- Page 1 USER MANUAL ENGLISH Aviano Tour 20 W CCT Product code: 31401 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Aviano Tour 20 W CCT Preface Thank you for purchasing this Showtec product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Aviano Tour 20 W CCT Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 Product Lifespan ..............................3 LEDs Lifespan ............................... 3 Text Conventions ..............................3 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................4 Safety .................................. -
Page 4: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Artecta Aviano Tour 20 W CCT with fixed Schuko power cable (6 m) ● User manual Fig. -
Page 5: Symbols And Signal Words
Aviano Tour 20 W CCT ● 0–255: Defines a range of values ● Notes: Note: (in bold lettering) is followed by useful information or tips Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. -
Page 6: Safety
Aviano Tour 20 W CCT Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. - Page 7 Aviano Tour 20 W CCT WARNING Risk of burns due to hot surface The surface and the inner parts of the device can become very hot during operation. ● Do not touch the device during operation. ● Allow the device to cool down for at least 15 minutes before handling.
-
Page 8: Requirements For The User
Aviano Tour 20 W CCT Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ●... -
Page 9: Description Of The Device
Description of the Device The Artecta Aviano Tour 20 W CCT is a 20 W LED flood light with a 110° beam angle and a color temperature switch. The device can be installed with a clamp or can be mounted on a wooden or concrete wall. -
Page 10: Product Specifications
Aviano Tour 20 W CCT Product Specifications Model: Aviano Tour 20 W CCT Electrical: Input voltage: 220–240 V AC, 50/60 Hz Power consumption: 21 W Physical: Dimensions: 179 x 47 x 164 mm (L x W x H) Weight: 1,24 kg... -
Page 11: Installation And Operation
Aviano Tour 20 W CCT Installation and Operation Safety Instructions WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. -
Page 12: Mounting
Aviano Tour 20 W CCT Mounting The device can be mounted to a truss or other rigging structure in any orientation or can be mounted to a wall. Make sure that all loads are within the pre-determined limits of the supporting structure. -
Page 13: Installation On A Wall
Aviano Tour 20 W CCT Installation on a Wall To install the device, follow the steps below: 01) Turn the 2 adjustment screws (01) counterclockwise to loosen them (Fig. 07). 02) Remove the 2 adjustment screws (01). The device and the mounting bracket (03) will disconnect. -
Page 14: Drilling Into Wood
Aviano Tour 20 W CCT 08) Insert the 2 adjustment screws (01) to connect the device to the mounting bracket (03). 09) Turn the 2 adjustment screws (01) clockwise to tighten them (Fig. 11). Fig. 11 Drilling into Wood If you drill into wood, use hardwood drill bits. Predrill before inserting screws, to remove drill dust and to avoid damaging of the wood. -
Page 15: Angle Adjustment
Aviano Tour 20 W CCT Angle Adjustment You can adjust the angle of the device with the adjustment screws (01). 01) Turn the adjustment screws (01) counterclockwise to release them. 02) Tilt the device to the desired angle (Fig. 14). -
Page 16: Power Linking Of Multiple Devices
Aviano Tour 20 W CCT Power Linking of Multiple Devices This device supports power linking. Power can be relayed to another device via the power OUT connector. Power linking of multiple devices must be carried out only by instructed or skilled persons. -
Page 17: Maintenance
Aviano Tour 20 W CCT Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ●... -
Page 18: Deinstallation, Transportation And Storage
Aviano Tour 20 W CCT Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device. - Page 19 Aviano Tour 20 W CCT Product code: 31401...
- Page 20 ©2022 Showtec...
