Troubleshooting

Possible malfunction /
occurring errors
Data is not being transferred
or is being transferred
incorrectly
38
6 Troubleshooting
Repair work may only be carried out by SCHUNK!
If you have any questions regarding maintenance and servicing,
our technicalcustomer service is available during our business
hours:
Service telephone: +49-7133-103-2956
service.toolholder@de.schunk.com
NOTE: All other errors are described in the Assembly and
Operating Manual for iTENDO² easy connect (1539948).
Possible causes
Incorrect process assignment
Tablet is not connected
Incorrect memory bank
Wrong program sequence
Program sequence too fast
01.00 | iTENDO² easy monitor | Assembly and Operating Manual | en | 1547510
Remedial measures
Assign the correct process to
the memory bank: } 5.6.3.6
[/ 33]
Connect the tablet during
recordings: } 5.6.2 [/ 20]
Check the memory bank
assignment in the iTENDO²
app: } 5.6.3.6 [/ 33]
Check the commands for
Digital IN 0-5: } 5.6.3.6 [/ 33]
Check the sequence of the
commands for Digital IN. See
chapter 6.2.3.1 in the
Assembly and Operating
Manual for iTENDO² easy
connect (1539948).
Adhere to waiting times. See
chapter 6.2.3.1 in the
Assembly and Operating
Manual for iTENDO² easy
connect (1539948).
