MIC-3042A/B
4U-High 8-slots
CompactPCI Platform
with Standard CPCI
Power Supply
Advantech CompactPCI™
Modular Industrial Computer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIC-3042A and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech MIC-3042A

Summary of Contents for Advantech MIC-3042A

  • Page 1 MIC-3042A/B 4U-High 8-slots CompactPCI Platform with Standard CPCI Power Supply Advantech CompactPCI™ Modular Industrial Computer...

  • Page 2: Copyright Notice

    CE Notification The MIC-3042 series, developed by Advantech Co., Ltd., has passed the CE test for environment specifications when shielded cables are used for external wiring. We recommend the use of shielded cables.

  • Page 3: Product Warranty

    Product warranty Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for one year from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 4: Packing List

    If any of these items are missing or damaged, contact your distributor or sales representative immediately. Technical Support and Sales Assistance If you have any technical questions about the MIC-3042 or any other Advantech products, please visit our support website at: •...

  • Page 5: Table Of Contents

    3.5.4 Fan Module Connector ..........17 3.5.5 LED Board Connector ............17 3.6 Clock Routing Configuration............17 Appendix A ……… 18 (Pin assignment of connectors in MIC-3042A Backplane) Appendix B ……… 38 (Pin assignment of connectors in MIC-3042B Backplane) Appendix C …………………………………………… 54...
  • Page 6 Figure 3-1: MIC-3042A Backplane slot numbering ............15 Figure 3-2: MIC-3042B Backplane slot numbering ............15 Figure 3-3: The connector and jumper locations on the rear side (MIC-3042A)…..16 Figure 3-4: The connector and jumper locations on the rear side (MIC-3042B)…..16 Figure 3-5: V I/O voltage selection..............

  • Page 7: General Information

    General Information MIC-3042 User Manual --- Page...

  • Page 8: Introduction

    (MIC-3924L-A), the chassis temperature and fan speed can be monitored and the MIC-3924L-A will issue sound to alarm while any abnormal. The MIC-3042A supports PICMG 2.16 and can be used as blade servers. Moreover, the MIC-3042B supports slim CD-ROM or FDD using MIC-3960 media carrier board.

  • Page 9: Features

    • Construction: Aluminum frame and galvanized sheet steel • 8-slot space (32 TE), including one system slot and seven peripheral slots for MIC-3042A and six peripheral slots and one media slot for MIC-3042B • "Hot swappable” platform complies with PICMG 2.1 R 2.0 Hot Swap Specification •...

  • Page 10: Power Supply

    • Life expectancy: 80,000 hours @ 40° C (front fan); 50,000 hours @ 25° C (rear fan) 1.3.3 Power Supply • Input: AC: 100~240 V @ 47~63 Hz, full range (for MIC-3042X-A models) DC: -48V (TYP), -36~-72V range (for MIC-3042X-D models) •...

  • Page 11: Figure 1-2: Appearance Of Mic-3042

    Figure 1-2: Appearance of MIC-3042 MIC-3042 User Manual --- Page...

  • Page 12: Installation

    Installation MIC-3042 User Manual --- Page...

  • Page 13: Initial Inspection

    2.1 Initial Inspection We have carefully inspected the MIC-3042 series mechanically and electrically before shipping. It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the MIC-3042 series, check it for signs of shipping damage (damaged box, scratches, dents, etc.).

  • Page 14: Installation Procedures

    The system slot is marked by a triangle enclosing the slot number 1 for MIC-3042A and 2 for MIC-3042B. Please refer to the Appendix A and Appendix B for detailed backplane information The insert/eject handles on CompactPCI™...

  • Page 15: Figure 2-3: Installing A Card Into The Chassis

    3. Insert the card into the chassis by sliding the left and right edges of the card into the card guides. 4. Push the card into the slot gently by sliding the card along the card guide until the handles meet the rectangular holes of the cross rails. Figure 2-3: Installing a card into the chassis Note: If the card is correctly positioned and has been slid all the way into...

  • Page 16: Before Operating The System

    2.3.2 Before Operating the System Before operating your system, check your power supply source firstly. Adjust the switch on the power supply to the correct voltage. Two mounting flanges are included for users who would like to install the MIC-3042 on a 19"...

  • Page 17: Backplane

    Backplane MIC-3042 User Manual --- Page 11...

