MIC-1810
Intel
Core™ i3-6100U/Celeron
®
Embedded Automation Computer
Startup Manual

Packing List

Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x MIC-1810 system
2. 1 x MIC-1810 startup manual
3. Terminal blocks: 1 x 2-pin, 1 x 16-pin, 1 x 24-pin, 3 x
10-pin
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Caution: BATTERIES ARE AT RISK OF EXPLODING IF
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER.
DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER'S INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU LE
TYPE ÉQUIVALENT RECOMMANDÉ PAR LE
FABRICANT, JETTENT LES BATTERIES UTILI-
SÉES INSTRUCTIONS DE S SELON FABRICANT
DES'.
Note:
For driver download, please search for below
products on support portal.

System:

MIO-5272U-U0A1E for MIC-1810-U0A1E
MIO-5272U-U3A1E for MIC-1810-U3A1E
DAQ board: MIC-1810 / MIOE-3810
For more information about this or other Advantech
products, please visit our website at
http://www.advantech.com
http://www.advantech.com/Products
For technical support and service, please visit our
support website at
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-1810 Series Rev. B1.
Part No. 2001181002
Printed in Taiwan
Edition 3
November 2020
3955U
®

Specifications

System
• 6th generation Intel
Core™ i processer
®

Memory

• 4GB SODIMM DDR3L 1600

Graphics

• Intel
HD Graphics 520/510, supports DirectX12
®

Serial Ports

• 2 x RS-232 via COM1/COM2

Ethernet

• Interface: 10/100/1000 Mbps
• Controller
LAN1: Intel i219
LAN2: Intel i210

Storage

• Internal SSD Bay: 1 x 2.5" SSD bay

Front I/O

• Display: 1 x VGA/HDMI
• USB: 2 x USB 3.0, 2 x USB 2.0

Power Requirement

• Power Type: 2-pin Phoenix Connector
• Input Voltage: 10~36V
Miscellaneous
• Power Switch
Orange: System standby
Green: System boot
Table Mount (Optional)
• P/N: 1960099348N001
• Dimensions (W x L): 220 x 156 mm

Environment

• Operating Temperature: -20~60 °C with 0.7m/S air flow
and 1 x industrial SSD
• Relative Humidity: 95% @ 40 °C (non-condensing)

Physical Characteristics

• Dimensions (W x H x D): 200 x 156 x 56 mm
• Weight: 2.41kg (5.3lb)
DC
MIC-1810 Startup Manual 1
