H3C MSR3610 Series Installation, Quick Start

H3C MSR3610-X1[3610-G-X3] Routers Installation Quick Start-6W102
H3C MSR3610-X1[3610-G-X3]路由器 快速安装指南-6W102
Tool list 工具参考
The installation tools are not provided with the device. Prepare them yourself.
设备不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
一字螺丝刀 十字螺丝刀
Flat-head screwdriver Phillips screwdriver
斜口钳 热吹风
Diagonal pliers Heat gun
Introduction to installation accessories 安装附件介绍
Cage nut
Grounding cable
(user supplied)
地线
浮动螺母(用户自备)
Mounting brackets Rubber feet
挂耳 脚垫
Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact and
!
is well grounded.
操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静电腕带已经良
好接地。
尖嘴钳 剥线钳
Needle-nose pliers Wire stripper
防静电腕带 电钻
Drill
ESD wrist strap
M6 screw
M4 countersunk head screw
(user supplied)
M4沉头螺钉
M6机柜螺钉(用户自备)
Releasable cable tie
(user supplied)
可拆卸式扎带(用户自备)
Airflow design of the device 设备的风向设计
Make sure the air inlet and outlet vents are not blocked and the installation site has a good
ventilation system.
请确保设备的进、出风孔不被遮挡，并将设备安装在具有良好通风散热系统的环境中。
羊角锤
Claw hammer
记号笔
Marker
Mounting the device on a workbench 安装设备到工作台
Mount the device on a workbench.
将设备安装到工作台
The device uses left-to-right aisles.
设备采用左进右出的风道设计