  • Page 18: General Information

    3.1 General Information There are two kinds of backplanes for MIC-3042 series. MIC-3042A and MIC-3042B are with H.110 CT bus backplane. Both backplanes provide eight CompactPCI™ slots with one slot dedicated to the CPU board. The MIC-3042 supports front I/O wiring, providing simplified system cabling.
  • Page 19 The system slot has a logical number of 1 (for MIC-3042A) or 2 (for MIC-3042B), and the peripheral slot has a logical number of 2~8 for MIC-3042A or 1, 3-8 for MIC-3042B. The connectors in logical slot 1 are designated as 1-P1, 1-P2, and 1-P3 from the bottom up.
  • Page 20 GNT5# P2:E15 GNT# P1:E5 System Slot (Logical Slot 1) Peripheral Slot (Logical Slot 8) CLK6 P2:A21 P1:D6 AD25 P1:D8 IDSEL P1:B9 REQ6# P2:A17 REQ# P1:A6 GNT6# P2:E17 GNT# P1:E5 Table 3-2 : MIC-3042B System to peripheral slot signal assignment. System Slot (Logical Slot 2) Peripheral Slot (Logical Slot 1) CLK0 P1:D6...

  • Page 21: Connector And Jumper Locations

    Figure 3-1: MIC-3042A backplane slot numbering Figure 3-2: MIC-3042B backplane slot numbering 3.5 Connector and Jumper Locations The backplane provides connectors and jumpers for users to configure the backplane for specific application. Table 3-2 gives a brief description to each connector on the backplane.

  • Page 22: Atx Power Connector (Atx1)

    P3, P5 P3, P5 H.110 CT bus / Non-CT bus (slot 2~6) Alarm Module Connector CN10 CN10 M66EN JP13 JP13 64EN JP1~JP8 JP1~JP8 Figure 3-3: The connector and jumper locations on the rear side. (MIC-3042A) MIC-3042 User Manual --- Page 16...

  • Page 23: Power Switch

    Figure 3-4: The connector and jumper locations on the rear side. (MIC-3042B) 3.5.1 ATX Power Connector (ATX1) This connector accepts one standard ATX power supply. Note: Do not use ATX power supply and plug-in power module at the same time. 3.5.2 Power Switch This connector provides power on/off control of the ATX power supply or the plug-in power module.

  • Page 24: Clock Routing Configuration

    +3.3V +3.3V VIO for +5V VIO for +3.3V Figure 3-5: V I/O voltage selection 3.5.4 Fan Module Connector The FAN connectors provide +12 V power for fan operation and accepts the tachometer output from the fans. Note the fan4 is reserved as factory default. 3.5.5 LED Status Connector This connector provides digital outputs for the alarm module (MIC-3924L-A) to the chassis front panel notification used.

