H3C MSR3600 Installation, Quick Start

H3C MSR3600 Routers Installation Quick Start (For MSR3600-28[28-SI][51][51-SI] -6PW104
H3C MSR3600
Tool list
The installation tools are not provided with the router. Prepare them Yourself. 路由器不随
机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flathead screwdriver Phillips screwdriver
一字螺丝刀 十字螺丝刀
Diagonal pliers Heat gun
斜口钳 热吹风
Installation accessories
Cage nut
Grounding cable
(user supplied)
(required)
浮动螺母(用户自备)
地线(标配)
Mounting bracket M6 screw
(required) (user supplied)
M6 螺钉(用户自备)
挂耳(标配)
Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact and is
!
reliably grounded. 操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认
防静电腕带已经良好接地。
Needle-nose pliers Wire-stripping pliers
尖嘴钳 剥线钳
ESD wrist strap Network cable tester
防静电腕带 测线仪
Rubber feet
(required)
胶垫贴(标配)
Bail latch
(MSR3600-28/28-SI/51-SI required)
电源线卡钩(MSR3600-28/28-SI/51-SI标配)
(For MSR3600-28[28-SI][51][51-SI] -6PW104
Mounting the router on a workbench
Mount the router on a workbench.
将路由器安装到工作台
Multimeter
万用表
Marker
记号笔
Mounting the router in a rack
Mounting brackets and their installation method vary by router model. 不同款型的设
备，标配挂耳及挂耳的安装方式不同，安装挂耳到路由器时请按照实际情况进行选择。
M4 screw
(required)
M4 螺钉(标配)
BOM: 3104A0DR
Install cage nuts.
安装浮动螺母
