Weights
Table 13. Unit shipping weights (starter cassette) (continued)
Unit
Overall Dimensions (in)
Size
40 Ton 70"x 84" x 95.5"
50 Ton 70"x 84" x 95.5"
60 Ton 70"x 84" x 95.5"
70 Ton 70"x 84" x 126"
80 Ton 70"x 84" x 126"
Table 14. Unit shipping weights (evaporator cassette)
Tonnage Overall dimensions (in)
25 Ton 70" x 84" x 56"
30 Ton 70" x 84" x 68"
35 Ton 70" x 84" x 68"
40 Ton 70"x 84" x 95.5"
50 Ton 70"x 84" x 95.5"
60 Ton 70"x 84" x 95.5"
70 Ton (a) 70"x 84" x 127"
80 Ton (a)
70"x 84" x 127"
(a) Split coils.
24
Unit Weight (lbs) Starter Cassette (in)
2933 34.5"x 54.5"x 27.6"
3365 34.5"x 54.5"x 27.6"
3500 34.5"x 54.5"x 27.6"
4545 34.5"x 54.5"x 27.6"
4545 34.5"x 54.5"x 27.6"
Unit Weight (lbs) Evaporator Cassette (in)
2030 34.5" x 84" x 55.2"
2580 35.5" x 84" x 67.7"
2580 34.5" x 84" x 67.7"
2933 34.5" x 84" x 94"
3365 34.5" x 84" x 94"
3500 34.5" x 84" x 94"
34.5" x 84" x 77"
4545
34.5" x 84" x 50"
34.5" x 84" x 77"
4545
34.5" x 84" x 50"
Starter Cassette
Weight (230 Vac) (lbs)
323
323
323
388
388
Total Weight of
Cassette
(excl. Economizer) (lbs)
1018
1082
1082
1127
1219
1254
1032
620
1032
620