  • Page 25: Mic-3042 User Manual

    Appendix A Pin Assignments of MIB-3042A backplane MIC-3042 User Manual --- Page 19...
  • Page 26 A1. Pin assignment of other connectors in MIC-3042A backplane A1.1-1 Fan connector (CN5 – CN9) Signal +12V Fan Speed A1.1-2 Fan connector (FAN1) Signal +12V Fan Speed A1.2 LED Connector (CN11) Signal Signal +3.3V +12V A1.3 POWER ON Connector(CN12) Signal...
  • Page 27 A1.4 Alarm board Connector (CN10) Signal Signal +3.3V FAN1 FAN2 -12V FAN3 FAN4 +12V +5VSB FAN5 T_SCLK (Clock of I C bus to temperature sensor) FAN6 T_SDAT (Data of I C bus to temperature sensor) B_SCLK (Clock of I C bus to system) POWER_ATX_ON# B_SDAT (Data of I C bus to system)
  • Page 28 A1.7 power in Connector (AC_DCIN1) Signal Signal ACL/-DC-IN-1 ACL/-DC-IN-1 ACN/+DC-IN-1 ACN/+DC-IN-1 ACL/-DC-IN-2 ACL/-DC-IN-2 ACN/+DC-IN-2 ACN/+DC-IN-2 ACL/-DC-IN-3 ACL/-DC-IN-3 ACN/+DC-IN-3 ACN/+DC-IN-3 A1.8 CPCI-POSITRONIC-PWR-CONN (POWERIN1~ POWERIN3) Signal Signal +5VADJ +5VSENSE +3.3VADJ +3.3VSENSE SRTN +5VSHARE +12VSENSE IPMBSCL +3.3V DEG# +3.3V INH# +3.3V IPMBSDA +3.3V +3.3VSHARE +3.3V FAL#...
  • Page 29 -12V CAN/+DCIN ACL/-DCIN FIXPIN FIXPIN MIC-3042 User Manual --- Page 23...
  • Page 30 A2. Pin assignment of P1~P5 connectors in MIC-3042A backplane A2.1 System Slot S1P1 Connector Table A2-1: System slot S1P1 connector REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]#...
  • Page 31 A2.2 System Slot S1P2 Connector Table A2-2: System slot S1P2 connector CLK6 CLK5 SMB_SDA SMB_SCL BRSVP2A18 BRSVP2B18 BRSVP2C18 BRSVP2E18 BRSVP2A17 PRST# REQ6# GNT6# BRSVP2A16 BRSVP2B16 BRSVP2E16 BRSVP2A15 FAL# REQ5# GNT5# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45]...
  • Page 32 A2.3 System Slot S1P3 Connector Table A2-3: System slot S1P3 connector SGA4 SGA3 SGA2 SGA1 SGA0 LP1A_DA+ LP1A_DA- LP1A_DC+ LP1A_DC- LP1A_DB+ LP1A_DB- LP1A_DD+ LP1A_DD- LP2B_DA+ LP2B_DA- LP2B_DC+ LP2B_DC- LP2B_DB+ LP2B_DB- LP2B_DD+ LP2B_DD- #: Low active MIC-3042 User Manual --- Page 26...
  • Page 33 A2.4 System Slot S1P4 Connector Table A2-4: System slot S1P4 connector 12-14 Key Area MIC-3042 User Manual --- Page 27...
  • Page 34 A2.5 System Slot S1P5 Connector Table A2-5: System slot S1P5 connector MIC-3042 User Manual --- Page 28...
  • Page 35 A2.6 Peripheral Slots (S2~S7) P1 Connector Table Peripheral Slot (S2~S7) P1 Connector REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]#...
  • Page 36 A2.7 Peripheral Slots (S2~S7) P2 Connector Table Peripheral Slot (S2~S7) P2 Connector SMB_SDA SMB_SCL BRSVP2A18 BRSVP2B18 BRSVP2C18 BRSVP2D18 BRSVP2E18 BRSVP2A17 PRST# BRSVP2A16 BRSVP2B16 BRSVP2E16 BRSVP2A15 FAL# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45] V(I/O) AD[44] AD[43] AD[49]...
  • Page 37 A2.8 Peripheral Slots (S2~S7) P3 Connector Table A2-8: Peripheral Slot (S3~S6,S8~S10,S12~S15,S17~S19) P3 Connector SGA4 SGA3 SGA2 SGA1 SGA0 LPxA_DA+ LPxA_DA- LPxA_DC+ LPxA_DC- LPxA_DB+ LPxA_DB- LPxA_DD+ LPxA_DD- LPxB_DA+ LPxB_DA- LPxB_DC+ LPxB_DC- LPxB_DB+ LPxB_DB- LPxB_DD+ LPxB_DD- #: Low active Note: “x” means slot #, i.e. Slot #2 would have “LP4B_DB+” in A15, “LP3B_DB+” in A17,and so does other pins.
  • Page 38 A2.9 Peripheral Slots (S2~S7) P4 Connector Table A2-9: Peripheral Slot (S2~S7) P4 Connector SGA4 SGA3 SGA2 SGA1 SGA0 FGND FGND +12V #CT_RT #CT_EN -12V CT_MC FGND #PF_S0 FGND -SEL_Vbat #PF_S1 SELVbatRtn FGND VRGRtn -Vbat VbatRtn 12-14 Key Area CT_D29 CT_D30 CT_D31 V(I/O) #CT_FA...
  • Page 39 A2.10 Peripheral Slots (S2~S7) P5 Connector Table A2-10: Peripheral Slot (S2~S7) P5 Connector Note: “x” means slot #, i.e. Slot #2 would have “LP3B_DB+” in A15, and so does other pins. MIC-3042 User Manual --- Page 33...
  • Page 40 A2.11 Fabric Slot S8P1 Connector Table A2-11: Fabric Slot S8P1 Connector REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]# +3.3V...
  • Page 41 A2.12 Fabric Slot S8P2 Connector Table A2-12: Fabric Slot S8P2 Connector SMB_SDA SMB_SCL BRSVP2A18 BRSVP2B18 BRSVP2C18 BRSVP2D18 BRSVP2E18 BRSVP2A17 PRST# BRSVP2A16 BRSVP2B16 BRSVP2E16 BRSVP2A15 FAL# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45] V(I/O) AD[44] AD[43] AD[49] AD[48]...
  • Page 42 A2.13 Fabric Slot S8P3 Connector Table A2-13: Fabric slot S8P3 connector SGA4 SGA3 SGA2 SGA1 SGA0 LP8B_DB+ LP8B_DB- LP8B_DD+ LP8B_DD- LP8B_DA+ LP8B_DA- LP8B_DC+ LP8B_DC- LP7B_DB+ LP7B_DB- LP7B_DD+ LP7B_DD- LP7B_DA+ LP7B_DA- LP7B_DC+ LP7B_DC- LP6B_DB+ LP6B_DB- LP6B_DD+ LP6B_DD- LP6B_DA+ LP6B_DA- LP6B_DC+ LP6B_DC- LP5B_DB+ LP5B_DB- LP5B_DD+...
  • Page 43 A2.14 Fabric Slot S8P4 Connector Table A2-14: Fabric slot S8P4 connector 12-14 Key Area MIC-3042 User Manual --- Page 37...

