Dimensional Data
Figure 7. Evaporator cassette assembly footprint (in inches)
Table 8. Evaporator cassette dimensions (in inches)
Model
25
30
35
40/40L
50/50L
60/60L
70/70L
(b)
80/80L
(b)
(a)
Does not include condensate drain connection. Add an additional 1.5 inch to width to account for drain connection.
(b)
Split coils.
20
Split Coil Width
Width
55.2
N/A
67.7
N/A
67.7
N/A
96
(a)
N/A
96
(a)
N/A
96
(a)
N/A
77
127
(a)
50
77
127
(a)
50
Height
Depth
84
34.5
84
34.5
84
34.5
84
34.5
84
34.5
84
34.5
84
34.5
84
34.5
84
34.5
84
34.5
PKG-SVX027D-EN
