  • Page 1 Contents Preparing for installation ················································································ 1 Safety recommendations ··································································································································· 1 Safety symbols ··········································································································································· 1 General safety recommendations ·············································································································· 1 Electricity safety ········································································································································· 1 Laser safety ················································································································································ 2 Examining the installation site ···························································································································· 2 Temperature and humidity ························································································································· 2 Cleanliness ················································································································································· 2 Cooling system ···········································································································································...
  • Page 2 Preparing for installation The MSR5600 router series includes the models in Table Table 1 MSR5600 router series models Model (on the front panel) Product code MSR5620 RT-MSR5620 MSR 56-60 RT-MSR5660 MSR 56-80 RT-MSR5680 Safety recommendations Safety symbols When reading this document, note the following symbols: WARNING means an alert that calls attention to important information that if not understood or followed can result in personal injury.
  • Page 3 Laser safety WARNING! Do not stare into any open apertures of operating transceiver modules or optical fiber connectors. The laser light emitted from these apertures might hurt your eyes. CAUTION: • Before you remove the optical fiber connector from a fiber port, execute the shutdown command in interface view to shut down the port.
  • Page 4 Table 4 Harmful gas limits in the equipment room Max. (mg/m 0.006 0.05 0.01 0.04 Cooling system The router uses left to rear airflow for heat dissipation. Figure 1 Airflow through the MSR 5600 chassis To ensure good ventilation, the following requirements must be met: •...
  • Page 5 • Always wear an ESD wrist strap and ESD cloth when touching a circuit board or transceiver module. The router does not supply an ESD wrist wrap. Prepare an ESD wrist wrap yourself. • Place the removed memory module, CF card, or interface module on an antistatic workbench, with the face upward, or put it into an antistatic bag.
  • Page 6 Rack-mounting Before mounting the router in a standard 19-inch rack, adhere to the following requirements: • The rack is equipped with a good ventilation system. • The rack is sturdy enough to support the router and its accessories. • For heat dissipation and device maintenance, make sure the front and rear of the rack are at least 0.8 m (2.62 ft) away from walls or other devices, and the headroom in the equipment room is no less than 3 m (9.84 ft).
  • Page 7 Pre-installation checklist Table 5 Pre-installation checklist Item Requirements Result • There is a minimum clearance of 10 cm (3.94 in) around the inlet and outlet vents for heat dissipation of the router chassis. Ventilation • A good ventilation system is available at the installation site.
  • Page 8 Item Requirements Result • Documents shipped with the router are available. Reference • Online documents are available.