  • Page 44: Appendix B (Pin Assignment Of Connectors In Mic-3042B Backplane)

    A2.15 Fabric Slot S8P5 Connector Table A2-15: Fabric slot S8P5 connector LP14B_DB+ LP14B_DB- LP14B_DD+ LP14B_DD- LP14B_DA+ LP14B_DA- LP14B_DC+ LP14B_DC- LP13B_DB+ LP13B_DB- LP13B_DD+ LP13B_DD- LP13B_DA+ LP13B_DA- LP13B_DC+ LP13B_DC- LP12B_DB+ LP12B_DB- LP12B_DD+ LP12B_DD- LP12B_DA+ LP12B_DA- LP12B_DC+ LP12B_DC- LP11B_DB+ LP11B_DB- LP11B_DD+ LP11B_DD- LP11B_DA+ LP11B_DA- LP11B_DC+ LP11B_DC-...
  • Page 45 Appendix B Pin Assignments of MIB-3042B backplane MIC-3042 User Manual --- Page 39...
  • Page 46 B1. Pin assignment of other connectors in MIC-3042BA backplane B1.1-1 Fan connector (CN5 – CN9) Signal +12V Fan Speed B1.1-2 Fan connector (FAN1) Signal +12V Fan Speed B1.2 LED Connector (CN11) Signal Signal +3.3V +12V B1.3 POWER ON Connector(CN12) Signal PS_ON# MIC-3042 User Manual --- Page 40...
  • Page 47 B1.4 Alarm board Connector (CN10) Signal Signal +3.3V FAN1 FAN2 -12V FAN3 FAN4 +12V +5VSB FAN5 T_SCLK (Clock of I C bus to temperature sensor) FAN6 T_SDAT (Data of I C bus to temperature sensor) B_SCLK (Clock of I C bus to system) POWER_ATX_ON# B_SDAT (Data of I C bus to system)
  • Page 48 B1.7 power in Connector (AC_DCIN1) Table A-7: Power in Connector Signal Signal ACL/-DC-IN-1 ACL/-DC-IN-1 ACN/+DC-IN-1 ACN/+DC-IN-1 ACL/-DC-IN-2 ACL/-DC-IN-2 ACN/+DC-IN-2 ACN/+DC-IN-2 ACL/-DC-IN-3 ACL/-DC-IN-3 ACN/+DC-IN-3 ACN/+DC-IN-3 B1.8 CPCI-POSITRONIC-PWR-CONN (POWERIN1~ POWERIN3) Signal Signal +5VADJ +5VSENSE +3.3VADJ +3.3VSENSE SRTN +5VSHARE +12VSENSE IPMBSCL +3.3V DEG# +3.3V INH# +3.3V...
  • Page 49 +12V CGND -12V CAN/+DCIN ACL/-DCIN FIXPIN FIXPIN MIC-3042 User Manual --- Page 43...
  • Page 50 B2. Pin assignment of P1~P5 connectors in MIC-3042 backplane B2.1 System Slot S2P1 Connector Table B2-1: System slot S2P1 connector REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11]...
  • Page 51 B2.2 System Slot S2P2 Connector Table B2-2: System slot S2P2 connector CLK6 CLK5 SMB_SDA SMB_SCL BRSVP2A18 BRSVP2B18 BRSVP2C18 BRSVP2E18 BRSVP2A17 PRST# REQ6# GNT6# BRSVP2A16 BRSVP2B16 BRSVP2E16 BRSVP2A15 FAL# REQ5# GNT5# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45]...
  • Page 52 B2.3 System Slot S2P3 Connector Table B2-3: System slot S2P3 connector HDD_D0 HDD_D2 HDD_D1 HDD_D3 HDD_D12 HDD_D4 HDD_D7 HDD_D5 HDD_D9 HDD_D13 HDD_D6 HDD_D8 HDD_D15 HDD_D14 HDD_IOR# HDD_D10 HDD_D11 HDD_LED HDD_IOW# HDD_DMREQ HDD_CS3# HDD_DRQ HDD_CBDET HDD_DA0 HDD_DA1 HDD_DA2 FDD_DIR# HDD_DMACK# HDD_RST# HDD_IORDY HDD_CS1# FDD_WGATE#...
