Installation - Mechanical
Figure 22. Fixed speed compressor power and
communication wiring
Figure 23. Variable speed power and communication
wiring
38
Figure 24. Fixed speed compressor power and
communication wire routing
Figure 25. Compressor communication terminations
Note: Pluggable connectors are color coded and
individually keyed for ease of installation.
PKG-SVX027D-EN
