H3C RA10 Installation, Quick Start

H3C RA10 Router Installation Quick Start-6PW104
H3C RA10路由器主机 快速安装指南-6PW104
Installation tools 工具参考
No installation tools are provided with the router. Prepare installation tools as required.
设备不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flathead screwdriver Phillips screwdriver
一字螺丝刀 十字螺丝刀
ESD wrist strap Diagonal pliers
防静电腕带 斜口钳
Installation accessories 安装附件介绍
M6 rack screw M4 mounting
(user supplied) bracket screw
M6机柜螺钉 (用户自备) M4挂耳螺钉
Grounding RA10-E mounting
cable brackets
地线
RA10-E挂耳
Wear an ESD wrist strap and make sure the strap makes good skin contact and is reliably grounded.
!
作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静电腕带已经良好接地。
Needle-nose pliers Wire-stripping pliers
尖嘴钳 剥线钳
Heat gun Drill
热吹风 电钻
Cage nut
Rubber feet
(user supplied)
脚垫
浮动螺母(用户自备)
Screw anchor and M6 RA10 mounting
wall-mounting screw
brackets
(user supplied)
RA10挂耳
M6壁挂螺钉和螺管套
(用户自备)
Mounting the router in a 19-inch rack 安装路由器到19英寸机柜
The rack-mounting procedure is the same for RA10 and RA10-E routers. RA10和RA10-E路由器机
柜安装方式一致。
Install cage nuts.
Hammer
安装浮动螺母
羊角锤
Marker
记号笔
Bail latch
电源线卡钩
Mark cage nut installation holes.
标记浮动螺母安装位置