  • Page 53 B2.4 System Slot S2P4 Connector Table B2-4: System slot S2P4 connector 12-14 Key Area MIC-3042 User Manual --- Page 47...
  • Page 54 B2.5 System Slot S2P5 Connector Table B2-5: System slot S2P5 connector MIC-3042 User Manual --- Page 48...
  • Page 55 B2.6 Peripheral Slots (S1, S3~S8) P1 Connector Table B2-6: Peripheral Slot (S1, S3~S8) P1 Connector REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13]...
  • Page 56 B2.7 Peripheral Slots (S1, S3~S8) P2 Connector Table B2-7: Peripheral Slot (S1, S3~S8) P2 Connector SMB_SDA SMB_SCL BRSVP2A18 BRSVP2B18 BRSVP2C18 BRSVP2D18 BRSVP2E18 BRSVP2A17 PRST# BRSVP2A16 BRSVP2B16 BRSVP2E16 BRSVP2A15 FAL# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45] V(I/O)
  • Page 57 B2.8 Peripheral Slots (S3~S8) P3 Connector Table B2-8: Peripheral Slot (S3~S8) P3 Connector #: Low active MIC-3042 User Manual --- Page 51...
  • Page 58 B2.9 Peripheral Slots S1P3 Connector Table B2-9: Peripheral Slot S1P3 Connector HDD_D3 HDD_D6 HDD_D2 HDD_D10 HDD_D14 HDD_D8 HDD_D5 HDD_D1 HDD_D11 HDD_D15 HDD_D9 HDD_D4 HDD_D0 HDD_D12 HDD_D13 HDD_D7 HDD_CS1# HDD_IOR# HDD_CS3# HDD_IORDY HDD_DMREQ HDD_DMACK# HDD_DA2 HDD_DRQ HDD_IOW# HDD_DA1 HDD_DA0 HDD_LED HDD_RST# HDD_CBDET FDD_DSKCHG# FDD_MTR0#...
  • Page 59 B2.10 Peripheral Slots (S1,S3~S8) P4 Connector Table B2-10: Peripheral Slot (S1, S3~S8) P4 Connector SGA4 SGA3 SGA2 SGA1 SGA0 FGND FGND +12V #CT_RT #CT_EN -12V CT_MC FGND #PF_S0 FGND -SEL_Vbat #PF_S1 SELVbatRtn FGND VRGRtn -Vbat VbatRtn 12-14 Key Area CT_D29 CT_D30 CT_D31 V(I/O)

  • Page 60: Appendix C (Ordering Information)

    B2.11 Peripheral Slots (S1, S3~S8) P5 Connector Table B2-11: Peripheral Slot (S1, S3~S8) P5 Connector MIC-3042 User Manual --- Page 54...
  • Page 61 Appendix C Ordering Information MIC-3042 User Manual --- Page 55...
  • Page 62 • MIC-3042A-A: MIC-3042A CompactPCI™ enclosure, w/ 8-slot CompactPCI™ 6U backplane (MIC-3042A) supporting CT bus application and PICMG 2.16, and 500W 2+1 redundant AC CPCI power supplies. • MIC-3042A-D: MIC-3042A CompactPCI™ enclosure, w/ 8-slot CompactPCI™ 6U backplane (MIC-3042A) supporting CT bus application and PICMG 2.16, and 500W 2+1 redundant DC CPCI power supplies.
