MIOS-5250 Intel
PC with Multiple I/O Extension Module
Startup Manual
Packing List
Before you begin installing your board, please make sure
that the following items have been shipped:
• 1 x MIOS-5250 Embedded System
• 1 x 2.5" HDD/SSD Assembly Kit
• 1 x Heatsink Thermal Pad Kit
• 1 x Heatsink wrench
• Startup Manual
• 1 x Mini Jumper (10pcs package)
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2.html
(Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com/support/new_de-
fault.aspx
This manual is for the MIOS-5250.
Part No. 2006S25000
Printed in China
Atom™ N2600/D2550 Fanless Embedded Box
®
(P/N 9680015412)
(P/N 9689000002)
1st Edition
April 2014
Specifications
General
• CPU: Intel
Atom™
®
- N2600 (Dual Core 1.6GHz)
- D2550 (Dual Core 1.86GHz)
• System Memory: 1 x 204-pin SODIMM socket DDR3 up to 4GB
- N2600: DDR3 800MHz
- D2550: DDR3 1066MHz
• 2nd Cache Memory:
- N2600: 1MB
- D2550: 1MB
• System Chipsets: Intel
• BIOS: AMI EFI 16-Mbit
• Watchdog Timer: 255 levels timer interval, program-
mable by software. Multi level WDT (set by iManager)
• Expansion Interface: Full-size Mini PCIe, CFast (support
by request), SIM Holder, MIOe
• Battery: Lithium 3 V / 210 mAH
• Audio: Supports High Definition Audio (HD), line-in, line-
out, Mic-in
Display
• Controller: Intel
®
Atom™ N2600 / D2550
• Resolution:
-- VGA: N2600 / D2550: 1920 x 1200
-- HDMI:
Supports 1920 x 1200 @60Hz
Supports HDMI 1.3, Max data rate up to 1.65Gb/s
-- LVDS (support by request):
N2600: 24-bit LVDS1, resolution up to1366 x 768
D2550: 24-bit LVDS1, resolution up to 1440 x 900,
48-bit LVDS2, resolution up to 2560 x 1600
(LVDS2 JEIDA support)
• Dual Independent Display:
VGA+LVDS, VGA+HDMI, HDMI+LVDS

Ethernet Interface

• Speed: 10/100/1000 Mbps
• Chipset: Intel
82583V (GbE1, GbE2)
®
• Ethernet Interface: Fully compliant with IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab
• Connector: RJ45 x2
I/O
• I/O Interface: 1 x SATAII, 2 x RS-232, 2 x RS232/422/485
(COM2,3), 6 x USB 2.0, GPIO, HD Audio, HDMI, VGA, 2 x
RJ45 Ethernet, DC Power in connector
• Power connector type:
MIOS-5250NS6-D0A1E: DC Jack
MIOS-5250DS8-P0A1E: 12~24V Phoenix power connec-
tor
• GPIO: 8-bit general purpose input/output
MIOS-5250 Startup Manual 1
Atom™ N2600/D2550 + NM10
®
