
Page 12: Technical Data
ID 350E Technical Information 1.4 Technical Data Mains Voltage (3-phase 50-60 Hz) TECHNICAL DATA UNIT ID 350E Rated Power 19.6 Welding Current Range 5 - 350 Rated Welding Current 350 (%35) Open Circuit Voltage Stick Electrode Diameter Range 1.60 - 5.00... -
Page 13: Delivery Control Installation
Installation ID 350E INSTALLATION 2.1 Delivery Control Make sure that all the materials you have ordered have been received. If any material is missing or damaged, contact your place of purchase immediately. The standard box includes the following; • Welding machine and connected mains cable • Warranty certificate •... -
Page 14: Mains Plug Connection
ID 350E Installation 2.3 Mains Plug Connection • No plug has been connected to the mains cable since there may different types of outlets available in plants, For your safety, never use the mains cord of the machine without a plug. -
Page 15: Operation
Operation ID 350E OPERATION 3.1 User Interface Displays the welding current during welding, displays the adjusted current when the machine doesn’t Current Display weld. İs used for adjusting the welding current a range of 5-350A. Current Adjustment Pot Displays the open circuit voltage and the welding voltage during welding. Voltage Display İs used for a better ignition in stick electrode welding. -
Page 16: Mma Welding
3.4 Remote Control (Optional) • It is possible to control the machine from long distances with the wired remote control options available from Magmaweld. In this case, the appropriate control socket must be installed on the machine by an authorized Magmaweld service. -
Page 17: Maintenance And Service
Maintenance and Service ID 350E MAINTENANCE AND SERVICE • Maintenance and repairs to the machine must be carried out by a qualified personnel. Our company will not be responsible for any accidents that may occur by unauthorized interventions. • Parts that will be used during repair can be obtained from our authorized services. The use of original spare parts will extend the life of your machine and prevent performance losses. -
Page 18: Error Codes
ID 350E Maintenance and Service 4.2 Error Codes • Let the machine on for a while in Error Code Error Cause Solution • Machine is overheated because of Thermal order to cool down itself with the ERR-T1 high ambient temperature of Error cooling fan. -
Page 19: Spare Parts List Annex
Annex ID 350E ANNEX 5.1 Spare Parts List Potency Button Small A229500001 DEFINITION ID 350E Potency Button Big A229500002 Welding Socket A377900106 Cooling Fan A250200015 Pacco Switch A308033005 Control Transformer A366100004 Hall Effect Sensor A830900008 Electronic Card E202A-3-400 K405000130 Electronic Card E202A-12 K405000137 Electronic Card E202A-FLT V1.1... -
Page 20: Connection Diagrams
ID 350E Annex 5.2 Connection Diagrams Block Diagram www.magmaweld.com USER MANUAL... - Page 21 Annex ID 350E Circuit Diagram USER MANUAL www.magmaweld.com...
