Advantech MIC-7700 Startup Manual

MIC-7700
Intel 6 /7
® th th
Fanless System
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following items have been shipped:
1. MIC-7700 bare-bone system x 1
2. Startup manual EN\CN\TC for MIC-7700 1st Ed
3. MIC-7700 Driver CD x 1
4. 4-pin Phoenix connector
5. Mounting bracket x2
6. SATA cable x1
7. SATA power cable x 1
8. 2 x DB9 ports cable x 1
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For detailed info about the MIC-7700, please
Note 1:
refer to information on the enclosed CD-ROM (in
PDF format).
Acrobat Reader is required to view any PDF file.
Note 2:
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
Caution: DANGER OF EXPLOSION IF BATTERY IS INCOR-
RECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER, DISCARD USED BAT-
TERIES ACCORDING TO THE MANUFACTURER'S
INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU LE TYPE
ÉQUIVALENT RECOMMANDÉ PAR LE FABRICANT,
JETTENT LES BATTERIES UTILISÉES INSTRUC-
TIONS DE S SELON FABRICANT DES'.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-7700 Series Rev. A1.
Part No. 2001770030
Printed in China
Generation Core™ i Socket Compact
P/N: 2001770030
P/N: 2061770010
P/N: 1652003234
P/N: 1960070543N001
P/N: 1700013095
P/N: 1700024372-01
P/N: 1701200220
1st Edition
April 2018
Specifications

Processor System

• Intel 6 /7 generation Core™ i socket CPU (LGA1151)
® th th
Memory
• Supports dual channel DDR4 SODIMM-2133 MHz, 16 GB
per slot without ECC function; Max. capacity is 32GB
Graphics
• Q170: Intel HD Graphics 530, supports DirectX 12
®
• H110: Intel HD Graphics 510, supports DirectX 12
®

Serial Ports

• 2 x RS-232/422/485, RS-485 supports automatic flow control
• 2 x RS232
Ethernet
• Interface: 10/100/1000 Mbps
• Controller:
Q170 LAN1: Intel I219LM, LAN2: Intel
®
H110 LAN1: Intel I219V, LAN2: Intel
®
Storage
• Internal 2.5" Storage Bay: 1
• CFast slot: 1
• mSATA: 1
Front I/O
• Display: 1 x VGA, 1 x DVI
• USB:
Q170: 8 x USB 3.0
H110: 4 x USB 3.0 and 4 x USB 2.0
• Serial: 2 x RS-232/422/485, 2 x RS-232
• Audio: Line-out/Mic-in

Power Requirement

• Power type: ATX/AT
• Power input Voltage: 9-36 VDC
• Minimum Power Input: 9VDC 16A - 36VDC 5A
This product is intended to be supplied by a UL certified
power supply or UL certified DC source rated 19Vdc, 7.89A
minimum, TMA 50 °C minimum, if you need further assis-
tance, please contact Advantech for further information.
Miscellaneous
• Power Switch
(Orange: System standby/Green: System Power boot)
• COM1 TX & RX LED; COM2 TX & RX LED; Storage Status LED
Environment
• Operation Temperature:
TDP 35W CPU: -10~50°C
TDP 65W CPU: -10~40°C (not support i7)
Note: Safety Certification Test Temperature: safety max
50 °C with SSD (TDP 35W CPU)
• Storage Temperature: -40 ~ 85 °C (-40 ~ 185 °F)
• Relative Humidity: 95% @ 40° C (non-condensing)
i210IT
®
i210IT
®
