Unpacking; The Preparatory Work - Pytes E-BOX Series User Manual

source and that the battery device is turned off. Distribution cabling needs to be handled carefully with
reasonable protective measures to avoid being touched during the maintenance and operation.
5.1.2 Checking the operating environment
The operating environment should meet the requirements described in Chapter 3, "Operating Environ-
ment". Otherwise, it needs to be adjusted and re-examined.
5.1.3 Tools
The tools that may be used are shown in Table 5-1.
Table 5-1 Tools
Screwdriver (Slotted, Phillips)
Diagonal pliers
Thermometer
Anti-static wrist ring
5.1.4 Technical preparation
Electrical interface settings:
If the battery is connected to the user device directly, please check:
Whether the DC charging interface of the energy storage inverter meets the charging voltage and
current requirements in Table 1-1 Battery Pack Specifications.
Whether the power of the electrical equipment matches the parameters listed in "Table 1-1 Battery
Pack Specifications";
Security check:
Fire-fighting equipment such as portable dry powder fire extinguishers should be available near
the equipment. Do not place dangerous materials such as any flammable or explosive ones near the
battery.

5.2 Unpacking

When the battery arrives at the installation site, it must be unloaded and stored properly and
prevented from the direct sunshine and rain. Before installation, check if there is any component
missing according to 1.1 product standard configuration and check whether the box appearance is
intact;
Carefully handling the unpacking. Protect the insulated coating on the case surface;
Check the LFP battery for damage after unpacking. If there is any
damage, contact Pytes or your reseller.

5.3 The preparatory work

1.Make sure the POWER buttons of all batteries are OFF.
2.Ensure the charging voltage of power supply equipment is DC57.5±0.1V;
Wrench
Tapes
Tools
Clip-on ammeter
09
Multimeter
Insulating tape
Pliers
Clip Pliers
Strippers
