MIC-1816
Intel
Core™ i3-3217UE/Celeron
®
Embedded Automation Computer
Startup Manual
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
1. 1 x MIC-1816 system
2. 1 x Adapter 100 ~ 240 V 60W 12 V WO/PFC
DC plug 90°
3. 1 x MIC-1816 startup manual
4. 1 x User note for MIC-1816
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Caution: BATTERIES ARE AT RISK OF EXPLODING IF
INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOMMEND-
ED BY THE MANUFACTURER. DISCARD USED
BATTERIES ACCORDING TO THE MANUFAC-
TURER'S INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU LE TYPE
ÉQUIVALENT RECOMMANDÉ PAR LE FABRICANT,
JETTENT LES BATTERIES UTILISÉES INSTRUC-
TIONS DE S SELON FABRICANT DES'.
For more information on this and other Advantech
products, please visit our website at
http://www.advantech.com
http://www.advantech.com/Products
For technical support and service, please visit our
support website at
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-1816 Series Rev. A1.
Part No. 2001181611
Printed in Taiwan
Edition 2
September 2017
1047UE
®
Specifications
System
• 3rd generation Intel
Core ™ i processer with QM77
®
chipset
Memory
• 4G SODIMM DDR3-1600, 204 pins, 512MX8, 1.35 V
Graphics
• Intel
HD Graphics 4000, supports DirectX11
®
Serial Ports
• 2 x RS-232 from COM1/COM2
Ethernet
• Interface: 10/100/1000 Mbps
• Controller
LAN1: QM77 (MAC) + 82579LM GbE (PHY)
LAN2: 82583V Gigabit Ethernet controller
Storage
• Internal SSD Bay: 1 x 2.5" SSD bay
Front I/O
• Display: 1 x VGA/HDMI
• USB: 2 x USB 3.0, 2 x USB 2.0
Power Requirement
• Power Type: DC power jack
• Input Voltage: 12 V
DC
Miscellaneous
• Power Switch
Orange: System standby
Green: System boot
Mounting Kit (Optional)
• Table Mount: 1960077844N001; 130 x 175 mm
• DIN Rail Mount: 1960018849T001
Environment
• Operating Temperature: 0 ~ 50 °C with 0.7m/S air flow
and 1 x industrial SSD
• Relative Humidity: 95% @ 40 °C (non-condensing)
Physical Characteristics
• Dimensions (W x H x D): 165 x 130 x 59 mm
• Weight: 1.45 kg (3.19 lb)
MIC-1816 Startup Manual 1
Advertisement
Table of Contents
Related Manuals for Advantech MIC-1816
Summary of Contents for Advantech MIC-1816
-
Page 1: Power Requirement
• Dimensions (W x H x D): 165 x 130 x 59 mm http://support.advantech.com.tw/support/default. aspx • Weight: 1.45 kg (3.19 lb) This manual is for the MIC-1816 Series Rev. A1. Part No. 2001181611 Edition 2 September 2017 Printed in Taiwan... -
Page 2: Analog Input
DAQ Specifications DAQ Specifications (Cont.) The MIC-1816 system features a built-in data acquisition Analog Output module (MIOe-3816). Channels Analog Input Resolution 16 bits Channels 16 single-ended/8 differential Memory Size 4K samples Resolution 16 bits Update Rate 3 MS/s Built-In 4K samples Internal 0 ~ 5 V, 0 ~ 10 V, ±5 V, ±10 V... -
Page 3: Hdd Installation
5. Reconnect the SATA and power cables and replace the rear cover. Secure in place using the 4 screws. Rail Mount Installation MIC-1816 can be fitted with a DIN rail mount for flexible installation. 1. Align the screw holes of the rail mount to the screw holes in the rear cover. -
Page 4: System Dimensions
System I/O Interface System Dimensions 4 MIC-1816 Startup Manual... - Page 5 Intel® Core™ i3-3217UE/Celeron® 1047UE微型计算机 快速入门手册 包装清单 产品规格 处理器系统 安装板卡之前，用户需确认包装中含有本设备以及下面所 列各项： • Intel第三代Core i处理器，带QM77芯片组 1. 1 x MIC-1816系统 内存 2. 1 x 适配器100 240 V 60W 12V WO/PFC DC plug 90° • 4G SODIMM DDR3-1600 204针512MX8 1.35 V 3. 1 x MIC-1816快速入门手册 显示...
- Page 6 最大0.8 V @+15mA ±5 V 0 ~ 10 V 1.04 us 计数器输出 高 最小2.0 V @-15mA ±2.5 V 0 ~ 5 V 1.04 us ±1.25 V 0 ~ 2.5 V 4 us ±0.625 V 0 ~ 1.25 V 5 us 2 MIC-1816快速入门手册...
- Page 7 0.1%，输入信号频率 ≤ 40 KHz 高级功能误差 脉冲输出 小于2%，输出频率 > 1 MHz PWM输出 小于2%，输出频率> 1 MHz 简易安装指导 HDD安装 1. 卸下4颗螺丝后移除底盖。 2. 从底盖上卸下用于固定SSD的4颗螺丝。 3. 插接SATA线缆/电源线后放回后盖并用4颗螺丝固定。 导轨安装 MIC-1816同时支持导轨安装，导轨对齐后进行锁即完成安 装。 桌面安装 MIC-1816支持桌面安装。为避免系统过热，散热片一侧必须 朝上放置。 1. 卸下4颗螺丝。 2. 底盖对齐后使用4颗螺丝进行固定完成桌面安装。 符合性声明 本品符合FCC规则第15款限制。操作符合下列两种情况： 1. 此设备不可产生干扰， 2. 本设备必须接受任何收到的干扰，但干扰可能导致意外 操作。 MIC-1816快速入门手册 3...
- Page 8 系统I/O接口 系统尺寸 4 MIC-1816快速入门手册...
