A.1.3
Example Program
1.
Enable the watchdog timer and set 10 seconds as the timeout interval
;-----------------------------------------------------------
Mov dx,2eh ; Unlock NCT6106D
Mov al,87h
Out dx,al
Out dx,al
;-----------------------------------------------------------
Mov al,07h ; Select registers of the watchdog timer
Out dx,al
Inc dx
Mov al,08h
Out dx,al
;-----------------------------------------------------------
Dec dx ; Enable the function of the watchdog timer
Mov al,30h
Out dx,al
Inc dx
Mov al,01h
Out dx,al
;-----------------------------------------------------------
Dec dx ; Set seconds as the counting unit
Mov al,0f0h
Out dx,al
Inc dx
In al,dx
And al,not 08h
Out dx,al
;-----------------------------------------------------------
Dec dx ; Set timeout interval as 10 seconds and start counting
Mov al,0f1h
Out dx,al
Inc dx
Mov al,10
Out dx,al
;-----------------------------------------------------------
Dec dx ; Lock NCT6106D
Mov al,0aah
Out dx,al
2.
Enable the watchdog timer and set 5 minutes as the timeout interval
;-----------------------------------------------------------
Mov dx,2eh ; Unlock NCT6106D
Mov al,87h
Out dx,al
73
MIC-770 User Manual
